  • Page 1 HD uDTA INSTALL Resource Book © 2013 Evolution Digital, LLC | This document contains confidential and privileged material for the sole use of the intended recipient.
  • Page 2 HD uDTA Customer Facing User Guide Liberty HD uDTA Wall-Plate Device Installation HD uDTA Traning Presentation HD uDTA Technical User Guide © 2013 Evolution Digital, LLC | This document contains confidential and privileged material for the sole use of the intended recipient.
  • Page 3 HD uDTA Customer Facing User Guide © 2013 Evolution Digital, LLC | This document contains confidential and privileged material for the sole use of the intended recipient.
  • Page 4 © 2013 Evolution Digital, LLC. All Rights Reserved. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI licensing LLC.
  • Page 5 Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. Getting Set Up In the box ê Thank You for choosing the Evolution Digital High- HD Set-Top Box Definition Set-Top Box (HD STB). You can now enjoy...

  • Page 6: Remote Control

    HDMI allows you to take full advantage Activation essentially “turns on” your digital box in your home and on your cable provider’s network. the “HDMI” port on your HDTV. of the Evolution Digital HD Set-Top Box high-definition digital features. 3. Connect the power cord to the To TV electrical wall outlet and the “DC 5V...

  • Page 7: Menu/Locks Setup

    Menu Menu Menu Locks Setup ç Using the RF output? The first time you enter Locks Setup, it will prompt you to Press the Menu button on your remote control to access the main menu. The menu Create Locks PIN. Enter your desired PIN and keep that in a safe will allow you to update your HD set-top box settings.
  • Page 8 Liberty HD uDTA Wall-Plate Device Installation © 2013 Evolution Digital, LLC | This document contains confidential and privileged material for the sole use of the intended recipient.
  • Page 9 HDMI to TV Liberty Reset button RF Output Channel 3/4 Removable DC Switch power supply HD uDTA Wall Plate Device Bottom Bypass port to connect secondary devices Screw Hole such as DVR or cable modem. (optional) Installation Set desired RF channel...
  • Page 10 HD uDTA Training Presentation © 2013 Evolution Digital, LLC | This document contains confidential and privileged material for the sole use of the intended recipient.
  • Page 11 Modes of Operation •  Boot •  Hunt •  Pending Initialization •  Normal Operations •  Code Download •  Trouble © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 12 •  Function: Validate/launch code image •  LED Status: None •  Valid Mode Transitions: Hunt Mode (if code image is successfully validated), Trouble Mode (if code image fails validation) © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 13 •  Function: Search for QAM with CAT PID and valid CA system ID •  LED Status: Continuous blink •  Valid Mode Transition: Pending Initialization (upon receipt of CAT PID) © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 14 •  If the DTA does not lock on to any of those frequencies it will start hunting at 57 MHz and increment by 6 MHz until it finds a valid QAM © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 15 Hunt Mode On-Screen Message © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 16 PID for SI, monitoring EMM PID for headend messaging •  LED Status: Two blinks, repeated continuously •  Valid Mode Transitions: Code Download, Boot, Normal Operations © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 17 Pending Initialization Mode On-Screen Message © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 18 •  Function: Decoding A/V, Monitoring SI data and EMM messages and remote control commands •  LED Status: Solid green, no blinking •  Valid Mode Transitions: Pending Initialization, Code Download, Boot © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 19 •  Function: Download new code image •  LED Status: Three blinks followed by a long pause •  Valid Mode Transitions: Boot (upon successful download), previous mode (upon failed download) © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 20 Code Download On-Screen Message © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 21 •  The DTA will only enter trouble mode from boot mode •  LED Status: Continuous short blink •  Valid Mode Transitions: None, the DTA must be reset in order to re-attempt a proper boot © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 22 Boot and Trouble) •  Although there are a large number of options, this presentation will only cover those that will be most useful in troubleshooting the DTA. © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 23 Diagnostics Menu © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 24 General Info Menu •  This menu gives key information about the DTA including hardware version, unit ID, MAC address etc. © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 25 HD DTA Status Menu 1 •  This menu gives