Summary of Contents for JBL M-Patch2
- Page 4 PASSIVE VOLUME CONTROL MONITOR SWITCH...
- Page 5 * Note: Please take into consideration your particular setup and cable arrangement when deciding on mounting your M-Patch with the highest degree of angle in relation to your desktop surface. You will need to ensure that you have enough space to connect your cables! PASSIVE VOLUME CONTROL MONITOR SWITCH * Note: The M-Patch 2 accepts mic or line level input signals.
- Page 6 * Note: You can connect up to three different devices to the three physical connector sets simultaneously. The input selector on the front panel allows selection of the desired inputs! * Note: It is possible to activate or deactivate each desired output pair using the output selector switches on the front panel.
- Page 7 * Note: All passive attenuation functions operate fully without the connection of the power supply. This enables portable use of the M-Patch 2 without restriction. * Note: If you have more than one pair of monitor speakers you could create a perfect switching facility for toggling between near- eld and lager format active room monitors.
- Page 9 * Note: Use of the headphone ampli er requires connection of the included external power supply.
- Page 10 Soundcard, CD player, MP3 Player OUTPUTS Active speakers 2 INPUTS JBL P ROF E SSIONAL NORT HRIDGE , CA. USA A HARMA N INTE RNA TIO NAL COMP A NY Active speakers 1 DAW or Mixer INPUTS OUTPUTS...
- Page 11 Input C onnectors 1 2 x C ombination X LR / 1/4-inch (6.5mm) Maximum Input Level > +26dB Input C onnectors 2 1 x stereo R C A pair (L&R ) Input C onnectors 3 1 x stereo 1/8 inch (3.5mm) jack O utput C onnectors 1 2 x XLR output pairs (1-/L&R , 2-/L&R ) O utput C onnectors...
