AMF-BRUNS
USERS GUIDE
ELECTRIC RETRACTORS
WARNING
Carefully read, understand and follow all warnings and instructions provided in this manual, and keep it in a safe place for future reference.
If you have any doubt whatsoever regarding the use or maintenance of any AMF-BRUNS product, please contact AMF-BRUNS.
Failure to follow these warnings and instructions can result in product malfunction or loss of control of the vehicle, causing an accident,
severe personal injury or death. This guide contains current information at the time of printing. AMF-Bruns reserves the right to
modify systems or content without notice. Please visit our website for updated versions.
AMF-BRUNS OF AMERICA
www.amfbrunsamerica.com
July 2019 • Part Number: TR700010
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AMF-BRUNS Electric Retractor
Summary of Contents for AMF-BRUNS Electric Retractor
- Page 1 Failure to follow these warnings and instructions can result in product malfunction or loss of control of the vehicle, causing an accident, severe personal injury or death. This guide contains current information at the time of printing. AMF-Bruns reserves the right to modify systems or content without notice.
- Page 3 Use only original spare parts or spare parts which have been approved of by AMF-Bruns. If spare parts other than these are used, this can have a negative effect on the specified characteristics, the functionality and safety of Electric Retractors.
- Page 4 ELECTRIC RETRACTORS 1) The following symbols and signage will be used in the Installation Instructions to emphasize safe installation and usage of this product: 2) Some text passages serve a special purpose. These are highlighted as lists and instructional text, i.e. a series of activities. 3) Meaning of directions: If directions are given in the text (in front of, front, behind, rear, right, left), these directions relate to the normal direction of travel of the vehicle.
- Page 5 Any incident such as this can cause severe personal injury or death, or result in property damage. 2) The product must be installed and repaired/modified by AMF-Bruns of America or an authorized dealer. 3) Read entire manual before using your product.
- Page 6 All systems require a second switch that de-energizes the relay, removing voltage to the Electric Retractors. In addition to these manual controls, the Electric Retractor installation shall be equipped with fail-safes that help to prevent them from being released while the vehicle is moving.
- Page 7 3) Position the wheelchair at the bottom of the ramp straight on and apply the wheelchair brake so that it is secure while attaching the Electric Retractor hooks / loops. 4) Turn on power to the Electric Retractors. This will unlock them and allow the webbing to be pulled out.
- Page 8 2) Open the access door and position ramp. 3) Release and remove the occupant restraints and place them in AMF-Bruns storage pouch (Part #: 10019363) so that they do not create a tripping hazard or get damaged.
- Page 9 3) Disengage the wheelchair or mobility aid brake, but DO NOT allow the wheelchair or mobility aid to roll forward at all. 4) Take hold of the Electric Retractor hook and webbing to ensure that the webbing is not retracted back into the housing.
- Page 10 Continue with the unloading of the wheelchair as trained. NOTE: If webbing is cut, call AMF-Bruns to replace the Electric Retractors (which is required) and order a belt cutter (Part #100207240) should you need to cut the webbing again.
- Page 11 ELECTRIC RETRACTORS • Always keep tie-downs and belts clean and off the floor by using AMF-Bruns storage pouch. Part #: 10019363. One storage device per wheelchair location is recommended. • All systems and components should be regularly inspected, cleaned and maintained.
- Page 12 • •• •...
