Table 3: Termination Details
Type of Field Device
Network Stat with
Terminals Addressable
Network Stat with
Terminals (Fixed
Address = 199)
Maximum Cable Length versus
Load Current
Use
Figure 7
to estimate the maximum cable length
relative to the wire size and the load current (in mA) when
wiring inputs and outputs.
VMA1610 and VMA1620 Variable Air Volume Controllers Installation Instructions
Type of
Termination Diagrams
Input/Output
SA Bus
SA Bus
