Page 1 READ, UNDERSTAND, and FOLLOW the Safety and Operation Instructions contained in this manual before operating the equipment. RHINO ® 1020 S. Sangamon Ave. Gibson City, IL 60936 800-446-5158 Email: parts@servis-rhino.com © 2004 Alamo Group Inc. P/N 00763618C $0.00...
Page 2: Before You Start
All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
Page 3: Before Operating
In order to reduce accidents and enhance the safe operation of mowers, Alamo Group Ag Division, in cooperation with other industry manufacturers has developed the AEM/FEMA Industrial and Agricultural Mower Safety Practices video and guide book. The video will familiarize and instruct mower-tractor operators in safe practices when using industrial and agricultural mowing equipment.
Page 4 Alamo Group Ag. Division is willing to provide one (1) AEM Mower Safety Practices Video Please Send Me: VHS Format – AEM/FEMA Mower Operator Safety Video DVD Format – AEM/FEMA Mower Operator Safety Video Mower Operator’s Manual AEM Mower Operator’s Safety Manual Requester Name: Requester Address: City...
Page 5: Table Of Contents
TABLE OF CONTENTS SAFETY SECTION ... 1-1 Decal Location ... 1-12 Decals ... 1-15 Federal Laws & Regulations ... 1-18 INTRODUCTION SECTION ... 2-1 ASSEMBLY SECTION ... 3-1 Tongue Jack and Wheel Attachment ... 3-2 Swivel & Lift Arm Attachment ... 3-3 Hydraulic Cylinder Attachment ...
Page 7: Safety Section
SAFETY SECTION Safety Section 1-1...
Page 8: Decals
A safe and careful operator is the best operator. manufacturer and should be to the owner/operator. Most accidents can be avoided by being aware of your equipment, your surroundings, and observing certain precautions. The first section of this manual includes a list of Safety Messages that, if followed, will help protect the operator and bystanders from injury or death.
Page 9 Never operate the Tractor or Implement until you have read and DANGER! completely understand this Manual, the Tractor Operator’s Manual, and each of the Safety Messages found in the Manual or on the Tractor and Implement. Learn how to stop the tractor engine suddenly in an emergency.
Page 10 DANGER! Start tractor only when properly seated in the Tractor seat. Starting a tractor in gear can result in injury or death. Read the Tractor operators manual for proper starting instructions. DANGER! Never work under the Implement, the framework, or any lifted component unless the Implement is securely supported or blocked up to prevent sudden or inadvertent falling which could cause serious injury or even death.
Page 11 WARNING! Periodically inspect all moving parts for wear and replace when necessary with authorized service parts. Look for loose fasteners, worn or broken parts, and leaky or loose fittings. Make sure all pins have cotter pins and washers. Serious injury may occur from not maintaining this machine in good working order.
Page 12 DANGER! Never run the tractor engine in a closed building or without adequate ventilation. The exhaust fumes can be hazardous to your health. DANGER! KEEP AWAY FROM ROTATING ELEMENTS to prevent entanglement and possible serious injury or death. Never allow children to play on or around Tractor or Implement. Children DANGER! can slip or fall off the Equipment and be injured or killed.
Page 13 DANGER! All Safety Shields, Guards and Safety devices including (but not limited to) - the Deflectors, Chain Guards, Steel Guards, Gearbox Shields, PTO integral shields , and Retractable Door Shields should be used and main- tained in good working condition. All safety devices should be inspected carefully at least daily for missing or broken components.
Page 14 Replace bent or broken blade with new blades. NEVER ATTEMPT TO DANGER! STRAIGHTEN OR WELD ON BLADES SINCE THIS WILL LIKELY CRACK OR OTHERWISE DAMAGE THE BLADE WITH SUBSE- QUENT FAILURE AND POSSIBLE SERIOUS INJURY FROM THROWN BLADES. (SGM-10) WARNING! Do not let the Blades turn when the Mower Deck is raised for any reason, including clearance or for turning.
Page 15 DANGER! Rotary Mowers are capable under adverse conditions of throwing objects for great distances (100 yards or more) and causing serious injury or death. Follow safety messages carefully STOP MOWING IF PASSERSBY ARE WITHIN 100 YARDS UNLESS: -Mower Deck Shielding, and Discharge Deflector are installed and in good, working condition;...
