Admag SE100DJ/EJ User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's
Manual
Y okogawa Electric Corporation
Models SE100DJ/EJ, SE200DJ/EJ
and SE300DJ/EJ
Magnetic Flow Tube
IM 1E10D0-01E
IM 1E10D0-01E
8th Edition

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SE100DJ/EJ and is the answer not in the manual?

Questions and answers

Related Manuals for Admag SE100DJ/EJ

Summary of Contents for Admag SE100DJ/EJ

  • Page 1 User's Manual Models SE100DJ/EJ, SE200DJ/EJ and SE300DJ/EJ Magnetic Flow Tube IM 1E10D0-01E IM 1E10D0-01E 8th Edition Y okogawa Electric Corporation...

  • Page 2: Table Of Contents

    CONTENTS Contents INTRODUCTION ....................1-1 HANDLING PRECAUTIONS ................2-1 Checking Model and Specifications ............... 2-1 Accessories ...................... 2-1 Storage Precautions ..................2-1 Installation Location Precautions ..............2-1 Terminal Box Reorientation Precautions ............2-1 INSTALLATION ....................3-1 Piping Design Precautions ................3-1 Handling Precautions ..................

  • Page 3: Introduction

    1. INTRODUCTION INTRODUCTION The following safety symbol marks are used in This instrument has been already adjusted at the this manual and instrument; factory before shipment. To ensure correct use of the instrument, please read WARNING this manual thoroughly and fully understand how to operate the instrument before operating it.
  • Page 4 1. INTRODUCTION Warranty (2) Wiring • The guaranteed term of this instrument is described • The instrument must be installed by expert engineer or skilled personnel. The procedures in the quotation. We repair the damages that described about WIRING are not permitted for occurred during the guaranteed term for free.

  • Page 5: Handling Precautions

    2. HANDLING PRECAUTIONS HANDLING PRECAUTIONS 2.3 Storage Precautions This instrument has been already tested thoroughly at the factory. When the instrument is delivered, please check externals and make sure that no damage In case the instrument is expected to be stored over a occurred during transportation.

  • Page 6: Installation

    3. INSTALLATION INSTALLATION D: Nominal diameter of flow tube Gate valve Reducer pipe Expander pipe fully open WARNING This instrument must be installed by expert 5 D or more 2 D or more Do not care to 0 D Do not care to 0 D 10 D or more 2 D or more engineer or skilled personnel.
  • Page 7 3. INSTALLATION (5) Liquid Sealing Compound (BAD) (GOOD) (GOOD) (BAD) h>0 IMPORTANT h>0 Please give attention in using Liquid Sealing Horizontal mounting Vertical mounting F030104.EPS Compound to the piping, because it brings bad Figure 3.1.4 Filling the Pipe with Liquid influences to measurement by flowing out and cover the surfaces of electrode and earth-ring.

  • Page 8: Handling Precautions

    3. INSTALLATION (12) Grounding CAUTION In case the Magnetic Flow Tube without eye-bolt IMPORTANT lifts up, please refer to Figure 3.2.1. Please Improper grounding can have an adverse affect never lift up by using a bar through the flow on the flow measurement. Please ensure that tube.

  • Page 9: Flow Tube Piping

    3. INSTALLATION CAUTION Be sure to lock the cover with the special screw using the Hexagonal Wrench attached after tightening the terminal box cover. (5) Long-term Non-use Mis-alignment Slant F030202.EPS Figure 3.2.2 Slant and Mis-alignment of Flow Tube Piping IMPORTANT It is not preferable to leave the flow tube for long term non-use after installation.
  • Page 10 3. INSTALLATION (3) Positioning Flow Tube Please pass two through-bolts to adjacent holes of both flanges and mount the Flow Tube, and pass other Through-Bolt and nut through-bolts to other holes. (Refer to Figure 3.3.1) In Please use appropriate bolts and case stud type of through-bolts are used, position them Flange nuts according to Process connection.

