Installation
This section provides installation instructions for wireless antennas supported on Cisco 1000 and 2000 Series Connected
Grid (CGR) routers. This section contains the following:
Antenna Ports, page 31

Safety Precautions

Warning: Do not locate the outdoor antenna near overhead power lines or other electric light or power circuits, or where
it can come into contact with such circuits. When installing the antenna, take extreme care not to come into contact with
such circuits, as they may cause serious injury or death. For proper installation and grounding of the antenna, please refer
to national and local codes (for example, U.S.:NFPA 70, National Electrical Code, Article 810, Canada:Canadian Electrical
Code, Section 54). Statement 1052
Each year hundreds of people are killed or injured when attempting to install an antenna. In many of these cases, the
victim was aware of the danger of electrocution, but did not take adequate steps to avoid the hazard.
For your safety, and to help you achieve a good installation, please read and follow these safety precautions. They may
save your life!
For your safety, read and follow these safety precautions.
If you are installing an antenna for the first time, for your own safety as well as others, seek professional assistance.
Your Cisco sales representative can explain which mounting method to use for the size and type antenna you are
about to install.
Before you install an antenna, contact your Cisco account representative to explain which mounting method to use
for the size and type of antenna that you are about to install.
Find someone to help you-installing an antenna is often a two-person job.
Cisco Systems, Inc.
www.cisco.com
27

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1726 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Audio Authority 1726

Summary of Contents for Audio Authority 1726

  • Page 1: Table Of Contents

    Installation This section provides installation instructions for wireless antennas supported on Cisco 1000 and 2000 Series Connected Grid (CGR) routers. This section contains the following:  Safety Precautions, page 27  Installation Requirements, page 28  General Installation Instructions for Mounting Antennas, page 30 ...

  • Page 2: Installation Requirements

     Select your installation site with safety, as well as performance, in mind. Remember that electric power lines and phone lines look alike. For your safety, assume that any overhead line can kill you.  Contact your electric power company. Tell them your plans and ask them to come look at your proposed installation. ...
  • Page 3  Customer premises field depot Before installing your antenna, determine the optimum location for safety and performance. Follow these steps to determine a safe distance from wires, power lines, and trees: Measure the height of your antenna. Add this length to the length of your tower or mast, then double this total for the minimum safe clearance distance from wires, power lines, and trees.

  • Page 4: General Installation Instructions For Mounting Antennas

     Microwave ovens and 2-GHz cordless phones can cause signal interference because they operate in the same frequency range as the WiFi radio to which one of the antennas is connected.  For instructions on installing or replacing a Cisco Connected Grid module, see the corresponding installation and configuration guide for each module.

  • Page 5: When To Install Or Replace Antennas

    When to Install or Replace Antennas Depending on the router configuration, it could arrive in the shipping container with all required antennas already installed and connected to the corresponding Cisco Connected Grid moduless (CG) that inside the router. However, you might need to install an antenna on the router when: ...
  • Page 6 Figure 1 CGR 1120 Antenna Ports WiFi antenna connector GPS antenna connector Cisco CGR 1240 antenna ports are shown in Figure Figure 2 CGR 1240 Antenna Port Numbers (Top of Router) Front of Router (Door) 3G auxiliary antenna 3G main antenna...
  • Page 7 Figure 3 CGR 1240 Antenna Port Numbers (Bottom of Router) Front of Router (Door) 900 MHz antenna Integrated WiFi antenna (router ships with this antenna installed) WiMAX antenna WiMAX antenna Unused Antenna Ports-N Connectors Port plugs or female N-connector bulkhead adapters with weatherproof caps must be installed in any unused antenna ports.

  • Page 8: Connecting The Antenna To The Cgr 1120

    Figure 4 N-Connector Installed in Unused Antenna Port Lightning arrestor N-connector: torque to 6 to 7 ft-lbs Plug: torque to 6 to 7 ft-lbs Ports must have either an antenna, connector, or plug installed. Connecting the Antenna to the CGR 1120 Secure the coaxial end of the end-to-end RF antenna cable to the antenna ports of your CGR 1120 router.

  • Page 9: Connect The Antenna-To-Module Cable In The Cgr 1240

    Figure 5 Insert Base of Antenna into Router Antenna Port WiFi antenna connector GPS antenna connector Connect the Antenna-to-Module Cable in the CGR 1240 The antenna-to-module coaxial antenna cable (MCX to QMA connectors) is shipped with your antenna. It is used as the interface between the external cable connection to the installed module.

  • Page 10: Antenna And Cg Module Color Codes

    Antenna base Universal coaxial antenna cable (MCX-to-QMA-male connector) Connected grid module coaxial connectors Universal coaxial cable, MCX end (QMA-female) From the exterior of the router, tighten the antenna using a strap wrench. Tighten to 6 to 7 ft-lbs. From the interior of the router, install the coaxial end of the cable to the appropriate connector on your installed module.

  • Page 11: Cisco Lightning Arrestors

    Figure 6 Example — Color Coding on Antenna Cable Color-coded antenna base The monopole antenna color code information follows: Color Antenna Product Number Connected Grid Module  Yellow ANT-MP-INT-OUT-M, 07-1140-02 RF900  RF antenna, 900MHz, 3G, WiFi, 2.5GHz WiMAX, omnidirectional, outdoor, transit style, 806 to 960 MHz, ...
  • Page 12 Consider the following:  Find a suitable location for the arrestor near a suitable ground per the relevant Safety codes.  The arrestor should either be bulkhead grounded (preferred way) or grounded through the lug provided and 6 AWG wire no more than 20" (50.8 cm) long. To install a lightning arrestor for the Cisco 1240 CGR (CGR-LA-NM-NF), see: http://www.cisco.com/en/US/docs/routers/connectedgrid/lightning_arrestor/Lightning_Arrestor_for_the_Cisco_1240 _Connected_Grid_Router.html...

  • Page 13: Obtaining Technical Assistance

    Securely clamp the wire to the bottom of the mast. Secure the lead-in wire to a lightning arrestor and mast ground wire to the building with stand-off insulators spaced from 4 ft (1.2 m) to 8 ft (1.8 m) apart. Mount the lightning arrestor as close as possible to the lead-in wire entry point on the building wall.

  • Page 14: Additional Information

    Additional Information Antenna Information For additional documentation, see the following:  For information about antennas and modules, see: www.cisco.com/go/cg-modules  For information on omnidirectional and directional antennas, see: http://www.cisco.com/en/US/tech/tk722/tk809/technologies_tech_note09186a00807f34d3.shtml Cisco General Information  Access the most current Cisco documentation at: http://www.cisco.com/cisco/web/support/index.html ...
