SPECIFICATIONS

d
Dimensions
Model
(H x W x D)
MCCSR1 23.4" x 18.0" x 20.9"
MCCSR1-P 594 x 458 x 531 (mm)
MCCSR2 23.4" x 18.0" x 41.7"
MCCSR2-P 594 x 458 x 1060 (mm)
f
▲ Model MCCSR2
Burners Net Weight
105.8 lbs.
1
2
a
c
▲ Model MCCSR1
e
NG
Pressure
(PSI/W.C.)
0.144 PSI
(48 kg) 4" W.C.
147.7 lbs. 0.144 PSI
(67 kg) 4" W.C.
7
b
a. 23.4" (594 mm)
b. 18.0" (458 mm)
c. 20.9" (531 mm)
d. 23.4" (594 mm)
e. 18.0" (458 mm)
f. 41.7" (1060 mm)
Gas Type
LP
Pressure
BTU
(PSI/W.C.)
0.36 PSI 10"
80,000
W.C.
0.36 PSI 10"
160,000
W.C.
Figure 1
BTU
50,000
100,000