  • Page 11: Nominal Diameter 50 Mm(2˝) To 200 Mm(8˝) Wafer Type

    3. INSTALLATION 3.3.2 Nominal Diameter 50 mm(2˝) to (2) Mounting Centering Devices 200 mm(8˝) Wafer Type To keep concentricity between the Flow Tube and pipes, centering devices must be used. Pass two through-bolts through the four centering devices (two IMPORTANT for each) and lower adjacent holes of both flanges.
  • Page 12 3. INSTALLATION Table 3.3.3 Tightening Torque Values for Metal Piping in N-m{kgf-cm}[in-lbf] Size mm(inch) JIS 10K JIS 20K ANSI 150 ANSI 300 DIN PN10 DIN PN16 DIN PN40 50(2) 35.0 - 39.5 16.5 - 19.5 35.0 - 39.5 16.5 - 19.5 39.0 - 39.5 {357 - 403} {168 - 199}...

  • Page 13: Nominal Diameter 15 Mm (0.5˝) To 400 Mm (16˝) Flange Type

    3. INSTALLATION 3.3.3 Nominal Diameter 15 mm (0.5˝) (2) Tightening Nuts to 400 mm (16˝) Flange Type Please tighten the bolts according to Torque Values in Table 3.3.7. In case of PVC piping, please select optional code/FRG, use rubber gasket and tighten with IMPORTANT the torque value in Table 3.3.8.
  • Page 14 3. INSTALLATION Table 3.3.7 Tightening Torque Values for Metal Piping in N-m{kgf-cm} [in-lbf] Size mm(inch) JIS 10K JIS 20K ANSI 150 ANSI 300 DIN PN10 DIN PN16 DIN PN40 JIS F12(75M) 15(0.5) 4.5 - 6.5 4.5 - 6.5 4.5 - 7.0 4.5 - 7.0 4.5 - 6.5 {46 - 66}...

  • Page 15: Wiring Precautions

    300 m (984 ft.) Maximum temperature: 80°C (176°F) CAUTION Please be sure to connect function grounding of ADMAG SE with cable of 2mm or larger cross section in order to prevent the influence of external noise. And further connect the grounding wire to the mark (100Ω...

  • Page 16: Connnection To Se14 Magnetic Flow Converter

    Flow Converter electrodes (these are actively driven shields). This is done to reduce the effect of the distrib- Flow Tube Model SE100DJ/EJ, SE200DJ/EJ uted capacitance of the cable at long cable and SE300DJ/EJ length. Note that, since the signals from the...
  • Page 17 3. INSTALLATION Waterproof gland Waterproof gland with union joint Optional specification code: /ECG Optional specification code: /ECU Washer G1/2 female Gasket Tightening gland Cable G1/2 female F030405. Figure 3.4.5 Waterproof Gland B : Insulation Check After wiring is completed, check insulation of the following terminals together with the wiring under the condition of the converter side wiring terminals disconnected.

  • Page 18: Maintenance

    Determine the period of regular inspection as necessary. 4.2 Trouble Shooting Since the ADMAG SE magnetic flowmeter has “self diagnostic functions”, if a failure occurs, it is displayed on the SE14 magnetic flow converter. Please refer to Instruction Manual of SE14 magnetic flow converter.

