- Page 1 1U 19” Rackmount LCD Console | USB Actual product may vary from photos User Manual SKU#: RKCONS1901 For the latest information and specifications visit www.startech.com/RKCONS1901 Manual Revision: 12/10/2018...
-
Page 2: Compliance Statements
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 3 This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual...
-
Page 4: Safety Statements
• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o pericoli per la sicurezza. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 5: Warning Statements
• Make sure to assemble this product according to the instructions. Failure to do so might result in personal injury or property damage. • Never use this product if parts are missing or damaged. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 6: Table Of Contents
LCD Console Panel Menu ........................14 Auto Tuning the Display ......................... 14 Adjusting the Display’s Brightness ..................... 15 Adjusting the Display’s Contrast ......................16 Adjusting the Display’s Color Settings ....................16 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 7 Resetting the LCD Console to Factory Settings................18 Exiting the OSD ............................18 LED Indicator ..................19 Configuration ..................19 Testing the LCD Console ......................... 19 Configuring Display Settings ........................ 20 Specifications ..................20 Important Considerations ..............21 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 8: Product Diagram (Rkcons1901)
Product Diagram (RKCONS1901) Front Release Handle Switch Display Console Panel Rails (2) Keyboard Mounting Brackets Touchpad To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 9: Rear
Rear Power Connection Port Power Host Switch Port Ground Connection Screw To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 10: Product Information
Requirements are subject to change. For the latest requirements, please visit www.startech.com/RKCONS1901. 1U of Rack Space • Grounding Wire • Power Source • Computer, Server, or KVM • Phillips Head Screwdriver • To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 11: Installation
Insert an M5 Screw (two per mounting post) through the Front Mounting Bracket (rail) into the M5 Cage Nut. Use a Phillips Head Screwdriver to tighten the M5 Screws. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 12: Grounding The Lcd Console
Connect the Power Cable to the Power Connection Port on the LCD Console and to an AC Electrical Outlet. Power on the LCD Console. Power the Computer or KVM back on. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 13: Opening The Lcd Console
Release the two Switches and continue pushing the LCD Console the rest of the way into the Rack, until you hear an audible click. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 14: Panel Controls And On-Screen Display (Osd) Functions
The Auto button automatically adjusts the display size and tunes the Display to its optimal state. On the Console Panel, press the Auto/Exit button. - or - On the Console Panel, press the Menu/Select button. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 15: Adjusting The Display's Brightness
Select button. Use the SL- down and SL+ up (on the Console Panel) buttons to adjust the brightness on the display. Press the Menu/Select button to save your selection. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 16: Adjusting The Display's Contrast
7500°K: Sets CIE coordinates at 7500°K color. • 6500°K: Sets CIE coordinates at 6500°K color. • User: Sets user defined CIE. • Auto Color: Auto adjusts color. • To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 17: Adjusting The Image Or Osd Position
On the OSD, use the SL- down and SL+ up on the Control Panel to highlight Menu, then press the Menu/Select button. On the Menu list select Language, then press the Menu/ Select button on the Console Panel. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 18: Resetting The Lcd Console To Factory Settings
Yes: Reset. • No: Returns to the OSD Menu without resetting. • Exiting the OSD To exit the menu, scroll to Exit, then press the Menu/Select • button. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 19: Led Indicator
Auto button on the Console Panel. Note: If the unit does not power up when the Display is pulled up, try pushing the Power button on the Console Panel. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 20: Configuring Display Settings
Response Time Rising Time: 8ms Decay Time: 8ms System Cables VGA + USB Keyboard 99-key Mouse Touchpad Sync 50 - 75KHz Power Source 100 - 240 VAC Input To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 21: Important Considerations
Appropriate consideration of equipment nameplate ratings should be used when addressing this concern. The LCD Console should be grounded appropriately during • installation. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 22 Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
