- Page 1 INSTALLATION MANUAL Wheel Drive Electric Bicycle Kit EVBIKE-SET-26F EVBIKE-SET-26R EVBIKE-SET-28F...
- Page 2 Thank you for purchasing EVBIKE product and we hope that you will become a happy user. Carefully read the entire manual prior to installation and first use! If you find any fact in the manual that would prevent you from using our product, please contact your reseller for further discussion and keep the original packaging.
-
Page 3: Table Of Contents
Rim material: Alluminium alloy 6061, (double wall) * Total bicycle load up to 120 kg must not be exceeded (includes the weight of the rider, bike and EVBIKE set). Importer: PHOYLO LTD, CZ684609501, Enterprise House, Pass Street 2, 0L9 6HZ Oldham,... - Page 4 Pedal assistant LCD display + fixing Accelerator Cable harness For succesful assembly of EVBIKE, you will also need following: • ribbons for cables fastening • screws, nuts, washers • special bottom bracket tools (see pictures a, b, c) • basic technical skills...
-
Page 5: Instaling Evbike Hub Motor
1. INSTALLING EVIBIKE HUB MOTOR 1) Remove the original wheel and swap tire to the EVBIKE HUB motor rim. Remove the original wheel and put tire with tube to the EVBIKE rim. Remember also protective wheel rim strip. Newly assembled wheel with HUB motor should be checked and trued after 100-200 km. - Page 6 Reaction torque on axle Direction of engine Axle spinout and spread dropouts torque Example of torque arm installation CAUTION In any case, it is necessary to ensure tight connection nuts, washers and fork surface. Insufficient nut tightening may cause wheel dropping out of the fork. The connection between wheel and fork must be firm and stable (Fig.
-
Page 7: Pedal Assistant
2. PEDAL ASSISTANT 1) When you start pedal, the pedal assistant will automatically adjust motor power. 2) To install this part, you have to remove spindle. Removing requires special tools (Fig. 1a, 1c). 3) Disassemble the bike parts as shown at the Fig. 9. 4) Mout plastic wheel with magnets in correct direction of rotation (shown on wheel by arrows). -
Page 8: Controller And Cabling
3. CONTROLLER AND CABLING Battery power Pedal assistant Cable harness (LCD display, brakes, accelerator) Motor connector WARNING Make sure proper cable connection! Conectors have different colors so risk of incorrect connection is minimised (Fig. 11). In addition, they have locks against turn over. Use adequate strength to connect connectors. -
Page 9: Lcd Panel Installation And Usage
4. LCD PANEL INSTALLATION AND USAGE The LCD panel is installed at the center of the handlebar (fig. 14), possibly may be installed on the right or left side. After installation of the LCD panel please connect cable to the control unit. Battery Capacity Light Brake... - Page 10 14. Surrounding temperature in °C or °F * Recovery function can be set in several grades. Incorrect setting can damage your battery or other electrical equipment components. For proper configuration, please contact the service partner EVBIKE. Description of the control buttons:...
- Page 11 . Recovery activation is accessible only by an authorized partner of EVBIKE and before its setting you must verify that the used battery and its protective system supports this kind of charge. 4. Indication accelerator function – this function symbol indicates the rotating parts around the perimeter of two digital digits 88 on-site display of the surrounding temperature.
- Page 12 3. Deleting the distance traveled and the travel time - To erase the data on distance milestones (DST) and travel time (TM), wait at least 20 seconds after activation of the LCD display. Then simultaneously press the symbols (UP) and (DOWN), after a few seconds, the data on time and distance will blink.
- Page 13 You can set these wheel diameters: 6, 8, 10, 12, 14, 16, 18, 20, 22, 24, 26, 700 C and 28 inches. For the speed measurement the unit EVBIKE uses signals from the hall probes of the engine.
-
Page 14: Brakes, Accelerator, Handle
5. BRAKES, ACCELERATOR, HANDLE • First disassemble the original equipment. • Controls assemble in this order see Figure 17. Accelerator and LCD can be installed on left or right side according to user preference. Brake lever Brake lever Ring spacer LCD controller LCD display Handle... -
Page 15: Maintenance
7 MAINTENANCE Before every ride is recommended to check the motor and wiring. Keep the motor and controller clean and dry. We recommend common check bolts and wiring, check if all connectors are firmly connected, then check the connector pins (whether bent or not corroded). We recommend checking every 500 km and at the start/end of the season. - Page 16 NOTES Importer: PHOYLO LTD, CZ684609501, Enterprise House, Pass Street 2, 0L9 6HZ Oldham, , UK Manchester...
