SciCan SANAO Red Dot Quick Reference Manual

SANAO Handpieces
™
Red Dot - High Speed Attachment
Up to 200,000 RPM = Gear ratio 1:5
Crown & bridge removal or preparation, caries removal,
endo access
Blue Dot - Low Speed Attachment
Up to 40,000 RPM = Gear ratio 1:1
Polishing, caries removal in dentin, endo access, endo at
torque below 1.5 Ncm
Green Dot - Very Low Speed Attachment
Up to 8,000 RPM = Gear ratio 5:1
Endo at torque of 1.5 Ncm or above
User friendly display menu
* only E-STATIS Advantage
Manufactured by:
Tel: +49 (0) 75 61 86 -0
SycoTec GmbH
E-Mail: info@sycotec.eu
Wangener Strasse 78
Internet: www.sycotec.eu
88299 Leutkirch Germany
SD-468 US EN R2_QRG TestDrive_Sanao.indd 1
- Quick Reference Guide
Customizable operative modes
Displays actual bur rotational speed
Light on/off
Presets of all common handpiece
transmissions plus two customizable presets
5 customizable endo settings*
Programmable motor torque
accommodates all rotary fi le requirements*
Distributed by:
Tel: 724-820-1600
SciCan Inc.
Toll free: 1-800-572-1211
701 Technology Dr.
Fax: 724-820-1479
Canonsburg, PA 15317 USA
uscustomerservice@scican.com
WARNING!
Risks when using handpieces with electric micro-motors.
Electric micro-motors generate signifi cantly more energy than conventional air
turbines and air motors. Due to the high torques and speeds poorly serviced,
damaged or misused handpieces may lead to overheating which could infl ict
severe burns on the patient.
Please observe the following:
• Carefully follow the maintenance instructions.
• Inspect the handpiece for external damage before each use.
• Run a test with the handpiece before each use.
Especially pay attention to unusual overheating, conspicuous noises
and vibrations.
• If a handpiece is found to be faulty, its use must be
immediately discontinued.
• Never lift cheeks or tongues with the handpiece.
IMPORTANT!
E-STATIS unit must be calibrated to the dental unit.
™
See reverse for calibration instructions.
