- Page 1 Users Guide UniStop Version 1.01 Go faster faster UNIPRO ApS VIBORG HOVEDVEJ 24 DK-7100 VEJLE DENMARK Tel.: +45 75 85 11 82 Fax: +45 75 85 17 82 www.uniprolaptimer.com mail@uniprolaptimer.com...
-
Page 2: Table Of Contents
Introduction..........................3 Overview..........................4 Quick Guide to the basic functions..................5 Turning UniStop on ....................5 Taking lap times and split times................5 Analyse mode ......................5 Clearing Laps ......................5 Turning UniStop off....................5 Reference Manual ........................7 Basic information ........................... 7 USB connector ....................... 7 Real-time Clock ...................... -
Page 3: Introduction
German, Italian, Danish, French, Spanish, Protoguese, Dutch and Norwegian. When other languages are added, new firmware (software) will be published on www.uniprolaptimer.com. If you have any problems or questions regarding your UniStop we will make sure to give you the necessary support. -
Page 4: Overview
Overview We have put a lot of effort into making UniStop very fast and easy to operate. The feedback we get from drivers and teams using UniStop tells us that we have succeeded. Here you can get an overview over the functions in UniStop. -
Page 5: Quick Guide To The Basic Functions
You always have to confirm by pressing OK except when using the first method. TURNING UNISTOP OFF Pressing the MENU button and holding it down will turn UniStop off. You can do the same from the main menu by choosing “POWER OFF”. - Page 6 UNIPRO – The original Laptimer...
-
Page 7: Reference Manual
The USB connection is compatible to USB version 2.0 full-speed. That is what you typically find on your PC. You have to notice, that UniStop acts as a device (or slave) so you will not be able to connect it to a USB printer. You should also notice that a special Unipro USB driver is needed on the PC. -
Page 8: Operating Modes
UniStop, for instance software version and owners name. At the same time UniStop is counting down to start with the LEDs at the top. After the count down, UniStop starts in the “Stop watch”. -
Page 9: Stop Watch
You will see the corresponding stop watch running in the display. Notice, that if you set UniStop to use “multistart”, all drivers will start at the same time. To take split times, you use the S1 – S4 buttons. One for each driver. You can take up to 8 split times per lap, but you are automatically getting a split from the last split point to the finish line. - Page 10 15 seconds before changing back to the current lap time. If no split times are measured on a lap, the last lap time is displayed instead of split times. The clock symbol at the top is indicating a stop watch is running. UNIPRO – The original Laptimer...
- Page 11 To change to this special mode, press and hold L2 when t urning UniStop on. If you want to change back again to normal m ode, press and hold L1 when turning on. You only need to do this change once, not every time you turn UniStop on! he example shows 4 drivers with the icons used.
- Page 12 Go to the “Main menu” If you already cleared the memory, the only thing you can chose from the popup menu is to go directly to the main menu. This example is shown on the picture on the left. UNIPRO – The original Laptimer...
-
Page 13: Stop Watch Analyse
OK. From the popup menu you will be able to do the following. • Clear all laps • Get more information, e.g. theoretical lap time and more • Go to the “Main menu” UNIPRO – The original Laptimer... -
Page 14: Info
4 drivers. If the theoretical lap time cannot be calculated, it is shown like “-:--:--“. When you press the OK button your UniStop will return to either the “Stop watch” or the “Stop Watch Analyse” screen. UNIPRO – The original Laptimer... -
Page 15: Main Menu
You can clearly see if the stop watch is running with the small clock icon at the top row. If you want to turn UniStop off, you use the arrow buttons to go to “POWER OFF” and then press the OK button. -
Page 16: Setup Menu
You can set the clock in two ways. The easiest way is to connect UniStop to the PC software called PC Watch. Every time you connect UniStop to the PC using the USB cable, the clock will be synchronized with the clock in the PC. -
Page 17: Language Setup
AUTO POWER-DOWN SETUP UniStop will automatically turn itself off if it is not used. To s batteries, you want it to turn off as fast as possible, but on the other hand it should not affect the daily work. -
Page 18: Pc Transfer
You will see the transfer status and progress on the screen. A progress bar goes from 0% to 100% indicating the data transfer. UniStop leaves PC mode and returns to the main menu as soon as the USB cable is removed again. -
Page 19: Battery Change
The battery voltage is measured when UniStop has not been touched for 10 seconds. The batteries are located inside the box. Put UniStop on the table with the backside up. Unscrew the six screws and remove the lower part of the box. Here you will see a battery holder with two standard Alkaline 1.5V AAA batteries.
