ST310014ACE Product Manual, Rev. D v
Figures
Figure 1. Typical startup and operation current profile . . . . . . . . . . . . 7
Figure 2. Breather filter hole location . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 3. Master/slave jumper settings . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 4. Mounting dimensions-top, side and end view . . . . . . . . . 19
Figure 5. I/O pins and supported ATA signals. . . . . . . . . . . . . . . . . . 21
