PARTS & OPERATING MANUAL
S-SERIES, 22-GALLON MID-SIZE
This operator's book has important information for the use and safe operation of this machine. Read this book carefully before
starting the machine. Keep this book near the machine, protected from liquids and other substances that can cause damage to it.
If you do not follow the instructions, you can cause an injury or damage equipment, furniture or buildings.
For new books, please download your copy from our website www.pacificfloorcare.com or write to:
Pacific Floorcare
2259 S. Sheridan Drive
Muskegon, MI 49442-6252
Carefully inspect all components to ensure that there is no concealed freight damage. If such damage is discovered, file a
"CONCEALED DAMAGE REPORT" immediately with the delivering carrier.
The contents of this manual are based on the latest product information available at the time of publication. Pacific Floorcare
reserves the right to make changes or improvements without being obliged to apply changes to the machines previously sold.
Thank you for purchasing a Pacific Floorcare product. Warranty registration will allow us to better serve you over the lifetime of
the product. For quick and easy registration, go to: www.pacificfloorcare.com/Register Product.
AUTO SCRUBBERS
PLEASE READ THIS BOOK
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S-SERIES and is the answer not in the manual?

Questions and answers

Related Manuals for Pacific Floorcare S-SERIES

Summary of Contents for Pacific Floorcare S-SERIES

  • Page 1 Thank you for purchasing a Pacific Floorcare product. Warranty registration will allow us to better serve you over the lifetime of...

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS This machine is intended for commercial use. Only use recommended pads or brushes and commercially approved floor cleaning chemical intended for machine application. The following symbols will be used to warn you of hazards or unsafe practices which could result in personal injury or death: CAUTION: INDICATES A POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT AVOIDED, MAY RESULT IN MINOR OR MODERATE INJURY.
  • Page 3 SAFETY PRECAUTIONS NOTE: Do not allow the brush/pad to operate while the machine is stationary to avoid damage to the floor. CAUTION: Do not bump into shelves or scaffoldings, especially where there is a risk of falling objects. CAUTION: Before leaving or servicing a machine, stop it on a level surface. NOTE: Before leaving or servicing a machine, turn off the unit and remove the key.

  • Page 4: Unpacking The Machine

    NOTE: The on-board charger has been programmed to work with the batteries that Pacific Floorcare provides. Using other battery types not specified for the S-Series mid-size scrubber by Pacific Floorcare may impair performance of the unit and will affect the life of the batteries.

  • Page 5: Battery Power Level Indicator

    MACHINE PREPARATION BATTERY POWER LEVEL INDICATORS The battery power level gage is located on the upper control panel. The gage has a series of LEDs to indicate the amount of power left in the batteries. When the batteries have a full charge, all LEDs are lit. As the batteries are discharged, the LEDs will begin to go out from right to left.

  • Page 6: Machine Preparation

    USING YOUR ON-BOARD CHARGER CHARGING THE BATTERIES WITH AN ON-BOARD CHARGER Before using your S-Series mid-size scrubber for the first time, fully charge your batteries. These units can be equipped with an on-board charger. The on-board charger is equipped with a 9 foot long cord that can be plugged directly into a 120V outlet. Do not use an extension cord.

  • Page 7: Battery Type

    Both the on-board and off-board chargers are able to charge wet, lead acid or maintenance-free AGM batteries. As your unit leaves Pacific Floorcare’s factory, the charger is set up to match the type of battery chosen in the original machine order. Should you choose to change from the original battery type, the charger can be changed by re-setting the dip switches.
  • Page 8 The off-board charger has both a standard 120V power cord and a cord with an “Anderson connector”. There is also an Anderson connector on-board the S-Series mid-size scrubber located on the lower control panel at the rear of the machine.
  • Page 9 SETTING THE DIP SWITCHES ON YOUR OFF-BOARD CHARGER FOR YOUR BATTERY TYPE The off-board charger is able to charge wet, lead acid or maintenance-free AGM batteries. As your unit leaves Pacific Floorcare’s factory, the charger is set up to match the type of battery chosen in the original machine order. Should you choose to change from the original battery type to the other, the charger can be changed by re-setting the dip switch.

