Preface
Thanks for your favor in our product. This manual is helpful for you to quickly know how
to use the product. For detailed features and operations, please refer to the Feature
Book along with the product.
This manual is applicable to the following product:
PD66Xi Um Digital Portable Radio
(X may represent 2, 5, 6 or 8)
Advertisement
Table of Contents
Related Manuals for Hytera PD66Xi Um Series
Summary of Contents for Hytera PD66Xi Um Series
- Page 1 Preface Thanks for your favor in our product. This manual is helpful for you to quickly know how to use the product. For detailed features and operations, please refer to the Feature Book along with the product. This manual is applicable to the following product: PD66Xi Um Digital Portable Radio (X may represent 2, 5, 6 or 8)
- Page 2 Disclaimer Hytera Communications Corporation Limited (the Company) endeavors to achieve the accuracy and completeness of this manual, but no warranty of accuracy or reliability is given. All the specifications and designs are subject to change without notice due to continuous technology development. No part of this manual may be copied, modified, translated, or distributed in any manner without the express written permission of us.
- Page 3 American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992; ● Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999; ● International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998; ● FCC Regulations Federal Communication Commission (FCC) requires that all radio communication products should meet the requirements set forth in the above standards before they can be marketed in the U.S, and the manufacturer shall post a RF label on the product to inform users of operational instructions, so as to enhance their occupational health against exposure to RF energy.
- Page 4 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of FCC Rules. These limits are designed to provide r easonable protection residential installation. This equipment generates and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may against harmful interference in a cause harmful interference to radio communications.
- Page 5 The antenna should be kept away from the face and eyes. When worn on the body, always place the radio in a Hytera-approved holder, holster, case, or body harness or by use of the correct clip for this product. Use of n on-approved accessories may re sult in exposure levels which exceed the FCC's occupational/controlled environmental RF exposure limits.
-
Page 6: Table Of Contents
Content -----------------------------------------------------10 Group Call Items in the Package ----------------------------------------1 Product Overview --------------------------------------------2 Call on Analog Channel (No Signaling) ----------------11 Product Controls ---------------------------------------------------2 Emergency Call ----------------------------------------------------11 Programmable Keys ----------------------------------------------3 Message Service -----------------------------------------11 Before Use ------------------------------------------------------3 Troubleshooting ----------------------------------------------12 Assembling the Radio --------------------------------------------3 Care and Cleaning -------------------------------------------14 Charging the Battery ----------------------------------------------4 Optional Accessories... -
Page 7: Items In The Package
Items in the Package Please unpack carefully and check that all items listed below are received. If any item is missing or damaged, please contact your dealer. The frequency band is marked on the label of the antenna; if not, refer to the label on the radio for Note frequency band information. -
Page 8: Product Overview
Product Overview Product Controls... -
Page 9: Programmable Keys
Product Overview Before Use Programmable Keys Assembling the Radio 1. Assembling the Battery For enhanced convenience, you may request your dealer to program the SK1, , P1, P2 and P3 as shortcuts to certain functions. Please refer to the corresponding Feature Book for more details. “click ”... -
Page 10: Charging The Battery
Before Use Charging the Battery Please use the charger specified by the Company to charge the battery. 3. Assembling the Belt Clip Charging Diagram is listed below. Charging Status LED Indication The LED Indicator flashes red slowly Standby (no load) The LED Indicator glows red Charging The LED Indicator glows orange... -
Page 11: Checking The Battery Power
Before Use Status Indication LCD Icon Checking the Battery Power Name Icon Radio Status You may check the current battery power by holding down the The GPS feature is enabled, programmed Battery Power Indicator key preset by your dealer. And a n d v a l i d G P S d a t a i s release the key to exit. - Page 12 Status Indication Name Icon Radio Status Name Icon Radio Status T h e M o n i t o r f e a t u r e i s No signal. Monitor Icon enabled. RSSI Icon The radio is in emergency More bars indicate better Emergency s t a t e ( e x c e p t f o r s i l e n t...
-
Page 13: Led Indicator
Status Indication LED Indicator LE D LED Indication Product Status The LED indicator flashes green Powering on The LED indicator glows green Receiving The LED indicator glows red Transmitting The LED indicator flashes orange slowly Scanning or Roaming The LED indicator flashes orange rapidly Emergency C a l l h u n g . -
Page 14: Menu Navigation
Menu Navigation The following diagram outlines the menu structure of the radio. You can personalize menu option displayed in the radio via your dealer. To select and confirm the options shown in the menu, press the Menu key to enter the main menu, and then press the Up/Down key to select the appropriate option, finally press the OK key. -
Page 15: Basic Operations
Basic Operations Powering On/Off Selecting a Channel After the radio is powered on, you can rotate the Channel Selector Knob to select an appropriate channel. You can also switch to the designated channel by pressing the programmed Preset Channel key preset by your dealer. -
Page 16: Call Service
Call Service Contact List or Call Logs After the radio is powered on, you can make and receive calls. To ensure Step 1 Go to “Menu -> Contact -> Contact List” or “Menu -> Call Logs -> optimal volume of the receiving radio, keep the microphone about 2.5 to Outgoing/Incoming/Missed”. -
Page 17: Call On Analog Channel (No Signaling)
Call Service Message Service You can send the Quick Text or forward the message saved in the InBox, Step 3 Hold down the PTT key to initiate a Group Call. OutBox or Drafts. Receiving and Responding to a Group Call Quick Text After receiving a group call, the radio will display the icon . -
Page 18: Troubleshooting
Troubleshooting If the solutions below cannot fix your problems, or you may have some other queries, please contact us or your local dealer for more technical support. Phenomena Analysis Solution The battery may be improperly installed. Remove the battery and then reattach it. The battery power may be used up. - Page 19 Troubleshooting Phenomena Analysis Solution Irrelevant You may be interrupted by radios using the same Change the frequency, or adjust the squelch level. frequency. communication Set signaling for all member radios to avoid interference at the or noise is heard The radio may be set with no signaling. on the channel.
-
Page 20: Care And Cleaning
Care and Cleaning Product Cleaning To guarantee optimal performance as well as a long service life of the product, please follow the tips below. Product Care Turn off the product and remove the battery before cleaning. Caution l Do not pierce or scrape the product. l Keep the product far away from substances that can corrode the circuitry. - Page 21 Optional Accessories Contact your local dealer for the optional accessories used with the product. Use the accessories specified by Hytera only; otherwise, the Company will not be liable for any loss or damage arising out of the use of any...
