- Page 1 XVR Kits Quick Start Guide Please read the Quick Start Guide carefully before using the product and keep it. Related tools and documents of products, please download from www.herospeed.net.
-
Page 2: Safety Precautions
Statement Thank you for purchasing our products, if you have any questions or requires, please contact us. This Guidelines adapt for XVR and HD cameras in the kits.It will be updated subject to product’s updating; new version will be not noticed specifically. If this manual’s any products description not accord with the real products, please in kind prevail. -
Page 3: Step 1: Installation Preparation
Notes: Image for instruction use only, the final goods are subjected to the real object. XVR Kits Quick Installation Guide XVR Kits is convenient for installation via easy plug & use, no need any set up. Start the installation guide step into: Step 1: Installation Preparation Install XVR hard drive. - Page 4 Step 2: Device Connection Use the 5ch power cable splitter to connect with the power supply, and another end connect with XVR recorder and the HD camera power supply. XVR recorder will preview the screen via the BNC cable. default (XVR address: //192.168.1.88), the connect way as below: 12V/5A Note: The picture is for reference only, the final product to prevail in kind Step 3: Make sure XVR kit working well：...
- Page 5 Start up the XVR, right click the desktop and enter the user login interface. Input the user name and password, click " Login ". System default user name : "admin" password : "12345". Enter preview interface after device start up. Preview interface include date and time of system, and channel name.
-
Page 6: Recording Setting
Shortcut Menu Introduction Click the right mouse button pop-up shortcut menu, shortcut menu consists of the following three parts: Preview mode: Select the preview mode in the menu bar you like. Shortcut menu mode: It contains 【Poll】, 【Record】, 【Add Camera】 , 【XVR image】, you can click and the enter corresponding menu directly. - Page 7 3、Motion Detection Setting. Enable “Motion” to activate motion recording, motion sections have no more than 6 times each day. If the setting of manual record and motion record are overlapped, it can only save the motion records while motion detection comes up. Enter “Playback”...
- Page 8 XVR kits default match cameras device, connect all the devices to XVR, power on, connect the monitor device, then can real time preview. Left click 【1-Win】/【4-Win】in the menu, and enter real time view interface, can add one or more cameras monitor Win at the same time.
- Page 9 PC Side LAN Access the PC and the device are in the same router XVR LAN login ( ① Make sure the recorder and the connected computer are in the same segment. If not, pleasse set IP address of your PC (computer) the same segment as the XVR’s, for example: ‘192.168.1.33, but it must be different IP as the XVR’s.
- Page 10 Mobile App Access Step 1: Download and install Bitdog on smart phone by following way: 1. In the Android phone App Store or iPhone App Store enter “Bitdog” search, download and install. 2. Scan the following QR codes to download and install the App. Android App QR iOS App QR 3.
