Community Playthings H551 Manual

Paper corner
Tool corner
Craft counter top 3
Craft counter top 4
Recommended Use
These items are intended for the storage and display of
arts and craft materials. They may also be used in other
interest areas for other items e.g. maths and sciences.
These counter tops can be used with craft shelves or
roomscape shelving.
Products consist of the
following:
H551 PAPER CORNER
Includes 5 green cups
H552 TOOL CORNER
H553 CRAFT COUNTER TOP 3
1 Paper corner, 1 Tool corner, 5 cups,
2 medium totes, 2 small totes, and
1 dowel
H554 CRAFT COUNTER TOP 4
1 Paper corner, 1 Tool corner, 5 cups,
4 medium totes, 4 small totes, and
1 dowel
If your shipment is incomplete,
please call Customer Service.
WARNING
c These products are intended for use by children of
immature judgment, therefore supervision is required at
all times.
CAUTION
c For indoor use only. These products are not waterproof.
Maintenance
Periodically inspect for cracks, breaks and loose or missing
parts. Remove Products from service when any condition
develops that might make operation unsafe.
Cleaning
Wipe with a damp cloth and mild detergent. Dry immediately.
Leaving water or cleaning agent on the surface may damage
the finish.
Construction
The wooden components are manufactured from solid birch
and birch plywood protected with a child-safe finish. The
cups and totes are plastic.
User modifications
We cannot be responsible for modifications made by custom-
ers to our products in the field without our supervision, test-
ing or evaluation.
IMPORTANT
Retain these instructions for future reference.
© 2005 by Community Products (UK) Ltd
TE52 Eu 0343 Revision 02
H551
H552
includes
Assembly
includes To attach Craft counter tops to Craft shelves
(requires 2 people, see Figure A):
1. Line up the counter above the shelf.
2. Lower the counter down until the back of the shelf is
To attach Craft counter tops to Roomscapes units
(requires 2 people, see Figure B):
1. Hook the front of the counter over the front edge of
2. Rotate the counter down over the back of the Rooms-
The Paper corner and the Tool corner locate on "bumps" on
the Craft counter top. Do not locate Paper corner and Tool
corner until Craft counter top is properly in place.
c Only rearrange items when Craft counter top is empty.
c Lift with 2 people where necessary.
c Do not attach Craft counter tops to 102cm high Rooms-
c Only attach Craft counter tops to Roomscapes furniture
c Craft counter tops are not intended to be used on a
Ordering parts
To order replacement parts, contact Customer Service with a
description of the part(s) needed and the ID Code from the
product.
Use only replacement parts supplied by
Community Playthings
www.communityplaythings.co.uk sales@communityplaythings.co.uk
Figure A
behind the back of the counter.
the Roomscapes unit.
capes unit.
CAUTION
Use handholds provided. Do not rearrange units with
children nearby.
capes furniture.
of the same length.
table.
Community Playthings
Brightling Road, Robertsbridge, TN32 5DR UK
Figure B
Phone: 0800 387 457
