20 Ton Electric Log Splitter
User Manual
[Revision 6.0 April 2018]
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY
DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by
this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
E&OE
©2018 Bäumr-AG
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Baumr-AG HPS4500E
Summary of Contents for Baumr-AG HPS4500E
- Page 1 20 Ton Electric Log Splitter User Manual [Revision 6.0 April 2018] READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
-
Page 2: Safety
20 Ton Electric Log Splitter Safety Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or equipment or property damage if not understood or followed. Safety messages have the following symbols: You WILL be KILLED or You CAN be KILLED or You CAN be INJURED if you SERIOUSLY INJURED if you... - Page 3 20 Ton Electric Log Splitter General Electrical Safety General Electrical Safety General Service Information • Inspect electrical equipment, extension • Electrically grounded equipment must • The equipment must be serviced or cords, power bars, and electrical fittings have an approved cord and plug and be repaired at authorised service centres for damage or wear before each use.
-
Page 4: Safety Symbols
20 Ton Electric Log Splitter Safety Symbols The product may have safety warning labels attached to it, explained below. Understand the symbols on your product and their meanings. If any stickers become unreadable, unattached etc, replace them. Flammable Material Hazard Read User Manual Use Hand Protection Carbon-Monoxide Hazard... - Page 5 20 Ton Electric Log Splitter Carbon-Monoxide Hazard Pull Hazard Slope / Fall Injury Hazard "Slam Dunk" Warning Do not use the product in Be aware that the product Be aware that using the Do NOT attempt "slam dunk" confined areas or without contains or uses mechanical product on sloping surfaces or maneouvres as this may result...
-
Page 6: Equipment Safety
20 Ton Electric Log Splitter Equipment Safety Log splitting machines produce high hydraulic pressures and have exposed parts that can cause serious injury if not used correctly or without taking proper safety precautions. It is extremely important that you read and fully understand the information in this section and all other safety warnings / recommendations and usage instructions before using the equipment. - Page 7 20 Ton Electric Log Splitter Transportation Safety • Always STOP the machine before transporting or working on it (adjusting etc). • Do not carry passengers, or allow any person to sit or stand on the machine. • Always fully secure the machine to the towing vehicle hitch before towing. •...
-
Page 8: Table Of Contents
20 Ton Electric Log Splitter Table of Contents Safety ..............................2 Safety Symbols ............................4 Equipment Safety ..........................6 Controls and Features Identification ....................9 Before Use Checklist ........................10 Assembly ..............................10 Hydraulic Oil ............................. 14 Log Splitter Operation ........................15 Splitting Logs ............................ -
Page 9: Controls And Features Identification
20 Ton Electric Log Splitter Controls and Features Identification Name Name Main Machine Frame Motor Control Lever Splitting Wedge Hydraulic Ram Log Cradle Control Valve Support Leg and Tow Hitch Oil Pump Handle Wheel E&OE ©2018 Bäumr-AG... -
Page 10: Before Use Checklist
20 Ton Electric Log Splitter Before Use Checklist Ensure that you carry out all procedures below before operating the equipment. All procedures described are generic in nature and slight variations between different models may exist. Failure to follow the checklist and carry out the procedures correctly may result in making the product warranty void. - Page 11 20 Ton Electric Log Splitter 5. Remove the split pin (40), M16 castellated nut (63) and M16 washer (64) from the axle on either end of the axle assembly (38). Then, slide each wheel (39) onto the axle. Place a M16 washer onto the axle, then the M16 castellated nut.
- Page 12 20 Ton Electric Log Splitter 9. Remove the 4 M8x35 bolts (65), washers (23), spring washers (22) and nuts (19) from the motor mounting plate on the axle assembly (38). Attach the motor (47) to the plate (ensure that the pump is facing toward the rear of the machine) using the previously removed fasteners.
- Page 13 20 Ton Electric Log Splitter 11. Attach the ON/OFF switch assembly (48) to the left side of the machine frame using 2 M6x12 bolts (55), spring washers (32) and washers (33). 12. Connect the oil pump outlet hose (26) to the oil pump (58) at connector (60) and to the control valve (motor side of the machine).
-
Page 14: Hydraulic Oil
20 Ton Electric Log Splitter 15. Attach the log cradles (11) to each side of the main machine frame (1) using 4 M10x25 bolts (49) and nuts (17). Hydraulic Oil The hydraulic system requires adequate hydraulic oil of the correct type to operate safely and efficiently. The machine is shipped without hydraulic oil although some oil may be supplied. -
Page 15: Log Splitter Operation
20 Ton Electric Log Splitter Log Splitter Operation The machine must be operated by one person only. Do not allow helpers or bystanders within 30m (90') of the machine. Bystanders should wear eye protection. • Make sure there are no nails or foreign objects in logs to be split. • Log ends must be cut square. • Branches must be cut off flush with the trunk. -
Page 16: Splitting Logs
20 Ton Electric Log Splitter Splitting Logs 1. Place the log on the slide/work table (A), with one end up against the non-moving part – that is, log stop (1). 2. Operate the hydraulic ram using the ram control lever (2). Move the lever in the direction of the log stop and hold it there for the hydraulic ram/wedge to push the forward. -
Page 17: Towing
20 Ton Electric Log Splitter Towing Before towing, ensure the axle nuts are tight and the axle nut split pins and securely in place. • Ensure that the tyres are inflated to the pressure marked on the tyre wall. • Do not tow if the tyres are worn, damaged or do not hold air pressure. -
Page 18: Maintenance
20 Ton Electric Log Splitter Maintenance Switch the machine OFF and disconnect it from the electrical supply during inspection and maintenance unless specifically required. • Some maintenance activities may be beyond the scope of some users. Do NOT attempt procedures that you are not comfortable with, or do not have the necessary tools, experience or knowledge for –... -
Page 19: Transportation And Storage
20 Ton Electric Log Splitter To change the hydraulic oil: 1. Place the machine on a suitable surface that is flat and level and have a container ready to catch drained oil. 2. Remove (rotate left) the drain plug (A) on the underside of the oil reservoir (main machine frame) and allow oil to drain from the tank. -
Page 20: Troubleshooting
20 Ton Electric Log Splitter Troubleshooting Switch the machine OFF and disconnect it from the electrical supply during inspection and maintenance unless specifically required. • Some maintenance activities may be beyond the scope of some users. Do NOT attempt procedures that you are not comfortable with, or do not have the necessary tools, experience or knowledge for –... -
Page 21: Specifications
20 Ton Electric Log Splitter Wood not splitting or splitting very slowly. Possible Fault Action Engine speed too slow Increase engine speed. Lack of hydraulic oil Check oil level and ensure that the level is at the recommended level. Air bubbles in hydraulic oil Allow oil to "settle"... - Page 22 20 Ton Electric Log Splitter Some experts believe the incorrect or prolonged use of almost any product could cause serious injury or death. For information that may reduce your risk of serious injury or death, consult the points below and additionally, the information available at www.datastreamserver.com/safety •...