information on the status of the DTA including the activated status as well as the current operating mode © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 26 HD DTA Status Menu 2 •  The second page of the HD DTA Status menu gives information about the time configuration of the DTA © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 27 Tuner Status Menu •  This menu tells you what frequency the DTA is currently tuned to and gives information about the power level, SNR, and CAT PID © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 28 PIDs are present •  The channel can be changed real time while viewing this menu by either direct channel entry or by using the CH up/down buttons on the remote © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 29 Current Channel Status © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 30 •  The virtual channel map will likely be several pages long and can be navigated using the up and down arrows on the remote control © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 31 Virtual Channel Map © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 32 Received Messages •  The received messages menu shows real time counters of all messages that have been received from the headend controller © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 33 •  If both banks display a code name then the bank with the asterisk next to it is the SW that the DTA is currently running and the other bank is the previously loaded SW © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 34 Code Objects © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 35 •  Tuner Status (while the DTA is tuned to the problematic channel or channels) •  Current Channel Status (of the problematic channel or channels) •  Code Objects •  Received Messages © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 36 Troubleshooting •  Additionally, a full QAM capture (capture of the RF input to the DTA) may be required © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 37 •  When all of this information has been gathered please contact Evolution support at support@evolutionbb.com for further instructions •  Note that the two steps listed above should be completed by headend personnel © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 38 DTA will be reset): •  Enter the diagnostics menu by holding 7 on the remote control © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 39 Factory Reset •  Once you are in the diagnostics menu, press the info button on the remote control to display the following hidden menu: © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 40 OK button on the remote control to complete the process •  After a successful reset the DTA will reboot and enter hunt mode © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 41 Remote © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 42 •  To pair the remote take the following steps (note that line of sight is required between the remote and the DTA during the pairing process): © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 43 RF Remote Pairing •  Enter the Setup menu by pressing the Menu button on the remote and then select Remote Control and press the OK button © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 44 RF Remote Pairing •  After you select Remote Control Pairing you will see a popup screen with instructions on how to complete the process © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 45 RF Remote Pairing •  Hold the Setup button on the remote until the LED turns green and then press the Menu button to bring up the code entry popup © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 46 IR will no longer be transmitted) •  Also note that the DTA will always be able to receive IR commands as a failsafe regardless of whether or not a remote is paired with it © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 47 RF Remote Pairing © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 48 9, 8, 7 •  If the code is entered successfully the LED will blink green two times and the remote will be unpaired and operate in IR mode © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 49 LED turns green and then enter 9, 8, 6 •  If the code is entered successfully the LED will blink green two times and the remote will no longer be able to control the television © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 50 (all RF pairing information and TV control will be reset and the remote will operate in IR mode) © 2013 Evolution Digital, LLC. All Rights Reserved. Confidential information.! 8/13/12...
  • Page 51 HD uDTA Technical User Guide © 2013 Evolution Digital, LLC | This document contains confidential and privileged material for the sole use of the intended recipient.
  • Page 52 DMS-2002HD-U User Guide Evolution Digital, LLC 7347 S. Revere Parkway, Building A | Centennial, CO 80112 www.evolutionbb.com | 800-315-2253    ...

