Front Panel Lights

During Power up, the lights will blink for several minutes.
LIGHT COLOR
Green
Power
Green or
Blue
Downstream
Green or
Blue
Upstream
Green
Online
Green
2.4 GHz
WLAN
Green
5 GHz WLAN
DESCRIPTION
MT7711 power off or
OFF:
on battery back-up
ON: MT7711 power on
OFF: On battery back-up
Green
Scanning for DS channel
Blinking:
Green ON: Connected on 1
Downstream channel
Blue Negotiating bonded
†
Blinking: channel(s)
Blue ON: Bonded with 2 or more
channels
Upstream not connected
OFF:
or on battery back-up
Green Ranging in progress
Blinking:
Green ON: Connected on 1 channel
Blue Negotiating bonded
†
Blinking: channel(s)
Blue ON: Bonded with 2 or more
channels
OFF: Offline or on battery
back-up
Blinking: Trying to go online
ON: Online
WiFi is not enabled or
OFF:
on battery back-up.
Blinking: Data is flowing.
ON: WiFi is enabled.
OFF: WiFi is not enabled or
on battery back-up.
Blinking: Data is flowing.
ON: WiFi is enabled.
17
