Specifications - 3rd Eye AWT09MLEDSD User Manual

ITEM
Input Level
Video Standard
Display Speed
Display
Resolution
Monitor Output
LINE Input Level
Output Level
Resolution
Active area
View angle
Luminance
Contrast ratio
Issued October 2018

Specifications

USER MANUAL
1.0 Vp-p±10% Composite, 75
Support NTSC (525 lines) / PAL (625 lines)
NTSC 240fps
PAL 200fps
CVBS 720 x 480, 720 x 576
Main 1.0Vp-p Composite, 75
x8 Audio Input @1Vp-p@20k
x1 -10dB 1K
Display (TFT LCD)
800 X 3 (RGB) X 480
198(W) X 111.70(H)mm
∘
0
70
∘
90
50
∘
180
70
∘
270
70
550
500
AWT09MLEDSD
SPECIFICATION
Video
W
W
Balanced
Audio
W
W
Balanced
(include 1CH MIC)
4