  • Page 53: Table Of Contents

    Evolution Digital Table of Contents     Introduction ..............................10     Terms and Abbreviations ..........................10     References ..............................11     Document Overview .............................11     Out of Scope Material ...........................12     DTA Modes ..............................12     High Level Overview ............................12  ...
  • Page 54 Evolution Digital     2.5.3 Interruption to Service ..........................29     2.5.4 Mode Transitions ............................30     Code Download Mode ..........................30     2.6.1 CVT.................................32     2.6.2 CVT Configuration Count ........................32     2.6.2.1 Location Value 0 ..........................33  ...
  • Page 55 6.10 Code Objects ..............................62     6.11 Code Download ............................63     6.12 HDMI ................................65     Evolution Digital Defined ..........................67     SI Descriptors ..............................68     Decoder Status ..............................69     RF Remote Control ............................69     EAS Location ..............................73  ...
  • Page 56 Evolution Digital     Hunt Mode ..............................73     Manual Clear ..............................73   Appendix A Frequency Hunt List ..........................75   Appendix B Default NVRAM Values .........................76   Appendix C Additional DTA Screenshots ........................77   Appendix D DTA Headend Messages .........................79  ...
  • Page 57 Evolution Digital List of Tables   Table 1 List of Terms and Abbreviations ........................10   Table 2 Boot Mode Properties .............................13   Table 3 Hunt Mode Properties ............................14   Table 4 Hunt Mode Progress Bar Percentages ......................18   Table 5 Pending Initialization Mode Properties ......................20  ...
  • Page 58 Evolution Digital   Table 24 NVRAM Default Values ..........................76 List of Figures   Figure 1 DTA Boot Sequence to Normal Operations ....................13   Figure 2 DTA Status, Hunt Mode ..........................15   Figure 3 Tuner Status, Hunt Mode ..........................16   Figure 4 Tuner Status, Pending Initialization Mode ....................17  ...
  • Page 59 Figure 39 Diagnostic Menu – Code Download ......................65   Figure 40 Diagnostic Menu – HDMI ...........................67   Figure 41 Evolution Digital Defined Menu .........................68   Figure 42 SI Descriptors Screen ..........................69   Figure 43 Diagnostic Menu – RF Remote Control, Screen 1 ..................72  ...
  • Page 60 Evolution Digital   Figure 47 DTA On-Screen Information – Channel Info ....................77   Figure 48 DTA On-Screen Information – Volume Bar ....................77   Figure 49 DTA On-Screen Information – Muted Volume Bar ..................78 Version Control Version Date Notes Author 06/15/2012 Initial Release A.Schneider...

  • Page 61: Introduction

    Evolution Digital Introduction This document provides detailed support and user information about Evolution Digital DTA, model number DMS- 2002U. This intended audience for this document is cable operator technicians and customer support personnel. Terms and Abbreviations Table 1 List of Terms and Abbreviations...

  • Page 62: References

    Evolution Digital Source Name Subtable System Time Clock System Time Table Virtual Channel Map References [Ref 1] OpenCable Common Download 2.0 Specification, OC-SP-CDL2.0-I06-080118, January 18, 2008, Cable Television Laboratories [Ref 2] Service Information Delivered Out-of-Band for Digital Cable Television, SCTE 65, 2008...

  • Page 63: Out Of Scope Material

    Evolution Digital Out of Scope Material Headend configuration and management is not covered in this document. Evolution Digital does not manufacture the headend equipment necessary to activate and configure the DTA. The operator must consult the manufacture and vendor of the headend equipment for questions regarding the operation and configuration of such equipment.

  • Page 64: Boot Mode

    Evolution Digital Figure 1 DTA Boot Sequence to Normal Operations Boot Mode The DTA will enter Boot Mode when power is applied or after a reset command has been received from the headend controller. While in Boot Mode, the DTA will validate the active code image. Once validated, the DTA will launch the image.

  • Page 65: Reset Processing

    Evolution Digital IR Input Disabled In-band Message None Processing Please note the DTA should not be sent an activation and or configuration message while in Boot Mode. These messages should only be sent when the DTA is in Pending Initialization Mode.

  • Page 66: Figure 2 Dta Status, Hunt Mode

    Evolution Digital A/V Decode None Diagnostics Available IR Input Available In-band Message Only processing CAT PID. Processing Figure 2 shows the DTA Status diagnostic screen while the DTA is in Hunt Mode. Please note the DTA should not be sent an activation and or configuration message while in Hunt Mode. These messages should only be sent when the DTA is in Pending Initialization Mode.

