MAINTENANCE
•
Lubricate rod ends
Service of smoothing roller bearings
•
Whilst the Roller is suspended by the Trailer, check
operational smoothness of the bearings fi tted to each
smoothing roller by rotating the rollers by hand. If
bearing tightness, roughness or excessive looseness is
detected, replace the faulty bearings.
•
If bearings are faulty
(a) Remove the complete smoothing head from the
machine, undo the four bearing mount bolts on
upper body and steering rod, wheel the roller away
until the total head is exposed to work on.
(b) Remove roller shaft bolts from end of the head,
remove rollers from the heads.
(c) Fit new bearings, replace rollers into the heads,
lubricate shaft bolts with an anti seize compound
before installing them. Tighten securely and ensure
rollers rotate freely when fully tightened.
(d) If the steering rod is removed or the length is
altered ensure it is correctly adjusted so that the
head is parallel to the body when in the straight
ahead position and the joystick is aligned with the
centre of the seat. Adjust if necessary.
Engine oil (Honda)
•
Check engine oil level prior to daily operation. Top up
as required.
•
Change oil per manufacturers (Honda) handbook
recommended schedule.
•
Use only manufacturers (Honda) handbook
recommended oils.
•
Refer to service chart on this page for additional
information.
11
Changing transmission oil
Ongoing Maintenance, Lubricant and Replacement
Schedule (below)
Note. Areas indicated with an aterix ( * ) need to be
changed when defective or as required. This may be
before the recommended replacement schedule. Please
replace all parts as necessary.
Description
Check Engine oil
Check Transmission Oil Level
Beware of contaminants entering the transmission
Lubricate drive chain with WD40 or equivalent
Check Tires Max 18 P.S.I.
Check Gas
Check Smoothing Roller Bearing
Check Drive Roller Bearings
Check for loose Nuts and Bolts
Renew Engine Oil
Renew Transmission Oil - See page 1 for correct oil
Renew Transmission Oil Filter
Renew Smoothing Roller Bearings
Renew Drive Roller Bearings
Renew Chain Tensioner Sprocket Bearings
Renew Drive Chain
Replace Foot Pedal Struts
Replace Trailer Strut
We use and recommend Penrite Synthetic 5 SAE
5W-60. Available through our dealer network.
Adjusting The Park Brake
If the park brake is slipping, increase the
tension of the cable by rotating the knob on
the end of the lever in a clockwise direction.
TRU-TURF GR11000D Golf Greens Roller Manual
Pre-Delivery
Pre-Operating
12 Monthly
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
as per manufacturers Handbook
√
every 500hrs or...
*
√
*
√
*
√
*
√
*
√
*
*
