AMF-BRUNS
USER AND INSTALLATION MANUAL
EASY PULL
FRONT WHEELCHAIR RESTRAINTS
WARNING
Carefully read, understand and follow all warnings and instructions provided in this manual, and keep it in a safe place for
future reference. If you have any doubt whatsoever regarding the use or maintenance of any AMF-Bruns product, please
contact AMF-Bruns. Failure to follow these warnings and instructions can result in product malfunction or loss of control of the
vehicle, causing an accident, severe personal injury or death. This guide contains current information at the time of printing.
AMF-Bruns reserves the right to modify systems or content without notice. Please visit our website for updated versions.
AMF-BRUNS OF AMERICA
www.amfbrunsamerica.com
REV 4/2018 Part Number: - TR-600002
