Manual Layout - Garmin GDL 82 Installation Manual

Record of Revisions
REVISION REVISION DATE
1 09/19/2017
2 10/12/2017
3 12/08/2017
4 01/17/2018
5 03/08/2018
Current Revision Change Description
SECTION
Updated required Windows operating system.
7.1
Added USB cable length requirement.
8.1.2 Updated name of switch and discrete input.

Manual Layout

The aim of this installation manual is to provide clear and concise guidance in a layout designed to follow the logical
order of a typical GDL 82 installation.
190-01810-00
Rev. 5
CHANGE DESCRIPTION
Initial Release.
Updated software and CLD part numbers.
Updated ADS-B In receiver descriptions.
Updated figure 5-1 J821 connector.
Updated PC requirements, USB cable length, and discrete input
information.
CHANGE DESCRIPTION
Record of Revisions
GDL 82 TSO Installation Manual
Page ii
