Matco Tools MFJ2QL Operating Manual page 3

Model # MFJ2QL 2 Ton Capacity Heavy Duty Quick To Load Service Jack
16
Item Part
No. No. Description
1 Frame
2 2QL02 Front Wheel Ass'y
3 2QL03 Retaining Ring
4 2QL04 Rear Caster Ass'y
5 2QL05 Lock Nut
6 Tensile Bar
7 Nut
8 Spring Washer
9 Bolt
10 Spring Washer
11 Bolt
12 Pin
13 Spring Washer
14 Nut
15 Bolt
16 Lift Arm Part
17 Shaft
18 2QL18 Saddle
19 Nut
20 3543 Saddle Cover
21 Filler Hold Cover
22 2QL22 Power Unit Assembly
2QL22SK Seal Kit for Power Unit
19
20
21
17
18
11
12
1
3
2
Qty.
1
2
2
2
2
1
2
2
1
2
2
2
2
2
1
1
1
1
2
1
1
1
Only items identified by part number are available for purchase.
Also Available: 2QLFP – Oil Fill Plug
25
26
24
23 25
34
27
29
9
8
10
15
5
7
6
L
4
13
14
Item Part
No. No.
23
24
25
26
27 2QL27
28
29 2QL29
30 2QL30
31
32
33
34 2QL34
35
36
37-1 2QL37-1
37-2 2QL37-2
38 2QL38
39 3544
40
41
3
22
40
41
39
37-2
37-1
31
38
32
33
30
35
36
28
Description
Connector
Pin
Spring
Washer
Handle Socket
(includes #31-36)
Pin
Spring
Bolt
Bolt
Pin
Washer
Gear Set
Spring Washer
Nut
Lower Handle
Upper Handle
Handle Bolt
Handle Cover
Low Pressure
Pump Piston
Qty.
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Rev. 10/11/01