Page 16 WARNING! Never leave Tractor and Implemented unattended while the implement is in the lifted position. Accidental operation of lifting lever or a hydraulic failure may cause sudden drop of unit with injury or death by crushing. To properly park the implement when disconnecting it from the tractor, lower the stand and put the retaining pin securely in place, or put a secure support under the A-Frame.
Page 17: Parts Information
SAFETY PARTS INFORMATION Servis-Rhino mowers use balanced and matched system components for blade carriers, blades, cuttershafts, knives, knife hangers, rollers, drivetrain components, and bearings. These parts are made and tested to Servis- Rhino specifications. Non-genuine "will fit" parts do not consistently meet these specifications. The use of “will fit”...
Page 18 NOTE: Rhino supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in shipping, use, or reconditioning. Rhino cares about the safety of its customers, operators, and bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).
Page 19 NOTE: Rhino supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in shipping, use, or reconditioning. Rhino cares about the safety of its customers, operators, and bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).
Page 20 ITEM PART NO. 00725746 00753840 00756004 00756004 00756005 00756059 00756494 00758194 00760657 00773723 00763536 00769736 00769737 02962765 02967827 D103 03200347 1458392 1458393 000678 00755691 00763613 00763977 D102 D301 D302 00763535 00763539 00763539A 00763539B 00763539C 00776481 00776031 00763618C 10058000 00024100 02959924 (( )) Installed by D/L Mfr.
Page 21 SAFETY 13 -- 02967827 Front Cover 15 -- 03200347 SMV reflector 16 -- 99203 Red Reflector 17 -- 99204 Yellow Reflector 1 -- 00725746 3 -- 00756004 2 -- 00753840 5 -- 00756059 4 -- 00756005 7 -- 00758194 R 07-31-97 Safety Section 1-15 Turf Flex 08/01...
Page 22 SAFETY 14 -- D103 6 -- 00756494 18 -- 000678 9 -- 00763536 8 -- 00760657 11 -- 00769737 R 04-23-99 Safety Section 1-16 Turf Flex 08/01 © 2004 Alamo Group Inc.
Page 23 SAFETY 10 -- 00769736 19 -- 00755691 24 -- D302 25 -- 00763535 TURF FLEX Name 26 -- Model Number 27 -- Serial Plate 28 -- Serial Plate 29 -- Serial Plate 30 -- Serial Plate 20 -- 00763613 23 -- D301 R 12-09-94 Safety Section 1-17 Turf Flex...
Page 24 SAFETY 22 -- D102 21 -- 00763977 8A -- 00773723 31 -00776481 Safety Section 1-18 Turf Flex 08/01 © 2004 Alamo Group Inc.
Page 25: Federal Laws & Regulations
FEDERAL LAWS AND REGULATIONS This section is intended to explain in broad terms the concept and effect of federal laws and regulations concerning employer and employee equipment operators. This section is not intended as a legal interpretation of the law and should not be considered as such.
Page 71: Introduction Section
INTRODUCTION SECTION Indroduction Section 2-1...
Page 72 This Rotary Mower is designed with care and built with quality materials by skilled workers. Proper assembly, maintenance, and operating practices, as described in this manual, will help the owner/operator get years of satisfactory service from the machine. The purpose of this manual is to familiarize, and instruct. The Assembly Section instructs the owner/ operator in the correct assembly of the Mower using standard and optional equipment.
Page 73 Your Turf Flex is designed for light-duty cutting such as lawn maintenance plus small weed and grass control. With a reasonable amount of preventive maintenance, your Mower will provide years of dependable service. NEVER ALLOW CHILDREN TO OPERATE, RIDE ON, OR COME CLOSE DANGER TO MOWER OR TRACTOR.
Page 74: Attention Owner/Operator
REPLACEMENT PARTS MAY CAUSE PREMATURE OR CATASTROPHIC FAILURE WHICH COULD RESULT IN SERIOUS INJURY OR DEATH. QUESTIONS CONCERNING THE REPAIR PARTS YOU ARE USING, CONTACT SERVIS-RHINO, P. O. BOX 712, SEGUIN, TX 78156. Turf Flex 08/01 © 2004 Alamo Group Inc.
