- Page 1 PowerBrick Ultra Plus V3 Rugged Industrial Computer System User Guide Published: December 2018 Version 3.0...
-
Page 2: Copyright
All Rights Reserved – Printed in Acura Embedded Systems Inc. Disclaimer Acura Embedded Systems Inc shall not be liable for technical or editorial errors or omissions contained here; nor for incidental or consequential damages resulting from using this material, or the performance or use of this product. -
Page 3: Table Of Contents
PowerBrick Ultra Plus V3 Contents Copyright ............................... 2 Disclaimer..............................2 General Information ............................. 4 Introduction .............................. 4 Features ..............................4 Specification .............................. 4 Technical Specification .......................... 5 Physical Dimensions ..........................6 System Setup ..............................7 Exploring PowerBrick Ultra Plus V3 ....................... 7 Important Connector .......................... -
Page 4: General Information
General Information Introduction PowerBrick Ultra Plus V3 is based on an Intel® Gen 6th Core™i5 6200U processor with Intel® HD Graphics 5500 and Intel® QM77 chipset. Its default 8 GB can earily upgrade to 16 GB. The design focuses on elements essential for a variety of industrial applications and environments excluding unneccesary hardware. -
Page 5: Technical Specification
PowerBrick Ultra Plus V3 Technical Specification System Onboard Intel Gen 6 Core i5 6200U Chipset INTEL QM77 Memory 1 x 8G DDR4L to 16GB. Graphics Intel HD Graphics 5500 VGA+HDMI, Synchronous or asynchronous display Resolution VGA maximum :1680x1050 HDMI maximum :1920x1080 Operating System Windows 7/10 Pro 32 or 64-bits Watchdog... -
Page 6: Physical Dimensions
PowerBrick Ultra Plus V3 Environment Operating Temp. -20°C~60°C (-4°F~140°F) Storage Temp. -40°C~85°C (-40°F~185°F) Relative Humidity 10%~90% (non-condensing) Physical Features Construction Aluminum alloy Mounting Supports wall‐mount Weight 2.1 kg (4.6 LBs) Dimensions 220mm x 166mm x 70.5mm (8.7" x 6.5" x 2.8") Physical Dimensions... -
Page 7: System Setup
PowerBrick Ultra Plus V3 Chapter 2 System Setup Exploring PowerBrick Ultra Plus V3 Get familiar with the locations and purposes of controls, drives, connectors and ports, which are illustrated in the figures below. Power COM5 Button COM6 USB2.0 Line DC IN Wi-Fi MIC USB3.0 USB3.0 HDMI DC IN... -
Page 8: Important Connector
PowerBrick Ultra Plus V3 Important Connector DC IN 12V Connector Signal Wire Color DC +9-30 V Negative Black Ground Green COM Port Connector (COM) Signal COM1,2,3_DCD (COM4,5,6 RS-485_TXD-/RXD-) COM1,2,3_RXD (COM4,5,6 RS-485_TXD+/RXD+) COM_TXD COM_DTR COM_DSR COM_RTS COM_CTS COM_RI#... -
Page 9: Bios Setting
