  • Page 1 User’s Guide MK STRUCTURE MK STRUCTURE MK STRUCTURE MK STRUCTURE E03FFN Construcción...
  • Page 2 Neither all nor part of this document may be reproduced or transmitted in any way by any electronic or mechanical procedure, including photocopy, magnetic recording or any other form of information storage or retrieval system without the permission of ULMA...

  • Page 3: Table Of Contents

    INDEX INDEX INDEX INDEX 4.4. STRUCTURE CONNECTION WITH SHORING ON ............................... 4 4 4 4 ..1. PRODUCT DESCRIPTI 1. PRODUCT DESCRIPTI 1. PRODUCT DESCRIPTI 1. PRODUCT DESCRIPTION SYSTEM ..............39 1.1. MK TRUSS ............5 4.5.

  • Page 4: Product Description On

    The core item for all these solutions is the Waler MK. Its elaborated design and the combination with various accessories, both unique of the MK system as well as shared with other ULMA products, enable to adapt it to all those above mentioned applications.

  • Page 5: Mk Truss

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 1.1. MK TRUSS MK TRUSS MK TRUSS MK TRUSS A truss structure, bi- or multi-supported, supports the formwork and absorbs the loads acting on the formwork. The formwork systems commonly used with the MK Truss Structure are Enkoform VMK or Enkoform H-120.
  • Page 6 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE If the span of the upper boom (or element that works at compression) is sought to be reduced or the bending capacity to be increased, a vertical tube is used to make the structure bear higher loads.

  • Page 7: Mk Form Carriers

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 1.2. MK FORM CARRIERS MK FORM CARRIERS MK FORM CARRIERS MK FORM CARRIERS The following types of form carriers can be erected with the MK system: Deck flange form carrier − Parapet form carrier −...
  • Page 8 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE There are two types of deck flange form carriers: Those where the rolling system is part of the form carrier (i.e. integrated in the secondary structure) or − Those where the rolling system is not part of the form carrier.
  • Page 9 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 1.2.2. PARAPET FORM CARRIER PARAPET FORM CARRIER PARAPET FORM CARRIER PARAPET FORM CARRIER This form carrier is a lighter version of the previous one. It is used for applications with lower load-bearing and forward-moving capacities. Unlike the one mentioned beforehand, the parapet form carrier can be moved manually and requires a solid base where the guide rail rests on.
  • Page 10 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 1.2.3. VERTICAL FORMWORK CARRIER VERTICAL FORMWORK CARRIER VERTICAL FORMWORK CARRIER VERTICAL FORMWORK CARRIER The main feature that distinguishes the vertical formwork carrier from others is that the vertical loads acting on the structure are exclusively caused by the self-weight of the structure. Its load-bearing and forward-moving capacities are still lower than the ones of the above mentioned form carriers.
  • Page 11 An all-round solution for cut-and-cover tunnels combines the MK Structure system for the top part of the vault with the MK Shoring system. A cut-and-cover tunnel form carrier usually consists of the following parts: Main structure: structure bearing the concrete load, both the vertical as well as the horizontal loads.
  • Page 12 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE Cut-and-cover tunnel from carriers vary depending on aspects such as the load-bearing capacity and the area where it is supported on and moved forward. Two types of cut-and-cover tunnel form carriers are distinguished regarding a restricted or free support area. In all cases, the rolling system forms part of the form carrier, i.e. it is integrated in the bogie.

  • Page 13: System Components

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 2. 2. 2. 2. SYSTEM COMPONENTS AND ACCESSORIES SYSTEM COMPONENTS AND ACCESSORIES SYSTEM COMPONENTS AND ACCESSORIES SYSTEM COMPONENTS AND ACCESSORIES 2.1. 2.1. 2.1. 2.1. GRAPHIC DESCRIPTION GRAPHIC DESCRIPTION GRAPHIC DESCRIPTION GRAPHIC DESCRIPTION Weight Weight Weight...
  • Page 14 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE Weight Weight Weight Weight Weight Weight Weight Weight Item no. Item no. Item name Item name Item no. Item no. Item name Item name Item no. Item no. Item name Item name Item no. Item no.
  • Page 15 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE Weight Weight Weight Weight Weight Weight Weight Weight Item no. Item no. Item name Item name Item no. Item no. Item name Item name Item no. Item no. Item name Item name Item no. Item no.
  • Page 16 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE Weight Weight Weight Weight Weight Weight Weight Weight Item no. Item no. Item name Item name Item no. Item no. Item name Item name Item no. Item no. Item name Item name Item no. Item no.

