ADC Digivance User Manual page 26

Table 4. RIU Rotary Switch Adjustment Settings
REVERSE GAIN SETTINGS
800 MHZ 1900 MSB
GAIN MHZ SETTING
(+dB) GAIN
(+dB)
59 64
58 63
57 62
56 61
55 60
54 59
53 58
52 57
51 56
50 55
49 54
48 53
47 52
46 51
45 50
44 49
43 48
42 47
41 46
40 45
39 44
38 43
37 42
36 41
35 40
34 39
33 38
32 37
31 36
30 35
29 34
28 33
FORWARD GAIN SETTINGS
LSB 800/1900
SETTING MHZ GAIN
(+dB)
0 0 40
0 1 39
0 2 38
0 3 37
0 4 36
0 5 35
0 6 34
0 7 33
0 8 32
0 9 31
0 10 30
0 11 29
0 12 28
0 13 27
0 14 26
0 15 25
16 0 24
16 1 23
16 2 22
16 3 21
16 4 20
16 5 19
16 6 18
16 7 17
16 8 16
16 9 15
16 10 14
16 11 13
16 12 12
16 13 11
16 14 10
16 15 9
ADCP-75-114 • Issue 2C • January 2002
MSB LSB
SETTING SETTING
0 0
0 1
0 2
0 3
0 4
0 5
0 6
0 7
0 8
0 9
0 10
0 11
0 12
0 13
0 14
0 15
16 0
16 1
16 2
16 3
16 4
16 5
16 6
16 7
16 8
16 9
16 10
16 11
16 12
16 13
16 14
16 15
