STEP - 4
Repeat step 3 for second half
STEP - 5
STEP - 6
STEP - 7
YOUR TABLE IS NOW READY FOR PLAY
SAFETY INSTRUCTIONS
Children below 14 years should not assemble the table.
This table is suitable for indoor and outdoor use.
Always cover the table when not in use
Bring both the complete halves
together, attach post (P5) with
table frame at both sides
using nut & bolt size 20×8mm
(P8) & tighten it with the help
of two spanners (P14)
Place the net (P6) into
post (P5) using bolt
size 38mm (P9)
&
tighten it with the
help of two
spanners (P14)
Washer (P12)
between (P5) & (P6)
Insert the rod (P11) through
legs-Z (P2) using a hammer.
Repeat this on all four legs
Table Tennis Table
City Concrete Outdoor
Assembly Instructions
Advertisement
Table of Contents
Related Manuals for Butterfly Table Tennis Table City Concrete Outdoor
Summary of Contents for Butterfly Table Tennis Table City Concrete Outdoor
- Page 1 STEP - 4 Repeat step 3 for second half STEP - 5 Bring both the complete halves together, attach post (P5) with Table Tennis Table table frame at both sides using nut & bolt size 20×8mm (P8) & tighten it with the help of two spanners (P14) City Concrete Outdoor Assembly Instructions...
-
Page 2: Parts List
PARTS LIST P4 & P7 P4 & P7 SIZE 9MM QTY. 16 SIZE 75×9MM QTY. 16 SIZE38MM QTY. 4 SIZE 20×8MM QTY. 8 P 12 SIZE 9×200MM QTY. 4 SIZE 9MM QTY. 4 QTY. 4 SIZE 765×730×125×50MM QTY. 4 SIZE 1205×125×50MM QTY. 2 P6 QTY.
