1.0 Drive specifications

Unless otherwise noted, all specifications are measured under ambient
conditions, at 25°C, and nominal power. For convenience, the phrases
the drive and this drive are used throughout this manual to indicate the
ST310014ACE.

1.1 Formatted capacity

Drive Model
ST310014ACE

1.1.1 Default logical geometry

CHS Mode
ST310014ACE
LBA Mode
When addressing drive in LBA mode, all blocks (sectors) are consecu-
tively numbered from 0 to n–1, where n is the number of guaranteed
sectors as defined above.

1.2 Physical organization

Drive Model
ST310014ACE

1.3 Recording and interface technology

Interface
Recording method
Recording density BPI (bits/inch)
Track density TPI (tracks/inch)
Areal density (Mbits/inch
Spindle speed (RPM) (± 0.2%)
Internal data-transfer rate
(Mbits/sec max)
ST310014ACE Product Manual, Rev. D
Formatted Gbytes
10.0
Cylinders
16,383
Read/Write heads (GMR)
1
2
max)
Guaranteed
sectors
20,005,650
Read/Write
heads
16
Number of discs
ATA
96/102 GPRML
376,200
58,000
21,800
5,400
366
Bytes per
sector
512
Sectors per
track
63
