- Page 1 Quick Guide Unipro Laptimer 3004A Version 1.00 Go faster faster UNIPRO ApS VIBORG HOVEDVEJ 24 DK-7100 VEJLE DENMARK Tel.: +45 75 85 11 82 Fax: +45 75 85 17 82 www.uniprolaptimer.com mail@uniprolaptimer.com...
-
Page 2: Table Of Contents
Clear all laps ......................17 Take advantage of the advanced features................17 Measure and set the wheel circumference ....................17 Analyse your data ..........................17 Data Analyser ......................18 Transferring data from the Laptimer to the Data Analyser is easy..............18 UNIPRO – The original Laptimer... -
Page 3: Introduction
We constantly try to develop our products with the most useful features so you can use the Laptimer to go faster, faster but we always appreciate good ideas from the users of our products. If you have any problems or questions regarding your Unipro Laptimer we will make sure to give you the necessary support. -
Page 4: Get Ready To Go
If you have bought the basic package you should have following parts to your Laptimer: Main Box Display Unit Receiver – Loop, Magnet or IR RPM Sensor You may also have bought any of these extra accessories: Speed Kit UNIPRO – The original Laptimer... -
Page 5: Installation
Tighten the nut when the display is strait and centered in the steering wheel. This picture shows the correct mounted Display Unit. MAIN BOX The main box is mounted behind the front cover. The following picture is showing the main box and its components. UNIPRO – The original Laptimer... - Page 6 Use the enclosed umbracho screw The enclosed screw is screwed through the front coat to ease the mounting of the main box. Use a 5 mm umbracho. UNIPRO – The original Laptimer...
- Page 7 Make a loop on the cable and strip it to the steering column. Test by turning the steering wheel all the way to both sides and feel if the cable at any points feels tight. UNIPRO – The original Laptimer...
-
Page 8: Rpm Sensor
RPM SENSOR The RPM sensor comes standard with every Unipro Laptimer. We use an active sensor to ensure the best possible signal from all kind of engines. Mount the sensor with care. You do not want it to fall of during a race. If that happens, the Laptimer will turn itself off after 5 minutes and you will no longer be able to see your lap times. -
Page 9: Magnet Receiver
Measure and drill the hole from the side. The most important issue is to mount the receiver horizontal. Remember to place the infrared transmitter at the same height as the infrared receiver at least 3 meters from the track. UNIPRO – The original Laptimer... -
Page 10: Wheel Sensor Kit
Tighten the three screws hard, so the sensor disc doesn’t go loose when you’re driving. After the sensor disc is mounted, the centering bush is removed again. The wheel is now ready for mounting again. UNIPRO – The original Laptimer... -
Page 11: The Wheel Sensor
Fix the cable to the frame with strips all the way to the Main Box. The cable is mounted in the connector named WHEEL on the Main Box. Tighten the connector hard with your fingers. UNIPRO – The original Laptimer... -
Page 12: Basic Functions And Setup
We have put a lot of experience and effort into making the Display Unit very easy to operate on the track and in the pit. The feed back we get from drivers and teams using the Unipro Laptimer tells us that we have succeeded. Here you can get an overview over the functions on the Display Unit. -
Page 13: Receiver Type
Receiver type This is the receiver type screen. The Unipro Laptimer can use all types of receivers. You can choose between IR (infrared), Loop (AMB active loop) and Stripe (magnets). Use the buttons to choose the receiver type connected to the Laptimer. If you use a loop or infrared receiver, you can skip the... -
Page 14: Magnet Delay
We will get back to this later in the Quick Guide, and you can read all about it in the Reference Manual. With the settings mentioned above, you can start to use your Laptimer, getting precise lap times and RPM values. UNIPRO – The original Laptimer... -
Page 15: Practice And Race Using The Basic Functions
It is possible to manual adjust this delay in first lap mode. If driving with Loop or IR receiver, this part of the display is blank. When passing the finish line for the first time, the Laptimer change to running mode. UNIPRO – The original Laptimer... -
Page 16: Running Mode
The BEST LAPTIME icon at the top indicates the best lap time. The button changes the data shown in the upper display. Pressing several times changes between the high (maximum) and the low (minimum) data values stored. UNIPRO – The original Laptimer... -
Page 17: Clear All Laps
Laptimer to a Data Analyser or to a PC (via the Data Analyser). This will give you the possibility to print or store all data electronically, and to make further analysis of the data. UNIPRO – The original Laptimer... -
Page 18: Data Analyser
DATA ANALYSER The Unipro Data Analyser is the perfect companion for your Laptimer. It is the fastest way to getting data out of the Laptimer, with the possibility to print the data, or view them while the driver is on the track.