  • Page 19: Outline

    5. OUTLINE OUTLINE • Non-asbestos joint sheet sheathed with fluoro STANDARD SPECIFICATIONS resin PTFE (between earth ring and process Protection: IP67, NEMA 4X, JIS C0920 water tight type flange; for optional code /BSF) Size in mm (inch): * Other gaskets between flow tube and earth ring; 15 (0.5), 25 (1), 40 (1.5), 50 (2), 80 (3), 100 (4), •...
  • Page 20 5. OUTLINE Safety Requirement Standard: ACCESSORIES IEC1010, EN61010 Centering device 1 set (in case of wafer type) EMC Conformity Standard: Hexagonal wrench EN61326 (for special screw of Terminal cover) 1 EN61000-3-2, EN61000-3-3 AS/NZS 2064 TERMINAL CONNECTION NORMAL OPERATING CONDITIONS Terminal Description Symbols °...
  • Page 21 5. OUTLINE MODEL AND SUFFIX CODE Magnetic Flow Tube : SE100DJ/EJ and SE200DJ/EJ Model Suffix code Description ....SE115 Nominal Size 15mm (1/2in.) ....
  • Page 22 5. OUTLINE Magnetic Flow Tube : SE300DJ Model Suffix code Description ....SE325 Nominal Size 250mm (10in.) ....SE330 Nominal Size 300mm (12in.) .
  • Page 23 5. OUTLINE EXTERNAL DIMENSIONS Magnetic Flow Tube 15mm (0.5in) Wafer Type Unit : mm (inch) ø86 (3.4) 111 (4.4) 48 (1.9) Ground Terminal (M4) *1 When no earth ring is selected the face to face length is shorter by approx. 1.6mm (0.06in). The face to face length is longer by approx.
  • Page 24 5. OUTLINE 250 and 300mm (10 and 12in) Wafer Type Unit : mm (inch) ø86 (3.4) Ground Terminal 48(1.9) (M4) 111 (4.4) Unit : mm (Approx. inch) Model SE325DJ SE330DJ Nominal Size (10) (12) Lining Fluorocarbon PFA (18.5) (20.4) Height (13.4) (15.3) Outside diameter...
  • Page 25 5. OUTLINE 80mm (3in) , 100mm (4in) Flange Type Unit : mm (inch) ø86(3.4) 48(1.9) Ground Terminal 111(4.4) (M4) *1 When no earth ring is selected the face to face length is shorter by approx. 1.6mm (0.06 in). The face to face length is longer by approx. øD 22mm (0.87in) for earth ring(P,T).
  • Page 26 5. OUTLINE 250mm (10in), 300mm (12in), 350mm (14in), 400mm (16in) Flange Type Unit : mm (inch) ø 86(3.4) 48(1.9) Eye Bolt Ground Terminal 111(4.4) (M4) *1 When no earth ring is selected the face to face length is shorter by approx. 26mm (1.02 inch) for 250mm(10 inch), 6mm (0.23 inch) for 300mm (12 inch), 10mm (0.4 inch) for 350mm (14 inch)

  • Page 27: Explosion Protected Type Instrument

    6. EXPLOSION PROTECTED TYPE INSTRUMENT EXPLOSION PROTECTED TYPE INSTRUMENT (3) Installation In this section, further requirements and differences for explosion proof type instrument are described. For WARNING explosion proof type instrument, the description in this chapter is prior to other description in this User's •...

  • Page 28: Csa

    6. EXPLOSION PROTECTED TYPE INSTRUMENT (2) Wiring ENCLOSURE : Enclosure protection number LININGL : Material of liner TAG NO. : Tag number WARNING SIZE : Nominal size of apparatus METER FACTOR : Sensor constant number of apparatus • All wiring shall comply with national electrical ELECTRODE : Material of electrodes code ANSI/NFPA 70 and local electrical code.

  • Page 29: Saa

    6. EXPLOSION PROTECTED TYPE INSTRUMENT (2) Wiring 6.4 SAA WARNING (1) Technical Data SA Certificate No.: AUS Ex 3764X All wiring shall comply with Canadian Electrical Type of Protection : Ex d m ia II C T6...T3 Code Part I and Local Electrical Codes. Enclosure Type : IP67 Note a warning label worded as follows.

  • Page 30: Pressure Equipment Directive

    7. PRESSURE EQUIPMENT DIRECTIVE PRESSURE EQUIPMENT DIRECTIVE (3) Operation This chapter is described further requirements and notices concerning the PED (Pressure Equipment WARNING Directive). The description in this chapter is prior to other description in this User's Manual. • The temperature and pressure of fluid should be applied under the normal operating (1) Technical Data condition.
