- Page 1 INSTALLATION MANUAL Mid-Drive Electric Bicycle Kit EVBIKE-SET-CMS EVBIKE-SET-CMS-48 EVBIKE-SET-CMS-68 EVBIKE-SET-CMS-100...
- Page 2 Thank you for purchasing EVBIKE product and we hope that you will become a happy user. Carefully read the entire manual prior to installation and first use! If you find any fact in the manual that would prevent you from using our product, please contact your reseller for further discussion and keep the original packaging.
-
Page 3: Table Of Contents
2. Installation of LCD display, left brake, accelerator and wheel speed sensor 3. Battery installation 4. Diagnostic of malfunctions and service 5. Usage 6. Maintenance SPECIFICATIONS EVBIKE-SET-CMS-48 EVBIKE-SET-CMS Motor power: 750 W 250 W Motor torque: nominal 70, peak 100 Nm... - Page 4 Fixing plate Motor unit Accelerator 2x Brake lever Main wiring harness eVBiKe, or sUccesfUl assemBlY of YoU Will also Need folloWiNg — ribbons for cables fastening — screws, nuts, washers — special bott om bracket tools (see pictures a, b, c) —...
- Page 5 Axle of the motor must go slip freely. Chainwheel will be on the right side Insert motor into (the driving direction) the hole for bottom bracket cartridge. www.EVBIKE.cz Importer: GWL Power a.s., EU-VAT ID: CZ25948253...
- Page 6 The surface with teeth of fixing plate towards inside, then fix the plate on drive unit with 2pcs M6 Nuts. Fixing plate with teeth. 2x M6 Nut. Teeth of the fixing plate must face towards the bicycle frame! www.EVBIKE.cz Importer: GWL Power a.s., EU-VAT ID: CZ25948253...
- Page 7 In the case of using a frame for the bottom bracket of width 73 mm (105 mm), is possible to install only one M33 nut. Is recommended to secure nut with a special glue for screws (not included in package). www.EVBIKE.cz Importer: GWL Power a.s., EU-VAT ID: CZ25948253...
- Page 8 Now place the left and right crank (watch the label L and R) and tighten M8 nuts with reasonable force after 50-100 km check the nuts. After tightening, install pedals (watch out for right and left-hand thread). M8 Nut. Left Crank. Right Crank. M8 Nut. www.EVBIKE.cz Importer: GWL Power a.s., EU-VAT ID: CZ25948253...
- Page 9 Check, that the distance is 5 mm. If the sensor and magnet are installed correctly, when rotating the LED on the sensor is activated and flashes when passing through the magnet. www.EVBIKE.cz Importer: GWL Power a.s., EU-VAT ID: CZ25948253...
- Page 10 Fasten or underlay and make sure, that distance between the magnet and the sensor is not greater than 5 mm. Connect sensor connector with output from the motor unit. www.EVBIKE.cz Importer: GWL Power a.s., EU-VAT ID: CZ25948253...
-
Page 11: Battery Installation
(Installation is done instead of the brake lever via distributor.) BATTERY INSTALLATION EVBIKE kit can be powered by your own battery of voltage 36 V or 48 V. For proper functionality and seamless installation we recommend using certified EVBIKE batteries. When you install your own batteries always make sure that the correct polarity of the connected battery and provide battery output with the connector that is compatible with the connector of the motor unit. -
Page 12: Usage
Do not concentrate on meter while riding. Safety first! CAUTION NEVER MANIPULATE THE CHAIN AND CHAINSET IF BATTERY IS CONNECTED. RISK OF SERIOUSLY INJURY! BEFORE HANDLING TURN OFF LCD DISPLAY, DISCONNECT BATTERY AND REMOVE IT OUT OF THE HOLDER. www.EVBIKE.cz Importer: GWL Power a.s., EU-VAT ID: CZ25948253... -
Page 13: Maintenance
118/2016 Coll., as well as the device conforms to basic requirements and any other relevant provisions of Decree-Law No 176/2008 Coll., establishing technical requirements for machinery (MACHINERY DIRECTIVE 2006/42/EC, 2009/127/EC). This statement is issued on the basis of documents presented by the producer. www.EVBIKE.cz Importer: GWL Power a.s., EU-VAT ID: CZ25948253... - Page 14 Importer: GWL Power a.s., EU-VAT ID: CZ25948253...
