Arteflame Classic Cooktop Assembly Manual

Hide thumbs Also See for Classic Cooktop:

Advertisement

Quick Links

Download this manual
Cooktop, Euro and Round Base
Assembly Instructions
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Classic Cooktop and is the answer not in the manual?

Questions and answers

Related Manuals for Arteflame Classic Cooktop

Summary of Contents for Arteflame Classic Cooktop

  • Page 1 Cooktop, Euro and Round Base Assembly Instructions...
  • Page 2 Thank you for your purchase! • You are minutes away from firing up your Arteflame and begin to experience outdoor entertainment, Arteflame style.  Assembly is simple and requires two people. We will start with the Euro version instructions but the round base instructions are identical except for the base assembly.
  • Page 3 One stainless steel, notched star footing base • One CORTEN cross key • Two CORTEN legs   • One with Arteflame badge, notch facing down (approximately 45 pounds) • One without badge, notch facing up (approximately 45 pounds) • All parts have a carefully developed patina and should be handled...
  • Page 4 Arteflame Euro Base Assembly 6 quick steps for 2 persons We recommend holding all parts by their edges while wearing gloves.
  • Page 5 Euro Base Assembly • Step 1: Place the stainless steel footer where you would like your Arteflame to be. Make sure this footer is as level as possible. • Step 2: Place the first leg without the Arteflame badge, notch facing up, onto the footer so that the tabs on the legs fit into the slots of the footer.
  • Page 6 • Step 3: Have the other person place the second leg with the Arteflame badge, notch facing down, over the first leg and slide it straight down so that the two notches slide into each other.  Gently push the legs until both legs fit into the holes of...
  • Page 7 Euro Base Assembly • Step 4: Make sure the intersection of the two legs is flush and flat where they cross at the top. • Once they are flush, both legs are properly seated in the footer. • If the legs are still not flush and flat then some of the notches on the bottom are not yet properly seated in the footer. ...
  • Page 8 Euro Base Assembly • Step 5: Place the CORTEN cross key on top of the interlocking legs, ensuring it sits flat and flush with the top of the legs and can be pushed into place.
  • Page 9 Euro Base Assembly • Step 6: Place the CORTEN locking ring on top of the legs and cross assembly, making sure it sits flat and even. • Now that your Euro Base is assembled you are ready to place the heavy duty cooktop on top of the base.
  • Page 10 Round Base Assembly Round Base Assembly...
  • Page 11 Round Base Assembly • Step 1: Place the Corten Round Base where you will be using your Arteflame. • Step 2: Put it on the ground so that the bottom of the base faces up. You will now need to locate the leveling feet and screw them into the bottom of the base if they have not been preinstalled at the factory.

  • Page 12: Base Assembly

    Place the coal catcher under the base. If any grease or ambers escape the fire bowl, they will collect here for easy removal and cleaning. NOTE: Each round Arteflame base is hand formed and will not be perfectly round. This is normal and expected.
  • Page 13 Arteflame Bowl & Cooktop Assembly  3 quick steps for 2 persons...
  • Page 14 Classic Cooktop Assembly • The Arteflame Classic 40 Bowl is made up of two pieces; • The spun Arteflame CORTEN bowl (approximately 45 pounds) • The laser cut carbon steel cooktop (approximately 150 pounds) • Moving the cooktop into place requires two people and a 6’...
  • Page 15 Removing Cooktop • Step 1: Insert the cooktop lifter into the center hole of the cooktop and slide a 6-8 foot long piece of 2x4 lumber through the top as shown.  With two people, lift the cooktop and set it down near where you are going to be setting up your grill. NEVER install the cooktop by hand holding it on the outside rim as...
  • Page 16 Installing Fire Bowl • Step 2: With two people, lift the Arteflame fire bowl by the inside ring so the patina doesn’t get disturbed.  Carefully walk the fire bowl to the grilling location where the base is waiting.  Carefully place it on top of the base as level as possible.
  • Page 17 Installing Cooktop • Step 3: With two people, carefully place the cooktop on the bowl using the lifting tool.  The cooktop slightly overhangs the bowl evenly on all sides.  Always use the included lifting tool.  If the lifter can't be used, position the bowl by lifting it through the center hole ONLY.  DO NOT lift it by the outer edge as your fingers could get pinched between the bowl and the cooktop.
  • Page 18 • Your fully assembled Arteflame grill is now complete!  Make sure your Arteflame is as level as possible so all excess grease will always flow into the middle and into the fire. • You are now ready to build your fire and start the seasoning process of the cooktop.
  • Page 19 Grill Grate • If you ordered your Arteflame with a grill grate, there will be a grate lifting tool included. • The lifting tool slides in between the center slots of the grill grate.  Don’t lift the grate with food on it as it could become unbalanced.

  • Page 20: Grilling Tips


 Grilling Tips:  When using your Arteflame for the first time, it is good practice to build a fire that burns for at least an hour.  This ensures that the cooktop reaches cooking temperature.  Once it has reached cooking temperature, rub the cooktop with oil to start the seasoning process. ...
  • Page 21 Any oxidation that does form can easily be removed using steel wool and re-oiling the cooktop. The more your Arteflame is used, the better the cooktop will be protected by the oil that you use on it.  This oil will actually impregnate the cooktop and prevent oxidation.

  • Page 22: Maintenance

    MAINTENANCE
 After using your Arteflame, either extinguish the fire or supervise it until it is burned out. Water can be used to extinguish the fire but BEWARE of excessive smoke, ash and steam when using water to extinguish the Arteflame.  The Arteflame will be very hot while the fire is burning itself out and can remain hot for hours. ...
  • Page 23 It is not necessary to store your Arteflame indoors.  Your Arteflame can be left outside year round.  When left outside, make sure to clean out your Arteflame before using it.  Debris like leaves, twigs or snow can accumulate in it. After each grill use, leave a thin layer of cooking oil (preferably flaxseed oil) on the cooktop to protect the cooktop against oxidation between uses just like you would with a cast iron skillet.

This manual is also suitable for:

Euro baseRound base
