- Page 1 Quick Start Guide Wireless AC1200 Dual-Band USB Adapter GWU735 PART NO. Q1262 www.iogear.com...
- Page 2 Windows are registered trademarks of Microsoft Corporation. All other brand and product names are trademarks or registered trademarks of their respective holders. IOGEAR makes no warranty of any kind with regards to the information presented in this document. All information furnished here is for informational purposes only and is subject to change without notice.
-
Page 3: Table Of Contents
Table of Content Table of Contents Package Contents System Requirements Overview Software Installation – PC Software Installation – MAC FCC Statement CE Statement Limited Warranty Contact... -
Page 4: Package Contents
Package Contents 1 x Wireless AC1200 Dual-Band USB Adapter 1 x Quick Start Guide 1 x Driver Installation CD 1 x Warranty Card System Requirements Operating System ® ® ® ® , Windows 7, Windows 8, Windows Available USB 1.1, USB 2.0, or USB 3.0 port* *Note: For best results, connect the wireless AC1200 Dual-Band USB adapter to a USB 3.0 port. -
Page 5: Overview
Overview 1. WPS Button 2. LED Status Indicator c. Off – Wireless LAN adapter is disabled 3. USB Connector 4. Cap... -
Page 6: Software Installation - Pc
Software Installation – PC 1. Insert the driver installation CD into your CD-ROM Drive. Double-click on Setup.exe to start the installation. 2. Wizard is ready to install driver and utility. Click Next to begin installation. 3. Click Finish to restart your computer for the installation to be in effect. - Page 7 Insert the USB Adapter 1. After the computer has restarted, insert the GWU735 Wireless AC1200 Dual-Band USB Adapter into an available USB port.* *Note: For optimal performance, connect to a USB 3.0 port. the driver installation. computer. scan for an available Access Point (AP).
- Page 8 Connect to a Wireless Network 1. Double-click the wireless utility icon on your desktop to open the IOGEAR USB Wireless LAN Utility. 2. Select the Available Network tab and wait for the utility to search for available wireless networks. The available networks will be listed in the table.
- Page 9 3. Next, the Wireless Network Properties window will appear. Enter the network key, then click OK to continue. 4. Once connected, the utility will display the Signal Strength and Link Quality.
- Page 10 Before you start, make sure your wireless router provides two connection methods: Option 1: program for your wireless the WPS Client set-up option. 2. Next, select the Wi-Fi Protect Setup tab in the IOGEAR USB Wireless LAN Utility, click the Pin Input button.
- Page 11 2. Click Yes Select.
- Page 12 4. Enter the pre-generated PIN code into the Wireless AP WPS client setting. Please refer to your router’s user manual for more instructions on how to add a WPS client. The WPS client screen you see may vary depending on your router.
- Page 13 6. You have now successfully added your computer to your router’s network. Option 2: 1. Press and hold the WPS button on the side of the GWU735 adapter for 5 seconds or click button under the Wi-Fi Protect Setup tab in the utility.
- Page 14 depending on your router. The WPS client screen you see may vary depending on your router.
- Page 15 4. You have now successfully added your computer to your router’s network.
-
Page 16: Software Installation - Mac
Software Installation – MAC Note: Do not connect GWU735 Wireless AC1200 Dual-Band Adapter until prompted. 1. Insert the driver installation CD into your computer’s CD-ROM drive, open the MAC folder, then select the driver folder for your Mac OS system. Double-click Installer.pkg to begin the installation. - Page 17 3. Read the important information and click Continue to proceed. 4. Select your language and click Continue to proceed.
- Page 18 5. Click Agree to continue. 6. Click Install to start the driver and utility installation.
- Page 19 7. When prompted, click Continue Installation to proceed. 8. Once the installation is successful, click Restart to complete the installation process.
- Page 20 1. After restarting, open the Applications folder on your Mac and the IOGEAR Wireless-AC Network Utility will appear. 2. Insert GWU735 into an available USB port*, then open the IOGEAR Wireless-AC Network Utility in your Applications folder. *Note: For optimal performance, connect to a USB 3.0 port.
- Page 21 3. To connect to an available network, click the Available Network tab, select the desired network, and click Connect. 4. Next the Wireless Network Security Properties window will appear. Enter the network key, then click OK to continue.
- Page 22 5. Once successfully connected, the utitlity will display the signal strength of the network.
- Page 23 Point and select the WPS Client Setup. Then select the PIN option. 2. Next, select the WPS tab in the IOGEAR Wireless-AC Network Utility and enter the pre-generated PIN into the Client PIN The WPS client screen you see may vary depending on your router.
- Page 24 1. Press and hold the WPS Button on the side of the GWU735 adapter for 5 seconds or you can press the virtual PBC button under the WPS tab of the IOGEAR Wireless-AC Network...
- Page 25 may vary depending on your wireless router.
- Page 26 4. You have now successfully added your computer to your router’s network.
-
Page 27: Fcc Statement
Federal Communications Commission This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential setting. This product generates, uses, and can radiate radio frequency energy and, if not installed and used as directed, it may cause harmful interference to radio communications. -
Page 28: Limited Warranty
WE’RE HERE TO HELP YOU! NEED ASSISTANCE SETTING UP THIS PRODUCT? Make sure you: Warranty Information This product carries a 3 Year Limited. For the terms and conditions of Important Product Information Product Model Serial Number CE Statement IOGEAR iogear.custhelp.com support@iogear.com www.iogear.com... - Page 29 This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. R&TTE directive “Hereby, ATEN Technology, Inc., dba IOGEAR , declares that this WLAN 11ac USB Adapter,2T2Ris in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.”...
- Page 30 ® GEAR © 2014 IO...