Page 75: Assembly Section
ASSEMBLY SECTION Assembly Section 3-1...
Page 76: Dealer Set-Up Instructions
DANGER! Operating with PTO speed over 540 RPM can cause excessive vibration with subsequent machine failure which can cause serious injury or even death. Never exceed 600 RPM. DEALER SET-UP INSTRUCTIONS Assembly of this mower is the reponsibility of the Rhino dealer. The mower should be delivered to the owner completely assembled, lubricated, and adjusted for normal cutting conditions.
Page 77: Swivel & Lift Arm Attachment
SWIVEL AND LIFT ARM ATTACHMENT Attach the Swivel Assembly on the Lift Arms using chrome plated Attaching Pin (1) retain with Roll Pin (2). Figure 3. Remove the Attaching Pin (3) from the Main Frame. Attach the Right and Left Lift Arm (Note Jack storage mount on Left Lift Arm only) to the Main Frame with attaching Pin (3).
Page 78: Hydraulic Cylinder Attachment
ASSEMBLY HYDRAULIC CYLINDER ATTACHMENT Attach the Rear Hydraulic Cylinder to the Main Frame with Fittings pointing down. Retain with Pin and Cotter Pin. Figure 5. Attach the Wing Hydraulic Cylinders to the the Main Frame and Toggel Links with Pins provided.
Page 79: Caster Wheel Attachment
CASTER WHEEL ATTACHMENTS REAR MOWER (FIGURE 8) Attach the right and left Axle Arm Weldment (1) to the deck with 3/8" Gr. 5 bolts (2) flatwasher (1-1/2OD x 3/16 thick) (3), and 3/8 locknuts (4). Install four one inch spacers (7) and two 1/4 inch spacer (8) on each fork and wheel assembly (9).
Page 80 ASSEMBLY CASTER WHEEL ATTACHMENTS WING MOWER (FIGURE 9) Attach the inside (1) and outside Axle Arm Weldments (1 or 1A) to the outer deck with 3/8" Gr. 2 bolt (2), flatwasher (1-1/2"OD x 3/16" thick) (3), and 3/8" locknut (4) installed in outer front hole.
Page 81: Rear Mower Attachment
CASTER WHEEL ATTACHMENTS WING MOWER (11' MODEL) FIGURE 11 Attach the right and left Axle Arm Weldment (1) to the outer deck with 3/8" Gr. 2 bolts (2) flatwasher (1-1/ 2"OD x 3/16" thick) (3), and 3/8" locknuts (4) in the front hole in Arm. All other Arm retaining bolts are Gr.
Page 82: Axle Arms
ASSEMBLY AXLE ARMS IN POSTION Note bolt locations of Axle Arms on 60" Deck. Figure 13. FIGURE 13 Turf Flex 08/01 Assembly Section 3-8 © 2004 Alamo Group Inc.
Page 83 ASSEMBLY AXLE ARMS IN POSTION Note bolt locations of Axle Arms on 72" Deck. Figure14 FIGURE 14 Turf Flex 08/01 Assembly Section 3-9 © 2004 Alamo Group Inc.
Page 84: Driveshaft Attachment
ASSEMBLY DRIVESHAFT ATTACHMENT All drivelines are equipped with slide collars on end yokes. To attach to the shaft grab and pull the collar on the end of attaching yoke toward the opposite end of the driveline. Slide the yoke (with collar depressed) onto the shaft.
Page 85: Wing Driveshaft Attachment
WING DRIVESHAFT ATTACHMENT Standard Driveline Attach the wing driveline to the center power divider gearbox as shown so that both sides of the gearbox are oriented the same NOTE: The driveline end with the extended shield cone attaches to the mower deck gearbox. (FIGURE16) LEFT WING DRIVELINE Constant Velocity (CV) Driveline...
Page 86: Rope Routing For Automatic Head Lock
ROPE ROUTING FOR AUTOMATIC HEAD LOCKS Attach rope ends to latch at location shown in figure 18. NOTE: 11' Model Only Turf Flex 08/01 © 2004 Alamo Group Inc. ASSEMBLY FIGURE 18 Latch Angle Lift Arm Pin wing Ref. Hole Clear- ance Latch...
