- Page 1 PLC KITS Quick Start Guide Please read the Quick Start Guide carefully before using the product and keep it. Related tools and documents of products, please download from www.herospeed.net.
-
Page 2: Safety Precautions
Statement Thank you for purchasing our company’s products, any questions&assistance you need, welcome to contact us at any time. This user manual is suitable for PLC NVR Kits( Power Line Communication NVR & Power Line Communication camera). It will be updated according to product’s updating, new version will be not noticed specifically. - Page 3 Products Appearance Description Ethenet、 Audio Output、Audio Input、VGA、HD、USB、DC12V Audio Output Ethenet Ethenet HD Port HD Port Audio Output Audio Input DC 12V Audio Input DC 12V Notes: Images for instruction use only, the final goods are subjected to the real object. PLC NVR Kits Quick Installation Guide PLC（Power Line Communication）,it is the network signal coupled to the power transmission line,no need cable,Plug and play,no need any setting,easy installation.
- Page 4 Keep the connected PLC camera and PLC recorder at the same ammeter,then we can operate it.The default NVR address http://192.168.1.88,refer to the below connection. Please pay special attention when installing: 1. With the same meter,no more than three air switch. 2.
- Page 5 Notes: Images for instruction use only, the final goods are subjected to the real object. Make sure the PLC KITS work normally：NVR connection the monitor,and all the devices are in power.When the monitor display the videos of all the IPC,it shows the devices running well.
-
Page 6: System Login
System login Start up the NVR,right click the desktop and enter the user login interface. Input the user name and password. System default user name : “ admin” password : “12345”. Preview Enter preview interface after device start up.Preview interface include date and time of system,and channel name.Login system,double left click to switch between full screen and multi-screen. - Page 7 Shortcut menu introduction Click the right mouse button pop-up shortcut menu, shortcut menu consists of the following three parts: Preview mode: Select the preview mode in the menu bar you like. Shortcut menu mode: In the menu bar wheel tour, video settings, add equipment, video playback, PTZ settings and NVR image color, you can directly enter the appropriate menu.
- Page 8 2. In the shortcut menu, click [Record],enter the video settings interface, or in the main menu,click the left mouse button [Record], to enter the video settings interface, NVR default all time ordinary Video. 3. Motion Detection Seetting,Enable “Motion”to activate motion recording,motion sections have no more than 6 times each day.
- Page 9 Playback Enter “Playback” interface by clicking “Playback” from shortcut or main menu, select channels and search the record files and playback what you want. (Video playback interface)
-
Page 10: Live View
1. Left click 【1-Win】/【4-Win】/【8-Win】/【9-Win】in the menu, it is available to add single channel or multi-channels on one screen. 2. PLC kits have matched Add Camera by default.Keep all the devices at the same ammeter,power on,it can realize the time preview when connecting the display device,if you change the defaulted IP address of IPC,you need to re-add the remote device. - Page 11 Webpage NVR Login １. Login NVR LAN( Same router in same computer, also named intranet) ① Connect PC with LAN of NVR with internet, confirm NVR and computer with the same network segment. If computer do not have the network segment, need add one same network segment with NVR.
- Page 12 2. Login IPC LAN( Same router in same computer, also named intranet) ① First set the PC's IP address and IPC for the same network segment, such as PC's IP can be set to "192.168.1.104" (Note: IPC default address of 192.168.1.100 ~ 103).
- Page 13 Mobile App Access Download and install iVMS320 on smart phone by following way: 1. In the Android phone App Store or iPhone App Store enter “iVMS320” search, download and install. 2. Scan the following QR codes to download and install the App. Android 3.
- Page 14 ⑤ ⑥ ⑦ ⑧ ① Click 【Device manage】in the sliding menu bar; ② Click【 】; ③ Click 【 Add device】; ④ Click 【SN Add】; ⑤ Scan the QR Code printed on the device sticker or posted on the P2P interface; ⑥...