  • Page 17: Items Description

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE In the centre row, holes and slots alternate, the holes 2.2. ITEMS DESCRIPTION ITEMS DESCRIPTION ITEMS DESCRIPTION ITEMS DESCRIPTION have a diameter of ∅20 mm, the slots have a length of 45.5 mm. The spacing between the holes in the The following connections with bolt and nut will centre row is 125 mm.
  • Page 18 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 2.2.3. NODE 120 MK This node enables to connect up to 3 walers at 60º. The connections are fastened with 6 bolts M16 inserted into the D17 holes. The D20 holes are mainly used for the connection of secondary components, i.e., bracing items.
  • Page 19 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE The D20 holes are mainly used for the connection of The support plate provides D25 (25 mm diameter) secondary components, i.e., bracing items. and D22 holes to connect other items and accessories. 2.2.7. NODE 90 MK 2.2.9.
  • Page 20 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 2.2.11. V BRACING TRUSS MK This part serves to reinforce certain points of the structure in its main plane where loads on the structure require such a reinforcement of the waler. Push Push Push Push- - - - Pull Prop E range from 2.2 Pull Prop E range from 2.2...
  • Page 21 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 2.2.15. HORIZONTAL BRACES 2.2.16. U SECONDARY AXIS MK DIAGONALS MK This item connects horizontal braces and diagonals to the structure. It can be placed either on walers or These items make the bracing of the structures.
  • Page 22 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 2.2.18. WALER - WALER 90º JOINT MK AND 2.2.20. JACK 360 MK NODE - WALER 90º JOINT MK The jacks are the elements which allow of the vertical adjustment, that is, the levelling of the form carrier.
  • Page 23 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 2.2.23. JACK WALER MK The jack walers form the bogie of heavy-duty form carriers. The bogie length can be adjusted at an interval of every 0.5 m. The jack walers are fastened together with 8 bolts M24 inserted into the D25 holes of their end-plate joints, thus creating a longer jack waler profile.
  • Page 24 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 2.2.28. NODE END-PLATE JOINT MK and WALER END-PLATE JOINT MK The Node End-Plate Joint MK enables an end joint of structures whenever a hinged support on the same is required. It is connected directly onto the MK Shoring Towers or to the bogie.

  • Page 25: Dismantling

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 3. 3. 3. 3. A A A A SSEMBLY, USE AND SSEMBLY, USE AND SSEMBLY, USE AND SSEMBLY, USE AND DISMANTLING DISMANTLING DISMANTLING DISMANTLING 3.1. 3.1. 3.1. 3.1. TECHNICHAL ASSEMBLY INSTRUCTIONS. GENERAL ASSEMBLY TECHNICHAL ASSEMBLY INSTRUCTIONS. GENERAL ASSEMBLY TECHNICHAL ASSEMBLY INSTRUCTIONS.
  • Page 26 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 3.1.3. Bracing assembly. Diagonals horizontal braces assembly between structures. - Assemble another structure equal to the first by following the steps described in 3.1.1. - Lift the whole or part of the structure and place it parallel to the first with the horizontal braces already in place.
  • Page 27 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE To form the handrail, use tubes D48 connected with the Handrail Head MK and couplers 48. The head is fastened to the waler with bolt M16. - Likewise proceed if it is required to assemble the Triangular Base MK.
  • Page 28 - In the case of combinations between MK Shoring Towers and MK Structure (Cut-and-cover tunnel form carrier), the lifting is carried out in several steps. To place the structure on towers, use walkway - Proceed with covering the parts of the structure platforms.

  • Page 29: Solutions

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE in order to ease future operations such as the placing 4. 4. 4. 4. Solutions Solutions Solutions Solutions of the structure into its final position. High load-bearing capacity structures up to 360 kN are obtained with triangular structures. These...
  • Page 30 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 4.1 STRUCTURE TYPES 4.2.2 Reinforced main axis structure 4.1.1 Truss structure 4.2.3 Medium load-bearing capacity 4.1.2 Hanging structure structure 4.1.3 Structure of form carriers 4.2.4 Secondary axis structure 4.1.4 Forward-moving structure 4.3 BRACING BETWEEN STRUCTURES 4.2 STRUCTURE LAYOUTS...
  • Page 31 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE STRUCTURE CONNECTION WITH SHORING 4.6 FORWARD-MOVING OF STRUCTURES SYSTEM 4.6.1 High load-bearing structure 4.4.1 Support on shoring towers or props 4.6.2 Medium load-bearing structure 4.4.2 Support on bogie 4.7 SAFETY AND ACCESS PLATFORMS 4.5 STRUCTURE LEVELLING 4.5.1 High load-bearing structure...

  • Page 32: Structure Types

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 4.1. 4.1. STRUCTURE TYPES STRUCTURE TYPES 4.1. 4.1. STRUCTURE TYPES STRUCTURE TYPES Theoretical length Theoretical length Theoretical length Theoretical length Nodes distance Nodes distance Nodes distance Nodes distance 1.625 m 4.1.1. Bi- or multi-supported truss structure 2.125 m...
  • Page 33 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE In general, they are tied directly to the main 4.1.3. Structure of form carriers structures with pins D40 allowing of a fast and safe Such structures must only bear their self-weight plus on-site assembly. the formwork they hold. They are medium load- bearing capacity structures and light, in general.