  • Page 10: Solution Tank

    SOLUTION TANK To prepare the machine for cleaning, the unit must be filled with cleaning solution. Water and cleaning agent can be added to the S-Series mid-size scrubber’s rear hose fill port located to the left of the control panel.
  • Page 11 MACHINE PREPARATION SOLUTION TANK - AUTO-OFF SOLUTION FILL SYSTEM OPTION If your machine is equipped with the auto-off solution fill system option, connect the male end of the quick-connector to your 1/2-inch inner diameter fill hose. Once your fill hose is set up, leave the faucet for that hose open - the connector will act as a stop. When it is time to fill your machine, click the hose onto the female quick-connector at the back of the machine and the unit will begin to fill with water.
  • Page 12 Repeat for the other pad driver. NOTE: The S-Series pad drivers are tufted pad drivers. Do not use a pad driver on the floor without a pad in place. This will cause damage to your floor.
  • Page 13 The pad drivers or brushes are attached by using the automatic on/off system. This valuable ingenuity removes the need for operators to kneel or strain to attach the pad drivers or brushes. First, start by placing the pad drivers or brushes on the floor in front of the S-Series mid-size scrubber. Turn the unit on using the power key switch.
  • Page 14 MACHINE PREPARATION ATTACHING YOUR PAD - ORBITAL HEAD ATTACHING A PAD TO YOUR ORBITAL PAD DRIVER The orbital unit can be used for daily cleaning; however it specializes in chemical-free finish removal for low-cost finish maintenance programs. The following directions show how to prepare the machine for both applications. For cleaning, the orbital unit is fit with a rectangular, 28 in (711 mm) x 14 in (356 mm) pad.
  • Page 15 MACHINE PREPARATION CONNECTING THE SQUEEGEE AND ADJUSTING SQUEEGEE HEIGHT Prior to shipping from the factory, the squeegee assembly is removed from the unit. To connect your squeegee assembly to the machine: Align the squeegee assembly retention slots with the easy-grip knobs then tighten until secure. Attach the recovery hose to the squeegee assembly neck.
  • Page 16 TREATING YOUR RECOVERY TANK Your S-Series mid-size scrubber has been designed with a debris tray and the TTS tank treatment system. TTS is a treatment system that utilizes Bromine tablets, typically used in pools and spas, to kill the bacteria in the tank that cause odors. To ensure that TTS is prepared to treat your recovery tank: Lift the recovery tank lid to the open position and locate the debris tray.

  • Page 17: Turning The Unit On/Off

    Additionally, once in operation, Pacific Floorcare’s goal was to provide an ergonomic, easy to use system. Due to this focus, the S-Series mid-size scrubber’s key operational controls are all within reach so that the operator doesn’t have to remove their hands to perform the operation - a key to safe, trouble-free, highly productive cleaning.
  • Page 18 MACHINE OPERATION ON-BOARD CHEMICAL INJECTION SYSTEM If your S-Series mid-size scrubber is equipped with the on-board chemical injection system, the following instructions will walk you through the easy process of setting up and operating this system. Lift the recovery water tank, opening it as far as it will go using the side handle.
  • Page 19 MACHINE OPERATION ON-BOARD CHEMICAL INJECTION SYSTEM Once the chemical mix ratio is selected, set your desired solution flow rate to low, medium or high based on your cleaning needs and the chemical injection system will automatically mix your chemical for you. A solid green LED indicates the system is powered and working properly.
  • Page 20 These steps are visually shown on the lower control panel by the S-Series mid-size scrubber’s “1, 2, 3-Step” on-board operation guide. Following are the detail steps of how scrubbing and recovery functions are activated.
  • Page 21 To lower the squeegee, lift the squeegee lever and shift it left to clear the notch. Once clear, lower the squeegee into the recovery position. In doing so, the S-Series mid-size scrubber’s vacuum motor will activate. Self-adjusting head shroud with...
  • Page 22 MACHINE OPERATION OPERATIONAL CONTROLS ACTIVATING THE SCRUBBER To begin scrubbing, engage the handle trigger. The trigger activates solution flow, the brush motor and traction drive. This unique, ergonomic design accommodates different operator heights by allowing the user to activate the trigger from any position on the handle.

  • Page 23: Transport Mode

    Easily transport machines in, out or through facilities with the S-Series mid-size scrubber’s unique squeegee hanger feature. Simply remove the squeegee assembly (see Page 14) while leaving the recovery hose attached, lift the squeegee to a vertical position on the right side of the machine and place the squeegee tab into the squeegee hanger.

  • Page 24: Maintenance

    MAINTENANCE SCHEDULE FOR SERVICE EVERY SIX MAINTENANCE DAILY WEEKLY MONTHLY MONTHS 100 HOURS 200 HOURS Clean squeegee assembly. Check blades for wear or damage. Check if adjustment needed to squeegee height Clean out recovery tank inside and out and float shut off assembly. Check both for damage.

  • Page 25: Recovery Tank

    MAINTENANCE END OF SHIFT Once you’ve completed your daily scrubbing, project work or finish maintenance, proper end of use maintenance can greatly extend the machine’s life, improve performance, enhance sanitization and lower the machine’s long-term operational costs. There are four key areas we will review and demonstrate: the recovery tank, squeegee assembly, battery maintenance and charging, ending with pad and brush maintenance.

