- Page 1 Digital Remote Wheels DRW-1 USER MANUAL Date 01.12.2018 ...
- Page 2 In no event shall ARRI or its subsidiaries be liable for or have a remedy for recovery of any special, direct, indirect, incidental, or consequential damages, including, but not limited to lost profits, lost savings, lost revenues or economic loss of any kind or for any claim by a third party, downtime, ...
-
Page 3: Table Of Contents
Table of contents 1 For your safety…………………………………………………………………………… 2 Functions………………………………………………………………………………….. 3 Assembling the DRW-1………………………………………………………………….. 4 LBUS………………………………………………………………………………………. 5 Selecting the axes ………………………………………………………………………. 6 Brake………………………………………………………………………………………. ... -
Page 4: For Your Safety
ARRI recommends that all users of the DRW-1 and SRH-3 system read the manual in its entirety prior to use. All directions are given from a camera operator's point of view. For example, camera-right side refers to the right side of the camera when standing behind the camera and operating it in a normal fashion. -
Page 5: Functions
3/8“ Thread Wheel Carrier Clamp Lever Mounting Bracket 3/8“ Thread DRW-1 Mounting Base Cover Screws Wheel Carrier SRH Remote Mounting Bracket Swivelling Rods ... -
Page 6: Assembling The Drw-1
Assembling the DRW-1 Mounting the DRW-1 base The bottom of the DRW-1 mounting base offers multiple mounting options: 3/8” threads for long camera dovetail plates, like the O’Connor plate code 08283, Euro style quick release plate code 2575-120, or the Sachtler sideload plate M code1164. - Page 7 The bottom of the SRH-3 remote control panel offers four M6 threads. Open the clamp lever of the remote mounting bracket, remove the bracket from the rods of the DRW-1 mounting base. Place the DRW-1 SRH remote mounting bracket to the bottom of the SRH-3 remote control panel.
-
Page 8: Lbus
Every DRW-1 module is equipped with two LBUS connectors and daisy chain technology. Up to three DRW-1 modules can be linked up in a row. Each DRW-1 module has two identical, bi-directional LBUS interfaces providing power and control signals to the DRW-1 module. -
Page 9: Selecting The Axes
Now engage the wheel again and move the head backwards to the starting point. Start the movement from the beginning. Fluid Drag Ring (friction) The DRW-1 wheels are equipped with a fluid drag ring, Softer which allows friction to be adjusted. ... -
Page 10: Remote Control Setup
Remote control setup 8.1 Assigning the wheels NOTE The DRW-1 wheels must be assigned to the corresponding axes of the remote head. For a fast selection, the home screen of the SRH remote control offers a ... - Page 11 Speed to Angle. Press Save after the mode is selected. 8.4 Additional adjustments To ensure that the DRW-1 wheels react promptly and precisely, the following the following adjustments needs to be considered: Ratio Sensitivity Deadband Ramp ...
- Page 12 Remote Control Setup 8.6 Sensitivity Selecting Position will open the controls position sub-menu. Touch Sensitivity: this selection will open a new touchscreen slider that allows you to change the sensitivity of the control device for the selected axis.
-
Page 13: Power Disconnection
Remote Control Setup 8.8 Speed In the factory preset setup, the Speed is assigned to the knobs K1, K2 and K3. Changing the speed value will also change the turns required to do a 180° Pan. ... -
Page 14: Technical Data
Contains: 2 x DRW-1 Module ……………………………………………….. K2.0019319 2 x Hand Wheel complete.………………………………………..150 N2.25004.A 1 x DRW-1 Mounting Base ………………………………………. K2.0019325 1 x Cable LBUS 0.3m/1ft ………………………………………… K2.0006750 1 x Cable LBUS 0.5m/1.5ft ……… ……………………………… K2.0006751 1 x DRW-1 Foam Set………………………………………………90.0020791 4 x M6x12 stainless hex screws………………………………….
