Wireless-G
USB 2.0 Flex Adapter
GWU513 Quick Start Guide
Read this guide thoroughly and follow the installation and operation procedures
carefully to prevent any damage to the unit and/or any of the devices it connects to.
GWU513 package contains:
1 802.11g USB Adapter
1 Quick Start Guide
1 Installation & Manual CD-ROM
1 Warranty/Registration Card
Copyright © 2003 IOGEAR
All brand names and trademarks are the registered
property of their respective owners
PKG-M0095/QS
®
®
Advertisement
Table of Contents
Related Manuals for IOGear GWU513
Summary of Contents for IOGear GWU513
- Page 1 Wireless-G USB 2.0 Flex Adapter GWU513 Quick Start Guide Read this guide thoroughly and follow the installation and operation procedures carefully to prevent any damage to the unit and/or any of the devices it connects to. GWU513 package contains: 1 802.11g USB Adapter 1 Quick Start Guide 1 Installation &...
- Page 2 Note: Your order has been carefully packaged and inspected, and we hope you are pleased with the IOGEAR Please inspect the contents of the package to ensure that you have received all items and that nothing has been damaged. If you discover a problem, please contact your dealer immediately for assistance.
- Page 3 3. Installation Wireless-G USB 2.0 Flex Adapter To have your Step. 1 Plug your Wireless-G USB 2.0 Flex Adapter into a USB 2.0 port on your PC. Step. 2 Your system will detect the device, and the Found New Hardware Wizard dialog box will appear. Choose Cancel to proceed.
- Page 4 Step. 5 Click Next in the WLAN 802.11G USB window to proceed. The system will start to copy the drivers found. Step. 6 Windows will notify you that the driver has not passed the Windows Logo testing. Because the USB adapter has been tested to work with Windows XP, please choose Continue Anyway in the Hardware Installation dialog box.
- Page 5 Step. 8 After rebooting, you will find the Wireless-G Configuration Tool tray icon, appeared in the system tray. Note that different colors of the tray icon reveal different status of the Internet connection. Check the table below to learn more: ICON The installation is entirely finished at the moment.
- Page 6 Step. 4 From the opened dialog box, on the General tab, find the descriptions under the Device Status pane to learn if the module is working properly. However, if there’s an error message shown, please choose Uninstall from the opened menu while right-clicking over the USB Adapter item, to which a red or yellow icon is attached beside, in the Device Manager dialog box.
- Page 7 The Wireless-G Configuration Tool Tray Icon a) Right-click the Network Connections icon at the task bar to open the Wireless Network Connection Status dialog box, and then select Properties. The Wireless Network Connection Status Dialog Box b) Choose the Wireless Networks tab in the Wireless Network Connection Properties dialog box, and remove the check from the Use Windows to configure my wireless network settings checkbox.
- Page 8 6. Radio and TV Interference This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
