- Page 1 Smart XVR Kits Quick Start Guide Related tools and documents of products, please download from www.herospeed.net.
-
Page 2: Safety Precautions
Stetement Thank you for purchasing our products, if you have any questions or requires, please contact us. This manual is applicable to Smart XVR Kits (XVR and PIR sensor cameras, sound alarm cameras, and gas detection cameras). The manual contents will be updated according to the upgrade or change of the product function. - Page 3 Product Rear Panel Description XVR rear panel interface description：BNC Video input, CVBS Video output, Audio output, VGA Video output interface, HD video output interface, Audio input, Ethernet port, USB2.0 port, RS485 connection PTZ, power input, as below： power input BNC Video output Notes: Image for instruction use only, the final goods are subjected to the real object.
- Page 4 Step 2: Device Connection Use the 5ch power cable splitter to connect with the power supply, and another end connect with XVR recorder and the HD camera power supply. XVR recorder will preview the screen via the BNC cable. default (XVR address: //192.168.1.88), the connect way as below: 12V/5A Notes: Images for instruction use only, the final goods are applied to the real object Confirm XVR kit is OK：Connected the XVR with the display, HD camera access XVR via the BNC,...
-
Page 5: System Login
System Login Start up the XVR, right click the desktop and enter the user login interface. Input the user name and password, click " Login ". System default user name : "admin" password : "12345". Preview Enter preview interface after device start up.Preview interface include date and time of system, and channel name.Login system,double left click to switch between full screen and multi-screen. - Page 6 Shortcut Menu Introduction Click the right mouse button pop-up shortcut menu, shortcut menu consists of the following three parts: Preview mode: Select the preview mode in the menu bar you like. Shortcut menu mode: in the menu bar wheel tour, video settings, add equipment, video playback, PTZ settings and NVR image color, you can directly enter the appropriatemenu.
- Page 7 3、Motion Detection Setting. Enable “Motion” to activate motion recording, motion sections have no more than 6 times each day. If the setting of manual record and motion record are overlapped, it can only save the motion records while motion detection comes up. Playback Enter “Playback”...
-
Page 8: Live View
Live View XVR kits default match cameras device, connect all the devices to XVR, power on, connect the monitor device, then can real time preview. Left click 【1-Win】/【4-Win】/【8-Win】/【9-Win】in the menu, and enter real time view interface, can add one or more cameras monitor Win at the same time. Intelligent Alarm Right-click the shortcut menu in the XVR preview interface and click Main Menu→... - Page 9 Webpage XVR Login Login XVR LAN( Same router in same computer, also named intranet) ① Connect PC with LAN of XVR with internet, confirm XVR and computer with the same network segment. If computer do not have the network segment, need add one same network segment with XVR.
- Page 10 P2P Access XVR 1、When you make sure the XVR already connect the network, enter the main menu 【Configuration】 -【Network】 setting, enter “P2P’, click "Start P2P" until it show "Online". 2、Type http://www/freeip.com/ in the browser that the network can work in outer net, login account-configuration management-quickly adding device(type the device serial number(XVR main menu-network-P2P interface can check the XVR serial number)), user name(admin), password(12345) -My FREEIP-choose adding device, preview real time videos(Remark: The first time log in the web need...
-
Page 11: Android App
Mobile App Acess XVR Download and install FreeIP on your smart phone by following way: （1）In the Android phone Google App Store or iphone App Store enter “FreeIP” search,download and install. （2）Search the following QR codes to download and install the App. （3）Download from the following websites. - Page 12 Open the FreeIP app(New users please register an account),follow up the following steps to add the devices. ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ① Click 【Device】to add the device. ② Click the bottom of the interface【+Add device】,select “The serial number to add”into the QR code scanning interface.