  • Page 34: Structure Layouts

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 4.1.4. Forward-moving structures For the forward-moving of heavy structures, an auxiliary structure is required. Such complementary or secondary structure (bogie) is placed perpendicular to the main structure easing the forward-moving of the overall structure consisting of...
  • Page 35 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 180º joint 90º joint Used for the intermediate nodes of the structure. Used at the ends which require a termination of the structure at 90º. Moreover useful when a pre- There are two options depending on the requirement...
  • Page 36 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE Joint with pins It is used to join two structures quickly and effectively. These are usually end joints which require a male end element on one structure and a female on the other. There are several parts fulfilling this function.
  • Page 37 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE - The second waler joint is a joint only between The joint can be fixed at any point of the waler, walers. The bracing of the secondary axis is made at aligned with a hole or slot every 62.5 mm, in both another point.

  • Page 38: Bracing Between Structures

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE Waler on V Bracing Truss MK joint used when actions in the secondary plane are There is still another way to join two walers. That is certainly not important. with the V Bracing Truss MK and without any additional part.

  • Page 39: Structure Connection With Shoring System

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE These joints allow of the pre-assembly of towers. 4.4. 4.4. 4.4. 4.4. STRUCTURE STRUCTURE STRUCTURE STRUCTURE CONNECTION CONNECTION CONNECTION CONNECTION WITH WITH WITH WITH Only subsequently, the structure is supported on SHORING SYSTEM SHORING SYSTEM...

  • Page 40: Structure Levelling

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 4.5. 4.5. 4.5. 4.5. STRUCTURE LEVELLING STRUCTURE LEVELLING STRUCTURE LEVELLING STRUCTURE LEVELLING 4.5.1. High load-bearing capacity structure These structures commonly have a bogie. The levelling of these structures is done with the Jacks MK 360 below the jack walers that form the bogie. If the acting loads allow it, Jacks MK 150 might also be used.

  • Page 41: System

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 4.5.2. Medium load-bearing capacity structure the next pouring stage is done with the aid of load arrester devices (e.g. Tractels). For lighter form carriers, the levelling is done using the Jack MK 60. These solutions do not require a...

  • Page 42: Safety And Access Platforms

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE Both options similarly serve to assemble platforms 4.7. 4.7. 4.7. 4.7. SAFETY AND ACCESS PLATFORMS SAFETY AND ACCESS PLATFORMS SAFETY AND ACCESS PLATFORMS SAFETY AND ACCESS PLATFORMS inside the structure. Safety platforms are assembled directly on the structures.

  • Page 43: System Properties

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE SYSTEM PROPERTIES SYSTEM PROPERTIES SYSTEM PROPERTIES SYSTEM PROPERTIES It is rather difficult to define limits for the manifold possible structure options which can be formed with the MK system. As for their variety, each structure must be calculated on an individual basis. Nevertheless, this chapter gives the necessary data to perform these calculations, and presents some limits for the most critical elements.
  • Page 44 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE Compression load of WALER MK Compression load of WALER MK- - - - 120 Compression load of WALER MK Compression load of WALER MK Free length Free length Free length Free length Compression load Compression load...
  • Page 45 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 5.1.5. PINNED JOINTS: PIN D40 AND MK CONNECTOR / NODES / JOINTS The working load of the pin D40 used in a joint of the structure: Designation Designation Designation Designation Working load (SLS) Working load (SLS)
  • Page 46 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 5.1.7. DIAGONAL TUBES MK (50x4) D D D D D D D D For any length of diagonals DIAGONAL LENGTH DIAGONAL LENGTH DIAGONAL LENGTH DIAGONAL LENGTH TENSION (SLS) TENSION (SLS) TENSION (SLS) TENSION (SLS) COMPRESSION (SLS)
  • Page 47 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE For the second case: R R R R C C C C C C C C BRACE LENGTH BRACE LENGTH DISTRIBUTED LOAD (SLS) R DISTRIBUTED LOAD (SLS) R COMPRESSION (SLS) COMPRESSION (SLS) BRACE LENGTH BRACE LENGTH...
  • Page 48 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 5.1.11. JACK WALER MK The jack waler is studied for the stripping at a 250 mm distance from the supporting areas of the posts. These areas have to be properly stiffened. F = 360 kN (SLS)
  • Page 49 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 5.1.12. JACK MK 360 The working loads of the Jack MK 360 are indicated in the table below. The table shows the possible combinations of axial (V) and horizontal (H) forces for the different jack extensions. In the same figure, two straight lines delimit the values for which there might be a sliding of the nut with respect to the fixed base depending on some estimated friction coefficients for a nut lubricated or non-lubricated on its base.

