Exposure 3010S Quick Start Manual

high fidelity engineering
since 1974
CD Player
Quick Start Manual
Thank you for purchasing the Exposure 3010S CD Player.
Before you start
Please check the contents in the box:
HS-101 Exposure System
Exposure 3010S
CD Player remote control
Mains cable 2 x AAA batteries
Ensure your unit is switched off.
Please note that your Exposure 3010S CD Player
may take up to 48 hours to "run-in" before reaching
its optimal performance. Each subsequent "run-in"
will then take about 20 minutes.
1
Installation
a) Connect the mains cable to
the IEC mains input socket.
2
Amplifier Connection
The Exposure 3010S CD Player is fitted with both analogue and digital audio outputs.
Please use your own preferred cables.
The Exposure 3010S CD Player : Back View
Analogue Output
• Connect RCA Phono sockets to appropriate line input
on the amplifier.
• Make sure right and left channels are properly connected.
(Right channel is marked in red)
3
Operation
Ensure that the volume control knob on your amplifier is set to minimum.
The Exposure 3010S CD Player : Front View
The LED power indicator will light up.
Press power switch.
b) Connect to the mains outlet on the wall.
DO NOT switch on until all input and output
connections are made.
Digital Output
Connect the digital outputs either to:
• An external digital to analogue converter.
or
• A digital device such as a CDR machine or
minidisc recorder.
(For hints on improving sound quality, please refer to "Extended Set-Up"
overleaf).
The display will illuminate.
4
Function Controls
Open Opens and closes the CD loading drawer.
Stop Stops disc playback.
Play/Pause Starts disc playback.
Pressing Play/Pause while a disc is playing will pause playback.
Pressing Play/Pause again will resume playback.
|<<
Selects the previous track in sequence.
>>| Selects the next track in sequence.
Display Press once to turn display off. The display will stay off until
another button is pressed, and it will then go off again after
a short delay. Press Display again to turn it back on.
5
Remote Control
Press the black CD button on the remote control before using the grey
function buttons.
1~9,10+ Direct access track functions
Display Press once to turn display off. The
display will stay off until another
button is pressed, and it will then
go off again after a short delay.
Press again to turn it back on.
PROG Programmable track selection.
RANDOM Random track selection.
TIME Track time countdown.
RPT Track/disc repeat.
PREV Selects the previous track in
sequence.
NEXT Selects the next track in
sequence.
<SEARCH> Press and hold < for Backward
Scan. Press and hold > for Forward
Scan.
Open Opens and closes the CD loading
drawer.
Stop Stops disc playback.
Play Starts disc playback.
Pause Pauses playback.To resume play,
press again or press the "Play"
button.
