E-Z-GO 295cc Shop Rebuild Manual page 91

ENGINE
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
175 601560
176 26642-G01
177 26681-G01
178 26673-G01
179
180 72507-G01
181
182 26675-G01
183 26673-G01
184 26674-G01
185
186 26716-G01
187 72512-G01
188
189 72540-G01
190 72541-G01
191 72542-G01
192
193 72543-G01
194 72544-G01
195 72545-G01
196 72857-G01
197 72508-G01
198 26728-G01
199 26727-G01
200 72840-G02
201 72840-G03
202 26706-G01
203* 72854-G01
204 26726-G01
Page F-12
1 2 3 4 5
CYLINDER BAFFLE, EXHAUST (1 PIECE MAN/EXH) ...............................
CYLINDER BAFFLE, EXHAUST ..................................................................
BOLT, FLANGED, M6 X 1 X 8MM................................................................
BOLT, FLANGED, M8 X 1.25 X 50MM.........................................................
VALVE, INTAKE ............................................................................................
BOLT, FLANGED, M8 X 1.25 X 40MM.........................................................
BOLT, FLANGED, M8 X 1.25 X 50MM.........................................................
BOLT, FLANGED, M8 X 1.25 X 60MM.........................................................
GASKET, CYLINDER HEAD, 295 cc ENGINE ONLY ..................................
GASKET, CYLINDER HEAD, 350 cc ENGINE ONLY ..................................
PISTON (STANDARD), 350 cc ENGINE ONLY ...........................................
PISTON (.25MM OVERSIZE), 350 cc ENGINE ONLY.................................
PISTON (.50MM OVERSIZE), 350 cc ENGINE ONLY.................................
PISTON RING SET (STANDARD), 350 cc ENGINE ONLY .........................
PISTON RING SET (.25MM OVERSIZE), 350 cc ENGINE ONLY...............
PISTON RING SET (.50MM OVERSIZE), 350 cc ENGINE ONLY...............
VALVE, EXHAUST (1 PIECE MAN/EXH) .....................................................
VALVE, EXHAUST ........................................................................................
BRACKET, CHOKE CABLE ................................................................................
GASKET, AIR CLEANER....................................................................................
CARBURETOR (STANDARD), 295 cc ENGINE ONLY ......................................
CARBURETOR (STANDARD), 350 cc ENGINE ONLY ......................................
FLANGE NUT, M6 X 1.0......................................................................................
INSULATOR, 350 cc ENGINE ONLY ..................................................................
GASKET, CARBURETOR...................................................................................
Engine Shop Rebuild and Parts Manual
Illustrated Parts Breakdown
DESCRIPTION QTY.
