Table 3: Termination Details
Type of Field Device
Voltage Input
(Self-Powered)
Dry Contact
0–10 VDC Output to
Actuator (External
Source)
0–10 VDC Output to
Actuator (Internal
Source)
Analog Output (Voltage)
24 VAC Triac Output
(Switch Low, External
Source)
VMA1610 and VMA1620 Variable Air Volume Controllers Installation Instructions
Type of
Termination Diagrams
Input/Output
UI
UI
CO or AO
CO or AO
CO or AO
CO or AO
10