  • Page 67: Qam Search

    Evolution Digital Figure 3 Tuner Status, Hunt Mode 2.3.1 QAM Search Upon entering Hunt Mode, the DTA will check if the Turn On QAM is set in NVRAM. If the Turn On QAM is set, the DTA will attempt to tune to this QAM. If the DTA does not lock within 1 second, it will continue searching for QAMs.

  • Page 68: Ca System Id

    Evolution Digital Figure 4 Tuner Status, Pending Initialization Mode 2.3.1.1 CA System ID The DTA recognizes two CA System IDs. They are 0x0E11 for a Cisco headend and 0x4749 for a Motorola headend. 2.3.1.2 Network PID As part of exiting Hunt Mode into Pending Initialization Mode, the DTA will detect the Network PID to use for SI data.

  • Page 69: Table 4 Hunt Mode Progress Bar Percentages

    Evolution Digital Figure 5 Hunt Mode On-Screen Message – Initial Scan This message is displayed while the DTA performs its initial hunt for QAM lock and CAT with CA system ID detection. The progress bar is shown on-screen for the duration of two full iterations through the predefined frequency list detailed in Appendix A Frequency Hunt List.

  • Page 70: Mode Transitions

    Evolution Digital After completing two iterations through the progress bar (reaching 100% two times) and failing to lock onto a QAM and detect a CAT PID with a valid CA system ID, the DTA will display the on-screen message shown in Figure 6.

  • Page 71: Table 5 Pending Initialization Mode Properties

    Evolution Digital Table 5 Pending Initialization Mode Properties Mode activities Verifying CA parameters found in hunt mode, monitoring network PID and EMM PID Valid Mode Transition(s) Common Download, Boot, Normal Operations LED status Two blinks, repeated continuously A/V Decode None...

  • Page 72: Ca Values Check

    Evolution Digital Figure 7 DTA Status Screen during Pending Initialization Figure 4 in Section 2.3.1 shows the Tuner Status screen when the DTA enters Pending Initialization Mode from Hunt Mode. 2.4.1 CA Values check Upon receiving the CAT PID with valid CA System ID, the DTA will store the CA System ID and EMM Provider ID as temporary values.

  • Page 73: Transition To Normal Operations

    Evolution Digital Site Code • In addition to setting the parameters listed above, the headend will assign the DTA to a VCT ID. The DTA will transition to Normal Operations mode once it has received the headend messaging to configure and activate the DTA and the DTA has fully downloaded and loaded the virtual channel map.

  • Page 74: Network Pid Monitoring

    Evolution Digital Pending Init Don’t care Zero Max LocID > Current LocID Pending Init Don’t care Zero Current LocID >= Max LocID Pending Init Any nonzero value Nonzero Don’t care Pending Init Don’t care Zero Don’t care In summary, if the Activation Flag is set to 0, the DTA will not enter Normal Operations Mode. If the Timeout Counter has reached 0, the DTA will revert to Pending Initialization mode.

  • Page 75: Figure 9 Activation Support Message - Initial Entry To Pending Init

    Evolution Digital Timeout Value Parameter is 0 Timeout Value Parameter is greater than 0, but the Timeout Counter is 0 Current Error Count is greater than Configured Error Count No channel map available for the assigned VCT ID Figure 9 shows the Activation Support message displayed on screen after immediately entering Pending Init.

  • Page 76: Figure 10 Activation Support Message - Cable Operator Defined Custom Message

    Evolution Digital Figure 10 Activation Support Message – Cable Operator Defined Custom Message You will notice that the text beneath “Your service needs to be activated before continuing” is the text that is fully customizable by the Cable Operator; this is commonly referred to as the “MSO Phone Number field”. For more information on the use of this field, please see Section 6.5.1.