  • Page 26: Squeegee Assembly

    Inspect the front and rear squeegee blades. If the blade edges are not clearly defined or worn halfway through the thickness of the blade, then it is time for replacement or to be flipped to another edge. The S-Series mid-size scrubber’s squeegee blades have four usable edges.

  • Page 27: Battery Maintenance

    Based on research and experience, batteries are the number one nuisance issue and drive a high cost of ownership if not properly maintained. With the S-Series mid-size scrubber, you can select from two types of batteries: wet, lead acid or sealed, maintenance-free AGM.
  • Page 28 MAINTENANCE END OF SHIFT BATTERYSHIELD AUTOMATIC WET BATTERY PROTECTION SYSTEM If your scrubber is equipped with BatteryShield technology, your scrubber will provide you “real time” notification when your wet batteries need to be watered. After your machine is charged and you turn the key switch on, BatteryShield will check your water levels for you. You can locate the BatteryShield optical sensor on the HydroLink®...
  • Page 29 END OF SHIFT PAD DRIVER AND BRUSH MAINTENANCE This portion of maintenance is simple and quick, but key to keeping your S-Series mid-size scrubber performing at peak levels. Remove the pad drivers or brushes to check for wear. To remove the pad drivers or brushes from your disk unit, locate the automatic off switch on the lower control panel at the rear of the machine.

  • Page 30: Periodic Maintenance

    CHANGING BATTERIES To change the batteries in your S-Series mid-size scrubber, move the machine to an area with a level surface, turn off the power switch and remove the key. If using an off-board charger, make sure that it is located near your machine and that your location is close to an electrical outlet for charging after installation.
  • Page 31 The locations of the isolators are shown below. If any of your isolators show signs of wear, degradation or damage, contact an authorized service center or Pacific Floorcare technical service to find a local authorized service center to replace all eight isolators.
  • Page 32 PERIODIC MAINTENANCE INSPECTING THE HEPA FILTER Your S-Series mid-size scrubber is equipped with a HEPA filter. You can locate the HEPA filter by lifting the recovery water tank, opening it as far as it will go using the side handle.
  • Page 33 TRANSPORTING YOUR UNIT Your S-Series mid-size scrubber was designed so that it could easily be transported on a route cleaning program. Easily transport machines in, out or through facilities with the S-Series mid-size scrubber’s unique squeegee hanger feature. Simply remove the squeegee assembly (see Page 14) while leaving the recovery hose attached, lift the squeegee to a vertical position on the right side of the machine and place the squeegee tab into the squeegee hanger.
  • Page 34 Remove and visually inspect the inside of the HEPA filter. Major discoloration or build up can cause reduced vacuum performance. Replace HEPA filter if necessary. Finally, should you still have recovery issues, contact your distributor or Pacific Floorcare for technical support. Lower elbow of recovery hose and...

  • Page 35: Troubleshooting

    See Changing Batteries segment of this manual for further instructions on how to replace your batteries. If none of these factors are present and you are still not getting expected run times, contact your distributor or Pacific Floorcare for technical support.
  • Page 36 Check to make sure that the ball valve is open. The handle of the ball valve should be in line with the solution flow direction. If none of the actions listed above fix the solution flow, contact your distributor or Pacific Floorcare for technical support.
  • Page 37 Of course, a long thin tool of some kind can be used as well, but be extremely careful not to puncture the hose wall. If a clog isn’t found in the system, contact your distributor or Pacific Floorcare for technical support.
  • Page 38 To fix this, check the routing of the recovery hose to be sure that it is not impeding the squeegee assembly from swinging. If this isn’t the issue, contact your distributor or Pacific Floorcare for technical support. Properly routed recovery hose...

