ISOFIX UNIT fix 012 Instruction Manual page 21

2. VeHIcle INsTallaTIoN PoINTs
WHERE:
In the vehicle rear seats.
Please, do NOT install the safety seat in forward seats except for
the following cases:
1. whenever the vehicle does not count with rear seats.
2. when all rear seats are already occupied by children
exceeding 135 cm height.
3. when it is not possible to install all child restraints systems in
the rear seats.
HOW:
GROUP 0+ / Install rearward facing.
GROUP 1 / Install forward facing.
GROUP 2 / Install forward facing.
En asientos con:
Anclajes ISOFIX (entre el asiento y el respaldo) y puntos de anclaje
Top Tether (por ejemplo en la bandeja, en el suelo o detrás del
respaldo) y cinturón de 3 puntos (cinturón del vehículo).
NOTICE:
The child seat must only be used in this seat IF it has a lap and
diagonal belt (3 points).
3. INsTallING THe car seaT. GroUP 0+
notice
1. Check the seat is ready to be installed rearward facing (Group
0) as shown in fig. 3.1. Recline the seat fully. Pull the lever
forward and adjust the angle of recline to position 4 without
releasing the lever. Release the lever when the seat is in the
desired position.
2. Place the seat in the back seat of the vehicle and contrary to
the direction of travel (fig. 3.2).
GROUP 0+ only. 0 to 10 months
(0-10 Kg)
1
2
(H)
21
