Summary of Contents for ADJ AV4IP
- Page 1 AV4IP User Guide...
- Page 2 ©2018 ADJ Products, LLC all rights reserved. Information, specifications, diagrams, images, and instructions herein are subject to change without notice. ADJ Products, LLC logo, and identifying product names and numbers herein are trademarks of ADJ Products, LLC. Copyright protection claimed includes all forms and matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted.
-
Page 3: Table Of Contents
CONTENTS General Information Limited Warranty (USA Only) Safety Guidelines Maintenance Guidelines Panel Overview Handling and Transportation Installation Technical Specifications Optional Components & Accessories ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, Netherlands... -
Page 4: General Information
GENERAL INFORMATION With a brightness of 4000 NITS, a 4.81mm pixel pitch, and an IP rating, the AV4IP is a cost effective bright, high-resolution video panel designed for indoor or temporary outdoor use. Although the 3-in-1 RGB SMD1921 LEDs create an impressive brightness of 4000 NITS, making it ideal for outdoor daylight, with its 0-100% brightness adjustment, the intensity of the screen can be reduced for indoor applications. -
Page 5: Limited Warranty (Usa Only)
LLC factory. All shipping charges must be prepaid. If the requested repairs or service (including parts replacement) are within the terms of this warranty, ADJ Products, LLC will pay return shipping charges only to a designated point within the United States. If the entire instrument is sent, it must be shipped in its original package and packaging material. -
Page 6: Safety Guidelines
This panel is a sophisticated piece of electronic equipment. To guarantee a smooth operation, it is important to follow all instructions and guidelines in this manual. ADJ is not responsible for injury and/or damages resulting from the misuse of this panel due to the disregard of the information printed in this manual. - Page 7 CAUTION: Test panel for 2-hours per week, if not used regularly or for an extended period of time. CAUTION: Cases used to transport panel must me properly waterproofed for transportation. ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, Netherlands...
-
Page 8: Maintenance Guidelines
4. Check each AV4IP LED Video Panel for loose screws and other fasteners. 5. If the AV4IP LED Video Panel installation is fixed or displayed for a lengthy time, regularly inspect all rigging and installation equipment, and replace or repair it as necessary, and during long periods of non-use, disconnect the main power to the unit. -
Page 9: Panel Overview
PANEL OVERVIEW Each AV4IP LED Video Panel includes a quick-release power supply with 2X receiver card modules, allowing for easy serviceability and simple repairs whilst out on the road. The cover of the power supply box can be secured to protect all internal accessories and components. - Page 10 Power Input (+) etherCON/RJ45 Integrated Horizontal Locking Panel Connector & Sockets ESD Grounding Hole & Connection Plate AV4IP Overview Power Signal Test etherCON/RJ45 Power Input (+) Power Output (-) etherCON/RJ45 ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, Netherlands...
-
Page 11: Handling And Transportation
HANDLING AND TRANSPORTATION The corners of the AV4IP LED Video Panel are susceptible to damage during handling and transportation. When removing AV4IP LED Video Panels from their respective Flight Cases (AV3FC sold separately), and before they are installed, take care to avoid damaging any of the 4 corners. - Page 12 HANDLING AND TRANSPORTATION The optional AV3FC Flight Case (sold separately) for the AV3 and AV4IP LED video panels holds 8x AV4IPs. The flight case features a full foam lining with slots for each unit. The case is robust, so will completely protect a set of panels on the road.
-
Page 13: Installation
If you lack these qualifications, do not attempt the installation yourself. Improper installation can result in bodily injury and property damage. ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, Netherlands... - Page 14 1. Align the locking-tab with keyed connector socket tab-keyed connector socket 3. Turn the panel connector 4. To unlock, squeeze orange lever down to lock tab and rotate lever upwards ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, Netherlands...
- Page 15 Integrated Vertical Locking Connectors Integrated Horizontal Locking Connectors ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, Netherlands...
- Page 16 INSTALLATION - RIGGING The AV4IP is compatible with ADJ’s AV3RB1 rigging bar (sold separately), which easily and securely locks to the top of the first panel in a vertical hang of up to 15 AV4IPs, allowing them hang from a truss, hoist, or lintel beam.
-
Page 17: Technical Specifications
Connect the device to an electrical outlet on a circuit different from which the radio receiver is connected. Consult the dealer or an experienced radio/TV technician for help. 501032 ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, Netherlands... -
Page 18: Optional Components & Accessories
5ft. / 1.52M (CAT305) 10ft. / 3.04M (CAT310) Panel to Panel Data Link Cables (etherCON to etherCON) 15ft. / 4.87M (CAT315) 25ft. / 7.62M (CAT325) 50ft. / 15.24M (CAT350) ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, Netherlands... - Page 19 (THIS PAGE IS INTENTIONALLY LEFT BLANK) ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, Netherlands...
