ST310014ACE Product Manual, Rev. D

2.1 Drive mounting

You can mount the drive in any orientation using four screws in the side-
mounting holes or four screws in the bottom-mounting holes. See Figure
3 for drive mounting dimensions. Follow these important mounting
precautions when mounting the drive:
•
Allow a minimum clearance of 0.030 inches (0.76 mm) around the
entire perimeter of the drive for cooling.
•
Use only 6-32 UNC mounting screws. Insert the screws no more than
0.20 inch (5.08 mm) into the bottom mounting holes and no more than
0.14 inch (3.55 mm) into the side mounting holes.
•
Do not overtighten the mounting screws (maximum torque: 6 inch-lb).
•
Do not use a drive interface cable that is more than 18 inches long.
Notes:
1. Dimensions are shown in inches (mm)
Dimensions are per SFF-8301 specification
0.787 in. max
(19.99 mm)
0.250 in. max
(6.350 mm)
+0.024
1.140
–0.015
+0.635
(28.956
–0.381
+0.025
1.683 in.
–0.015
+0.635
(41.605 mm)
–0.381
+0.025
4.000
–0.015
+0.635
(101.60
–0.381
3X 6-32 UNC-2B
max. insertion depth
0.14 in. both sides
Figure 4. Mounting dimensions—top, side and end view
0.226 in.
(5.750 mm)
in.
mm)
+0.015
5.770 in.
–0.005
in.
+0.38
(146.56 mm)
–0.13
mm)
0.125 in.
(3.175 mm)
4.000 in.
(101.600 mm)
2.229 in.
(56.616 mm)
2.829 in.
(71.856 mm)
3.717 ± 0.30 in.
(94.406 ± 0.762 mm)
3.750 ± 0.10 in.
(95.250 ± 0.254 mm)
+0.015
4.000 in.
–0.005
+0.381
(101.60 mm)
–0.127
19
0.176 ± 0.015 in.
(4.480 ± 0.381 mm)
+0.020
2X 1.645 in.
–0.010
+0.508
(41.783 mm)
–0.254
+0.020
2X 1.750 in.
–0.010
+0.508
(44.450 mm)
–0.254
4X 6-32 UNC-2B
max. insertion depth
0.22 in.
