Summary of Contents for Apache Manitou MX
- Page 1 APACHE EBIKE USER MANUAL 2018...
- Page 2 Immediately after the purchase check that you have received together with your eBike all accessories listed here. Charger, battery lock keys and tools (spanner 18/15 and allen wrench key) are included in to each Apache eBike.
- Page 3 Nevertheless we do recommend using the cycling helmet to all E-bike users without difference. Technical specification of Apache eBike: Nominal motor performance 250W Voltage of electric system 36 V Operating temperature 0 / +40 °C...
- Page 4 GENERAL INFORMATION FOR USE OF eBIKE IMPORTANT Before every ride check the brakes functionality and battery charge status. During the ride on eBike always use cycling helmet! Riding an eBike Riding eBike is just like on any other bike. Just push and set off from the ground and pedal. The motor activates itself after the crank spinning and operates further according to mode of assistance setted up.
-
Page 5: Switching On/Off
CODAC - EBIKE CONTROL (Hawk E3/E5, Manitou E3/E5, Yamka E3/E5, Matto E3/E5, Matto E3/E5 Lady, Tate 24”, Tate 27.5”, Gaagii, Gaagii Lady, Wakita Tour, Wakita City, Wakita Grace, Wakan City) power scale lights assistance level battery status speed units speed USB port km/h error code... -
Page 6: Parameters Settings
– assistance setting – for each assistance level you can set up your own value in % from the maximum performance 250 W (this function is available only by models with Apache Power Silent Plus motor– Hawk E3, Manitou E3, Yamka E3, Matto E3) Sd –... - Page 7 TFT COLOUR - EBIKE CONTROL (Hawk MX, Manitou MX, Yamka MX, Matto MX, Matto MX Lady, Wakita Tour MX, Wakan Tour MX, Wakita Grace MX, Wakan Grand MX) time battery status 13:14 USB charging voltage indicator / battery status in %...
-
Page 8: Parameters Setting
Change of riding data display Displayed informations are changed by short pressing of button . Informations are displayed in the sequence below: TRIP RANGE CALORIES TIME Trip Total Maximum Average Remaining Energy Total distance distance speed speed distance output travel time *energy output is defined in kilocalories (kCal) Switching on and off the display background light To switch the display background light on or off press the button... -
Page 9: Error Codes
Error codes Code Problem cause Protection from battery overvoltage (check the battery voltage). Error of motor hall sensor (check the settings and connections with the motor). Error of motor phase cable (check the settings and connections with the motor). Error of unit control temperature sensor (check the settings and connections with the control unit). Error of torque moment sensor (check the settings and connections with the motor). - Page 10 Assistance level setting To change the assistance level in the range 0-5 shortly press button . The highest assistance level is 5, level 0 is without the motor assistance. In case of riding at low revolutions and high assistance mode the motor can vibrate for a brief moment.
-
Page 11: Battery Status Indicator
- EBIKE CONTROL (Wakita Prime, Tanka, Tanka Nexus, Tocho, Tocho Nexus, Dakotah, Dakotah Nexus) lights assistance level ON/OFF battery status Switching on - off Switch on the electric system supply to the battery Tanka, Tocho, Wakita Prime – witch on the battery using the switch in the upper part of the battery Dakotah –... - Page 12 Prior any handling with the battery always switch it off first. Frame battery (Hawk MX, Manitou MX, Yamka MX, Matto MX, Matto MX Lady, Hawk E3/E5, Manitou E3/E5, Yamka E3/E5, Matto E3/E5, Matto E3/E5 Lady, Tate 24”, Tate 27.5”, Matto E7, Matto E7 Lady)
-
Page 13: Power Switch
Seat tube battery (Wakita Tour MX, Wakan Tour MX, Wakita Grace MX, Wakan Grand MX, Wakita Grace, Gaagii, Gaagii Lady, Wakita Tour, Wakita City, Wakita Prime, Wakan City, Tanka, Tanka Nexus, Tocho, Tocho Nexus) Switching on: Switch on the battery using the switch in the upper part of the battery. Handling: To remove the battery eject the saddle tube with the saddle from the frame. -
Page 14: Battery Charging
BATTERY CHARGING RECOMMENDATION Battery is ready for immediate use. To achieve maximum capacity we recommend however apply 3 full charging cycles at the beginning of the use. That means to discharge the battery by riding completely followed by full recharge at room temperature. Thereafter charge the battery any time without full discharging need. -
Page 15: Battery Storage
FACTORS AFFECTING THE EBIKE´S TRAVEL DISTANCE The riding distance of the eBike is affected by many various factors and therefore it is very difficult to define the number of kilometres on one charge. The key factors include: • the route profile (flat terrain vs. long sharp elevations) •... - Page 16 ASSEMBLY AND SETTING UP EBIKE Assembly and disassembly front or rear wheel with motor Due to the need of transport or service there may be a situation that you might need to dismantle front or rear wheel with motor. At first disconnect the motor connector that is approximately 20 cm away from the motor axle.
- Page 17 Service of Apache eBikes In case of any technical problems with Apache eBike contact your dealer or any authorised partner of Apache. Complaints about the eBike or battery shall be raised always to your dealer where you bought the eBike.
-
Page 18: Warranty Terms
EBIKE WARRANTY Warranty inspection In order to ensure complete function of the eBike it is recommended to perform the warranty inspection. It should be performed commonly after 100 to 150 km of ride. During the inspection there is going to be checked the fastening of all joints, brakes and gears setting and naturally the electric system itself. -
Page 19: Declaration Of Conformity
Type of product marking: Hawk MX, Manitou MX, Yamka MX, Matto MX, Matto MX Lady, Hawk E3/E5, Manitou E3/E5, Yamka E3/E5, Matto E3/E5, Matto E3/E5 Lady, Tate 24”, Tate 27.5”, Matto E7, Matto E7 Lady, Wakita Tour MX, Wakan Tour MX,... - Page 20 V1 04/2018 EN www.apache-bike.cz...
