Configuring Port Channels
This example shows how to create a vEthernet port profile and pin it to port channel subgroup 3:
switch# configure terminal
switch(config)# port-profile type vethernet PortProfile1
switch(config-port-prof)# pinning id 3
switch(config-port-prof)# show port-profile name PortProfile1
port-profile PortProfile1
description:
type: vethernet
status: disabled
capability l3control: no
pinning control-vlan: -
pinning packet-vlan: -
system vlans: none
port-group:
max ports: 32
inherit:
config attributes:
pinning id 3
evaluated config attributes:
pinning id 3
assigned interfaces:
switch(config-port-prof)# copy running-config startup-config
This example shows how to create a vEthernet port profile and pin it to port channel subgroup 3 and backup
subgroups 4 and 6:
switch# configure terminal
switch(config)# port-profile type vethernet PortProfile1
switch(config-port-prof)# pinning id 3 backup 4 6
switch(config-port-prof)# show port-profile name PortProfile1
port-profile PortProfile1
description:
type: vethernet
status: disabled
capability l3control: no
pinning control-vlan: -
pinning packet-vlan: -
system vlans: none
port-group:
max ports: 32
inherit:
config attributes:
pinning id 3 backup 4 6
evaluated config attributes:
pinning id 3
assigned interfaces:
switch(config-port-prof)# copy running-config startup-config

Pinning a Control or Packet VLAN to a Subgroup

You can pin a control or packet VLAN to a specific subgroup.
Before You Begin
• Log in to the CLI in EXEC mode.
• Know that the existing port profile must be a system port profile.
• Know that the port profile must be an Ethernet type.
• If you are pinning a control or packet VLAN, know that it must already be in the port profile.
• If you are pinning a control VLAN, know that the control VLAN must already be one of the system
VLANs in the port profile.