  • Page 39: Troubleshooting Guide

    TROUBLESHOOTING GUIDE ISSUE POTENTIAL CAUSE PROPOSED SOLUTION Make sure the solution control valve is open by Solution flow setting is too low adjusting the solution flow knob Check the sight gage for solution level. If low or Solution tank is empty empty, add water and detergent Remove inline filter cap &...
  • Page 40 TROUBLESHOOTING GUIDE ISSUE POTENTIAL CAUSE PROPOSED SOLUTION Inspect & replace if necessary. Brushes should be Machine isn’t cleaning satisfactorily Pad or brush may be worn replaced when the bristles reach a length of 3/4 in (19 mm) Check bottle label. Use low foaming detergent or Detergent used is not a low foaming add a small quantity of defoamer to the recovery detergent...
  • Page 41 TROUBLESHOOTING GUIDE BATTERY POWER LEVEL INDICATOR FAULT CODES TRANSAXLE DRIVE UNITS CODE (FLASHING LED POTENTIAL CAUSE PROPOSED SOLUTION Recharge batteries Low voltage shut-off. Brush motor shut down Check battery connections Battery charge level getting low Recharge batteries Traction drive motor tripped Remove overload condition and reset Three Traction drive motor has short circuited...
  • Page 42 SUGGESTED SERVICE PART LISTING S-28 S-28 DISK ORBITAL OPTIONS SUB-ASSEMBLY DESCRIPTION PART NUMBER S-24 QTY S-32 QTY Charger, On-board Cord, 9 ft (3 m) 908128* Charger, On-board Charger, on-board, 24VDC 852407 BatteryShield Sensor assy, BatteryShield 878520 ® BatteryShield Relay, BatteryShield 911685 ®...
  • Page 43 SUGGESTED SERVICE PART LISTING S-28 S-28 DISK ORBITAL OPTIONS SUB-ASSEMBLY DESCRIPTION PART NUMBER S-24 QTY S-32 QTY Head Belt, v-groove 903046* Head Bearing, .75-inch, sealed 902053 Head Guide, driver 853803* Head Guide, pad 853804* Head Guide, pad, plastic 873801* Head Wheel, guide 859703 Head...
  • Page 44 SUGGESTED SERVICE PART LISTING S-28 S-28 DISK ORBITAL OPTIONS SUB-ASSEMBLY DESCRIPTION PART NUMBER S-24 QTY S-32 QTY Squeegee Blade, rear, 35 in (889 mm) Linatex 870701* Squeegee Blade, rear, 35 in (889 mm) urethane 870707* --> Squeegee Blade, front, 35 in (889 mm) Linatex 870702* Squeegee Blade, front, 35 in (889 mm) urethane...
  • Page 45 FRAME ASSEMBLY WITH URETHANE WHEELS...
  • Page 46 FRAME ASSEMBLY WITH FOAM-FILLED WHEELS...

  • Page 47: Solution Tank Assembly

    SOLUTION TANK ASSEMBLY Head switch location for all machines built prior to March 13, 2015 and before serial #102090...
  • Page 48 ON-BOARD CHEMICAL INJECTION ASSEMBLY (OPTIONAL)

  • Page 49: Battery Assembly

    BATTERY ASSEMBLY...

  • Page 50: Recovery Tank Assembly

    RECOVERY TANK ASSEMBLY...
  • Page 51 SQUEEGEE ASSEMBLY, S-24...
  • Page 52 SQUEEGEE ASSEMBLY, S-28...
  • Page 53 SQUEEGEE ASSEMBLY, S-32...
  • Page 54 SQUEEGEE LINKAGE ASSEMBLY...
  • Page 55 HEAD LIFT ASSEMBLY...
  • Page 56 HEAD ASSEMBLY (DRAWING 1 OF 2), S-24...
  • Page 57 HEAD ASSEMBLY (DRAWING 2 OF 2), S-24...
  • Page 58 HEAD ASSEMBLY, S-28 DISK...
  • Page 59 HEAD ASSEMBLY, S-32...
  • Page 60 HEAD ASSEMBLY, LOWER, S-28 ORBITAL...
  • Page 61 HEAD ASSEMBLY, UPPER, S-28 ORBITAL...
  • Page 62 CONTROLS ASSEMBLY, S-24...
  • Page 63 CONTROLS ASSEMBLY, S-28 & S-32 DISK...
  • Page 64 CONTROLS ASSEMBLY, S-28 ORBITAL...
  • Page 65 CONTROLS ASSEMBLY, BATTERYSHIELD & CHEMICAL INJECTION SYSTEM ® (OPTIONAL)
  • Page 66 ELECTRONICS ASSEMBLY, S-24...
  • Page 67 ELECTRONICS ASSEMBLY, S-28 & S-32 DISK...
  • Page 68 ELECTRONICS ASSEMBLY, S-28 ORBITAL...
  • Page 69 ELECTRONICS ASSEMBLY, BATTERYSHIELD...
  • Page 70 CHARGER ASSEMBLY, ON-BOARD...

  • Page 71: Wiring Diagrams

    WIRING DIAGRAM, S-24 * 1 amp diode part #: 7250008...
  • Page 72 WIRING DIAGRAM, S-28 & S-32 DISK * 1 amp diode part #: 7250008...
  • Page 73 WIRING DIAGRAM, S-28 ORBITAL * 1 amp diode part #: 7250008...
  • Page 74 WIRING DIAGRAM, BATTERYSHIELD (OPTIONAL)
  • Page 75 WIRING DIAGRAM, ON-BOARD CHEMICAL INJECTION SYSTEM (OPTIONAL)

  • Page 76: Warranty Policy

    2. Upon compliance with the above warranty procedure, all warranted repairs will be completed at no additional charge or cost to the user. 3. Only Pacific Floorcare or its authorized dealers and agents may make no charge warranty repairs on this product. All others do so at their own risk.
