- Page 1 PoE NVR Kits Quick Start Guide Please read the Quick Operation Guide carefully before using the product and keep it. Related tools and documents of products, please download from www.herospeed.net.
-
Page 2: Safety Precautions
Statement Thanks for purchasing our products. If you have any questions or need, please contact us directly. This manual is used for PoE NVR and PoE cameras in the kit. The contents of this manual will be updated according to our products improvements. And updated contents will be added in new versions of this manual without prior notice. -
Page 3: Step1：Installation Preparation
Notes: Images for instruction use only, the final goods are subjected to the real object. PoE NVR Kits Quick Installation Guide This PoE NVR Kit can be easily installed, no need cable, plug and play and no need any set up. - Page 4 Step2：Device connection Power on the PoE NVR and connect it to Network. After connecting IP cameras with the POE port of NVR through network cable, the kit can work normally. Note: NVR default IP address is http://192.168.1.88. AUDIO IN POWER AUDIO OUT Notes: Images for instruction use only, the final goods are subjected to the real object.
-
Page 5: System Login
System login Start up the NVR,right click the desktop and enter the user login interface. Input the user name and password. System default user name : “ admin” Password : “12345”. Preview Enter preview interface after device start up.Preview interface include date and time of system,and channel name.Login system,double left click to switch between full screen and multi-screen. - Page 6 Shortcut menu introduction Click the right mouse button pop-up shortcut menu, shortcut menu consists of the following three parts: Preview mode: Select the preview mode in the menu bar you like. Shortcut menu mode: In the menu bar wheel tour, video settings, add equipment, video playback, PTZ settings and NVR image color, you can directly enter the appropriate menu.
- Page 7 3. Set the motion detection video, check the "motion detection", then you can open the dynamic detection of video, Everyday, you can set up to 6 intermittent scheduled time period. When colleagues set up ordinary video and motion detection video at the same channel, there is a motion detection occurs, you can query the motion detection video, then no ordinary.
-
Page 8: Live View
Live View 1. Left click【1-Win】/【4-Win】/【8-Win】/【9-Win】in the menu, and enter real time view interface, can add one or more cameras monitor pictures at the same time. 2. POE kits default match cameras device, connect all the devices to NVR, power on, connect the monitor device, then can real time preview, if you change the cameras default IP address, need to add again the devices to the NVR. - Page 9 Webpage NVR Login １. Login NVR LAN( Same router in same computer, also named intranet) ① Connect PC with LAN of NVR with internet, confirm NVR and computer with the same network segment. If computer do not have the network segment, need add one same network segment with NVR.
- Page 10 2. Login IPC LAN( Same router in same computer, also named intranet) ① First set the PC's IP address and IPC for the same network segment, such as PC's IP can be set to "192.168.1.104" (Note: IPC default address of 192.168.1.100 ~ 103). ②...
- Page 11 Mobile App Access Download and install iVMS320 on smart phone by following way: 1. In the Android phone App Store or iPhone App Store enter “iVMS320” search, download and install. 2. Scan the following QR codes to download and install the App. Android 3.
- Page 12 ⑤ ⑥ ⑦ ⑧ ① Click 【Device manage】in the sliding menu bar; ② Click【 】; ③ Click 【 Add device】; ④ Click 【SN Add】; ⑤ Scan the QR Code printed on the device sticker or posted on the P2P interface; ⑥...