Page 87 NOTE: FIELD ASSEMBLY (FIGURE 19)- Head Locks 1. Loop ends back through welded link on lock bar and then inside of braid by forming a hole 16" from end. 2. Adjust lengths as shown to give 8" overlap and 4" loop.
Page 89: Operation Section
OPERATION SECTION Operation Section 4-1...
Page 90: Tractor Preparation
The safe operation of this machine is the responsibility of the operator. The operator should be familiar with the mower and tractor and all safety practices before starting operation. This mower is designed for lawn or grass mowing. It is not designed for rough conditions or heavy weed mowing. It is equipped with suction type blades for best results in lawn mowing.
Page 91 NOTE: If attaching Mower Clevis, tractor drawbar must extend to rear to allow turning without binding in the Tongue Clevis. DO NOT USE THIS TYPE DRAWBAR WITHOUT STABILIZERS. Install washers the same as detailed previously. See art below. CONTACT HERE DRAWBAR WILL CAUSE IMMEDIATE...
Page 92: Cutting Height Adjustment
DRIVELINE ATTACHMENT TO TRACTOR 1. Grasp and pull collar on end of attaching yoke toward mower. 2. Slide yoke (with collar depressed) onto PTO shaft. 3. Move yoke back and forth until locking collar clicks forward and locks the yoke in place. WARNING! When attaching PTO yoke to tractor PTO shaft, it is important that spring activated locking collar slides freely and is seated in groove on PTO shaft.
Page 93: Cutting Speed
STARTING & STOPPING MOWER Power for operating mower is supplied from tractor PTO. Refer to your tractor manual instructions for engaging and disengaging the PTO. Always engage the PTO at low engine rpm. Always operate at recommended PTO speed of 540 RPM. Learn how to stop tractor and mower quickly in case of an emergency. IMPORTANT: Stop mower and tractor immediately upon striking an obstruction.
Page 94: Driveline Length Check Procedure
DETACHING AND STORING Lower the Mower to the Ground. Park the Tractor with the transmission in the correct gear ( Automatic Trans- mission-- Park; Standard Transmission--Neutral). Set the parking brake, shut off the engine, and remove the key. Wait until the PTO stops rotating before getting down from the tractor . Disconnect the driveline from the tractor PTO and store it to prevent it from contacting the ground.
Page 95 With the PTO NOT TURNING, slowly drive the tractor with mower attached through sharpest turn possible and watch shaft movement. With PTO NOT TURNING, slowly drive the tractor with mower attached through the most severe terrain conditions expected and watch Shaft movement. Check position which places driveline at maximum extended length and at maximum compressed length.
Page 96 If you have a condition where your tractor will be going up a steep incline with your mower still on the flat area or coming down the opposite incline, you have a potential problem. Figure 11. The correct preventive measure is to instruct the operator to cross this kind of terrain at an angle.
Page 97 CV DRIVELINE CHECK PROCEDURES The Main Driveline to tractor is equipped with a special constant velocity (CV) joint that allows the joint to run smooth with no vibration even at joint angles up to 80 degrees. This joint will operate and perform satisfactorily as long as it is not subjected to conditions which abuse it or go beyond its operating limits.
Page 98: Troubleshooting
PROBLEM POSSIBLE CAUSE STREAKING Slow Blade Speed Worn Blade Tips Dull Blades Blades unable to cut that part of grass pressed down by path of tractor tires or casters Mowing Too Fast Drive Belt Loose Belt Glazed/Slipping Blade Loose on Spindle Conditions too wet for mowing MATERIAL DISCHARGES Material too high and too much...
Page 99 PROBLEM POSSIBLE CAUSE BELT SLIPPAGE Mower overloading, material too tall or heavy Oil on belt from over lubrication Belt hung up or rubbing FRAYED EDGES ON Belt misaligned or belt rubbing BELT COVER guide. Pulley misalignment BELT ROLLOVER Pulley misalignment Damaged belt Foreign object in pulley grooves Worn pulley groove...
Page 101: Maintenance Section
MAINTENANCE SECTION Maintenance Section 5-1...
