TRANSMISSION COVER LATCH
STEP 5
SCREW BOLT INTO END OF SHAFT
R8343 LATCH ASSEMBLY DETAIL
STEP 4
SLIDE SPRING & SHOULDER
WASHERS ONTO BOLT
STEP 3
FIT HOOK ASSEMBLY
OVER SQUARE END OF SHAFT
NOTE
RAISED LUG MUST BE
LOCATED IN RECESS OF BODY
STEP1
FIT BODY & NUT TO COVER
STEP2
FIT WAVE WASHER
AND SHAFT INTO BODY
