P R O G R A M M A B L E F E E D E R
5 lb and 10lb ASSEMBLY INSTRUCTIONS:
To Assemble Hopper on Base:
1) Align hopper with base.
2) Insert hopper into base.
3) Twist and lock into place.
To Assemble Lid on Hopper:
1) Line up arrows on hopper with arrows on lid.
2) Place lid on top of hopper.
3) Twist and lock lid into place.
To Assemble Bowl into Base:
1) Insert bowl into base.
2) Lower bowl into base connecting hooks into the base.
(Make sure Portion Control LeBistro
®
Close up ofTwist and Lock Hopper on Base.

SPECIFICATIONS:

Programming
• Up to three different sized Meals per 24 hours.
• Each Meal Serving is adjustable in 1/4 cup increments.
• 5 lb unit can be set from 1/4 cup to 2 cups.
• 10 lb unit can be set from 1/4 cup to 3 cups.
• Default Meal Servings are: Breakfast at 6:00 a.m. Lunch at 12:00 p.m. and
Dinner at 6:00 p.m.All Meals are preset for 1/2 cups.
Dimensions
14"L x 10"W x 15"H (assembled)
Capacity
• 5 lb Hopper (alone) will hold 5.0 Ibs of typical variety of dry food.
• Base unit fully loaded, bowl and food wheel will hold additional 0.9 Ibs.
• 10 lb Hopper (alone) will hold 8.55 Ibs of typical variety of dry food.
• Base unit fully loaded, bowl and food wheel will hold additional 1.55 Ibs.
is placed on an even surface)
Alignment Arrows
Base
Food Chute
Removable Bowl
Close up of Bowl hook into Base.
Wheel Dispensing Capacity
• 1/4 Cup increments or 1 Cup per complete revolution.
Overall Weight
• Weight: 3.5 Ibs (assembled without batteries and food).
Power
• Requires THREE "D" size batteries. Batteries NOT included.
• Use only alkaline batteries.
• Estimated life of one set of batteries is 6 months or less.
Note: DC Power Converter available as an accessory and can
be ordered online at www.petmate.com
Types of Food
• Dry dog or cat food only.
• Do NOT use canned food. Do NOT use moist dog or cat food.
• Do NOT use semi-moist food. Do NOT use treats.
Locking Lid
Hopper
Control Panel
Low Battery Light
Lift Handles