Page 102: Lubrication Information
Before operating your Mower, make sure it is properly lubricated and thoroughy inspected. Only a minimum of time and effort is required to regularly lubricate and maintain this machine to provide long life and trouble free operation. WARNING! Always disengage the PTO before raising the mower for transporting or making adjustments.
Page 103: Gearbox
MAINTENANCE GEARBOX The Gearboxes have been filled with lubricant to the Test Plug Level prior to shipment. However, you should check the oil level at Test Plug before operating, and frequently thereafter. The gearbox should not require additional lubricant unless the box is cracked or a seal is leaking. It is recommended that the oil level plug be removed after every 8 to 10 hours of operation and oil added until it runs out Test Plug hole.
Page 104: Swivel Assembly
MAINTENANCE SWIVEL ASSEMBLY The Swivel Assembly should be lubricated every 8 hours. Figure 3. FIGURE 3 GAUGE WHEEL ASSEMBLIES Gauge wheels are equipped with bushings which require grease daily. Grease Fittings are provided in the Wheel Hub and Gauge Wheel Pivot . Grease after 8 hours of use. Figure 4 &5. FIGURE 4 FIGURE 5 BLADE SPINDLE LUBRICATION...
Page 105: Driveline Lubrication
DRIVELINE LUBRICATION The Drivelines and U-Joints should be inspected each morning before the mower is started. FIGURE 7 The U-Joint and CV Joint on the Driveline undergo extreme forces when the unit is turning or when the Wings are being raised. It is important that the U-Joints and CV Joint be greased each day before the unit is started, and after each 8 hours of use.
Page 106: Blade Servicing
BLADE SERVICING Inspect blades before each use to determine that they are properly installed and in good condition. Replace any blade that is bent, excessively nicked, worn, or has any other damage. Small nicks can be ground out when sharpening. Use only original equipment blades on this mower.
Page 107 FIGURE 10 BELT ADJUSTMENT PROCEDURE (All Models except 11') Adjust the tension in the drive belt, item1, properly so that it deflects 3/4" when a force of approximately 10 lb. is applied as indicated. Tighten drive belt by loosening nut, items 2 & 5, and turn nut, item 3 against the anchor plate until proper tension is reached.
Page 108: Belt Adjustment Procedure
MAINTENANCE BELT ADJUSTMENT PROCEDURE (11' MODEL) Adjust the tension in the drive belt, item 1, properly so that they deflect 3/4" when a force of approximately 10 lb. is applied. Tighten drive belt by loosening one nut, items 2, and tightening other nut until belt is properly tensioned. Jam the first Nut to hold adjustment.
Page 109: Storage
STORAGE Your rotary mower represents an investment from which you should get the greatest possible benefit. Therefore, when the season is over, the cutter should be thoroughly checked and prepared for storage so that a minimum amount of work will be required to put it back into operation for the next season. The following are suggested storage procedures: 1.
Page 110: Blade Spindle Service Instructions
BLADE SPINDLE SERVICE INSTRUCTIONS (FIGURE 13) DISASSEMBLY 1. Remove adjusting nut #3. 2. Support spindle housing #2 under flange and drive out shaft assembly #1. CAUTION! Use tube on top end of shaft to protect grease fitting. 3. Remove bearing cups from housing. Remove lower bearing from shaft assembly by inserting punch through hole in shaft hub and drive bearing off shaft.
Page 111: Clutch Assembly
MAINTENANCE CLUTCH ASSEMBLY (Figure 14) 1. Remove snap ring (1). This allows removal of complete quick coupler (13,14,15,2) and three locking clutch balls (18). 2. Tighten four hex nuts (10) until spring assembly (9 and 12) are loose in main housing (3). NOTE: Small amount of lubricant on nut and threaded stud will avoid problem of twisting studs off.
Page 113 To keep your implement running efficiently and safely, read your manual thoroughly and follow these directions and the Safety Messages in this Manual. The Table of Contents clearly identifies each section where you can easily find the information you need. The OCCUPATIONAL SAFETY AND HEALTH ACT (1928.51 Subpart C) makes these minimum safety requirements of tractor operators: REQUIRED OF THE OWNER:...
Page 114 TURFFLEX-OMWPL-08/01 P/N 00763618C Printed U.S.A.