  • Page 50: Limits For Standard Structures

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 5.2. 5.2. 5.2. 5.2. LIMITS FOR STANDARD STRUCTURES LIMITS FOR STANDARD STRUCTURES LIMITS FOR STANDARD STRUCTURES LIMITS FOR STANDARD STRUCTURES The following information and data may merely act as reference. Formulas included in different calculation bases for truss beams are used.
  • Page 51 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 5.2.1.1. Node distance 3 m Truss 2,60 Truss Longitud Total qmax kN/m NTensor max MCercha max Mmax Riostra Axil Max kN R Apoyos kN Tensor a utilizar Truss (m) (ELS) kN (ELS) kNm (ELS) kNm (ELS)
  • Page 52 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 5.2.1.2. Node distance 2.5 m Truss 2,17 Truss Longitud Total qmax kN/m NTensor max MCercha max Mmax Riostra Axil Max kN R Apoyos kN Tensor a utilizar Truss (m) (ELS) kN (ELS) kNm (ELS) kNm (ELS)
  • Page 53 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 5.2.1.3. Node distance 2m Truss 1,73 Truss Longitud Total qmax kN/m NTensor max MCercha max Mmax Riostra Axil Max kN R Apoyos kN Tensor a utilizar Truss (m) (ELS) kN (ELS) kNm (ELS) kNm (ELS)
  • Page 54 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 5.2.1.4. Node distance 1.5m Truss 1,30 Truss Longitud Total qmax kN/m NTensor max MCercha max Mmax Riostra Axil Max kN R Apoyos kN Tensor a utilizar Truss (m) (ELS) kN (ELS) kNm (ELS) kNm (ELS)

  • Page 55: Terms And Conditi

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE the stability of all ties, meshes, platform 6. 6. 6. 6. TERMS AND CONDITIONS OF USE TERMS AND CONDITIONS OF USE TERMS AND CONDITIONS OF USE TERMS AND CONDITIONS OF USE anchorages, etc. before and afterwards.
  • Page 56 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 6.1.2. Guidelines for Guidelines for structures structures Guidelines for Guidelines for structures structures • Ensure that there are no loose elements on top of the structure if the dismantling is done by 6.1.2.1. Structure assembly means of crane.
  • Page 57 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE must be thoroughly sealed to prevent any further • Place the concrete in uniform layers of 30 to 45 damage to the plywood. • Any cut edge of the plywood should be sealed as • For vertical concrete placement, cast the concrete...

  • Page 58: Transport, Handling And Storage

    MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE • Increase the curing time of the concrete when • The material packed transport facing fast drying and shrinkage due to appropriate containers such as wood or steel evaporation from wind or low temperatures. pallets, boxes, or strapped in bundles with stable base.

  • Page 59: Inspection And Maintenance

    General guidelines General guidelines are directed by a banksman who is in constant • ULMA is responsible for the delivery of the communication with the crane operator by products, for sale or rent, in good working means of a previously agreed sign code.
  • Page 60 ULMA Construcción equipment marketed by ULMA Construcción Before each use, the condition of element appliances Equipment with CE marking marketed by ULMA with CE marking must be checked. In case that it Constucción is checked following the instructions does not fulfil all defined requirements, it must be stipulated in the User´s Guide of the respective...
  • Page 61 MK STRUCTURE STRUCTURE STRUCTURE STRUCTURE 7. 7. 7. 7. L L L L EGAL REFERENCES EGAL REFERENCES EGAL REFERENCES EGAL REFERENCES • Council Directive 89/391/EEC Council Directive 89/391/EEC of 12 June 1989 on the introduction of measures to encourage improvements in...
  • Page 62 ULMA Construcción around the world www.ulma-c.com PRODUCTION PLANT Poland AND HEADQUARTERS ULMA Construccion Polska S.A. WARSAW ULMA C y E, S. Coop. www.ulma-c.pl Ps. Otadui, 3 - P.O. Box 13 WSCHÓD REGION 20560 OÑATI (Guipúzcoa) SPAIN WARSZAWA Branch Phone: + 34 943 034900...
  • Page 63 Bolton - ONTARIO P.R. China www.ulma-c.ca ULMA Formworks China R.O. LEVANTE Branch SHANGHAI NÁQUERA (Valencia) www.ulma-c.cn Chile MOLINA DE SEGURA (Murcia) ULMA Chile - Andamios y Moldajes, S.A. SANTIAGO www.ulma-c.cl ULMA Formworks UAE L.L.C. DUBAI Norte Branch www.ulma-c.ae ANTOFAGASTA Sur Branch India CONCEPCIÓN...
