- Page 1 External Radio Modules for SRH ERM-2400 / ERM-900 SUP2.3 USER MANUAL Date 20.03.2020...
- Page 2 In no event shall ARRI or its subsidiaries be liable for or have a remedy for recovery of any special, direct, indirect, incidental, or consequential damages, including, but not limited to lost profits, lost...
-
Page 3: Table Of Contents
Table of Contents Table of contents 1 For your safety………………………………………………………………………….. 2 Functions .………………………………………………………………………………. 3 Introduction …………………………………………………………………………… 3.1 How It Works …………………………………………………………………………… 4 Powering the remote control panel (RCP) ………………………………………….. 5 Connecting the ERM ……………………………………………………..…………… 5.1 Connecting the ERM to the remote control panel (RCP) ………………………….. 5.2 Connecting the ERM to the remote head ……………………………………………... -
Page 4: For Your Safety
This product is NOT intended for inexperienced users and should not be used without reading the manual or additional training. ARRI recommends that all users read the manual in its entirety prior to use. How to use this manual All directions are given from a camera operator's point of view. For example, camera-right side refers to the right side of the camera when standing behind the camera and operating it in a normal fashion. -
Page 5: Functions
Functions Functions Functions front view Rubber Duck Antenna Signal Strength Display RXD / TXD Status FS CAN Bus Power In LEMO 0B 2pin USB Port Functions back view 1/4“ thread 3/8“ thread / RMB-2 mounting thread RMB-2 / RMB-3 mounting threads M4 thread ERM for SRH SUP2.3... -
Page 6: Introduction
The ERM modules are already paired with each other. The modules can be used both as transmitters and receivers. Avoid mixing individual modules with other paired ERMs. ERM-2400 for LCS and ERM-2400 for SRH are NOT compatible with one another. Powering the remote control panel (RCP) Ensure that the SRH remote control panel is powered with 12V. -
Page 7: Connecting The Erm To The Remote Head
Positioning Connect the second ERM to the remote head Connect the FS CAN Bus Cable to the remote head and then to the ERM. SRH FS CAN Bus Cable, 1m/3.2ft K2.0033762 Positioning the ERMs CAUTION To exclude any health risk, the minimum distance between the ERM transmitter and the operator must be at least 1 m. -
Page 8: Pairing The Erms
ERM Reconnect the first ERM one more time. Disconnect the first ERM Now the first ERM had been detected and connected. In this case the ERM-2400. When ready, detach the first ERM. Connect the second ERM Connect the second ERM. -
Page 9: Appendix
Frequency Hopping, DTS V OUT ERM-900 Specifications Electrical/General Supported Frequency 902 - 928 MHz Spreading Method Frequency Hopping, DTS Dimensions without antenna ERM-2400 / ERM-900 Length 11 cm / 4.33“ Width 9 cm / 3,54“ Hight 4 cm / 1,57“... - Page 10 Appendix Dimensional Drawings ERM for SRH SUP2.3...
- Page 11 Declarations of Conformity Approval Information The products offered by ARRI are approved for use in a number of countries. Product- specific information on approval can be found in the respective operating instruction manuals. Import and use in countries other than those mentioned in the respective operating instructions may be subject to legal, regulatory, or official requirements and regulations.
- Page 12 Appendix Declaration of Conformity Product Type External Radiomodule Brand Name FoMaSystems Product Name FoMaSystems ERM-P2400 Address FoMa Systems GmbH Oskar-Sembach-Ring 11 D-91207 Lauf The product complies which the requirements of the following European directives: DIRECTIVE 2014/53/EU OF THE EUROPEAN PARLIAMENT AND OF 2014/53/EU THE COUNCIL on the harmonisation of the laws of the Member States relating to the making available on the market of radio equipment and...
- Page 13 FCC Statement / IC Statement ERM-2400 contains: FCCID: NS9P2400 ERM-900 contains: FCCID: NSN920X2 The ERM-2400 will be shipped with readjusted 0.1Watt transmission power to be complaint in all addressed markets. NOTICE For USA and Canada the transmission power can be changed locally by the ARRI service to 1Watt transmission power.
