Vex Robotics Competition Turning Point Build Instructions page 16

Hide thumbs

Advertisement

3X
21
001
58 in
1473.2 mm
After alignment
tighten screws
Use 4x 006 for
Alignment
Align bottoms
002
47in
1193.8 mm
Assemble on flat surface
20
